Maximum 065-3114-8 Instruction Manual

1000 Lumens
Rechargeable Headlamp
model no. 065-3114-8
IMPORTANT:
Please read this manual carefully before
using this headlamp and save it for future
reference.
3
model no. 065-3114-8 | contact us 1.888.670.6682
INSTALLATION
Detachable Headband
MULTI-ANGLE LIGHTING
TYPE-C DIRECT CHARGING
Red light: Charging
Blue light: Fully charged
Charging time: 3.5 ± 1 h
(Fully charged by connecting Type-C
cable to 5 V / 1 A)
WARNING!
To prevent damage to eyesight, never look directly into the light when it is on. Do not shine light directly
into someone's face.
Please charge up the battery completely the first time it is used; if left unused for a long time, recharge
every three months.
Do not place the activated headlamp near flammable materials, fire or extreme heat.
Do not dismantle the bulb assembly.
成品尺寸：46.6mm × 23.3mm
展开尺寸：140mm × 140mm
印刷说明：80克双胶纸双面印刷
颜色： PANTONE 2945 C+K
2
model no. 065-3114-8 | contact us 1.888.670.6682
Technical Specifications
ANSI/PLATO-FL1
Light Output
Run Time
Beam Distance
Impact Resistance
Water Resistance
Weight And
Dimensions
Body Material
Includes
FEATURES
1
OSRAM LED, max output up to 1000 lumens
INSTRUCTION
2
Detachable headband for convenient and portable lighting
MANUAL
3
360 ° rotatable head for mode switch, easy to operate
4
MODE SWITCHING
Rotating the head for mode switching: high, medium, low and o
MAINTENANCE
If headlamp comes in contact with salt water or corrosive chemicals,
1
please rinse immediately with clean water and dry.
Please keep headlamp dry and cool when it is not in use for an
2
extended period of time.
LIFETIME WARRANTY
This MAXIMUM product carries a lifetime warranty against defects in
workmanship and materials. This product is not guaranteed against
wear and tear or breakage due to misuse and/or abuse. At its discretion,
Maximum Canada will repair or replace any defective product parts at no
charge when returned by the original purchaser with proof of purchase.
If this product is discontinued or no longer available for sale, Maximum
Canada, as its sole discretion, will provide a comparable substitute item.
MADE IN CHINA
IMPORTED BY MAXIMUM CANADA
TORONTO, CANADA M4S 2B8
High Medium
1000 lm 150 lm
4 h 30 min 8 h
190 m
1 m
IPX-4
Weight: 149 g
Light body: 34 x 18.5 x 34 mm
Battery pack: 73 x 43 x 31.5 mm
Light Source: OSRAM LED
Aluminum and plastic
3.6 V / 9.36 Wh built-in 18650 rechargeable lithium-ion battery, Type-C Cable
High
O
Medium
Low
Low
20 lm
40 h
