IDEC KW2D Series Manual
Ø22 smart rfid reader
Hide thumbs
Also See for KW2D Series:
- User manual (123 pages) ,
- User manual (91 pages) ,
- User manual (129 pages)
Related Manuals for IDEC KW2D Series
Summary of Contents for IDEC KW2D Series
- Page 1 ø22 SMART RFID READER KW2D SERIES Smart RFID Reader Manage user authority for machines and equipment Control and track access to production sites...
- Page 2 ø22 KW2D Series Compact and smart design ideal for factory automation environments Mounts on ø22mm panel cut-out * Actual size Front unit: 43.6 × 43.6mm Panel front height: 9.0mm Back unit: 40.0 × 40.0mm Can be used for IC Depth: 48.5mm cards, such as employee IDs...
- Page 3 Panel Mount RFID Reader Holder feature available for mounting RFID tags * 5 types are available (sold separately). An Ethernet port enhances connection compatibility with host devices • Supported protocol: Modbus TCP (server) * EtherNet/IP and CC-LINK IE FB will be supported soon. With a verification function inside, the Verification result (Success/Error) Name 1, 2...
-
Page 4: Application Examples
Application Examples Manage user authority for machines and devices BEFORE Anyone can operate the machines. AFTER Inadvertent operation and setting changes are prevented, reducing equipment malfunctions and failures. Mount the RFID reader on the operation panel of a machine and register the workers in the RFID reader. - Page 5 KW2D SERIES Manage inspection history BEFORE Inspection reports were written by hand. AFTER After inspection work, employee ID cards are read and data is recorded. Inspection details are recorded as electronic data and linked to worker data. The time and work details are recorded on a touch panel or PLC to ensure reliable traceability.
-
Page 6: Operating Environment
1.0GHz or more Memory 1GB or more Environment Microsoft.NET Framework4.0 or later * The configuration tool can be downloaded from the IDEC website. Screen 1 RFID Reader Configuration Screen Intuitive operation allows settings to be configured on a single screen. Only the... -
Page 7: Connection Diagram
KW2D SERIES Connection diagram * Connect to a computer when configuring settings. LAN cable Screen 2 Tag List Registration Screen • Up to 500 items • Import and export as CSV file The RFID reader is equipped with a verification function, enabling output of arbitrary data. -
Page 8: System Configuration Example
System Configuration Example KW2D SERIES When using a supported communication protocol UID: 123456789 KW2D series PLC or Switching hub 0ABCDEF RFID Reader controller Employee ID card Verification - Success External device - Inverter, motor, * The same configuration is also used for EtherNet/IP and etc. - Page 9 Compact RFID reader with integrated functions for the factory automation industry Without holder With holder Note: Approvals apply only to the main unit. • For more information about certified products, see the IDEC website. Main Unit Package Quantity: 1 Model...
- Page 10 *2 The tag reading distance is a value that was measured using the tags listed in “Names Buzzer Single tone of LSIs in Tested Tags” (on page 2-3 of the User’s Manual) that IDEC has tested. The tag FR, 94V-0 reading distance will vary depending on the tag that is actually used and the operating environment.
- Page 11 KW2D Series ø22 Smart RFID Reader Dimensions (Units: mm) Main Unit Without holder: KW2D-R100Q4E Panel thickness: 0.8 to 4.0 43.6 48.5 40.0 With holder: KW2D-RH100Q4E Panel thickness: 0.8 to 4.0 43.6 16.5 48.5 40.0...
- Page 12 KW2D Series ø22 Smart RFID Reader Dimensions (Units: mm) KEYFOB type: KW9Z-T1X1G, KW9Z-T1X2Y, KW9Z-T1X3R, KW9Z-T1X4S, KW9Z-T1X5B *1 Minimum size with KEYFOB attached. Card type: KW9Z-T2X0 85.7 85.7 54.0 Cover KW9Z-CV KW9Z-CVH 43.3 16.4 43.3 16.4 43.3 43.3...
- Page 13 KW2D Series ø22 Smart RFID Reader Safety Precautions • Be sure to turn off the power before starting installation, removal, wiring, maintenance, and inspection work. Failure to turn power off may cause electrical shocks or fire hazard. Precautions for Use...
- Page 14 The following recommended tools can be used. The recommended Power Supply Wiring tools are manufactured by Weidmüller. • The KW2D Series RFID Reader has a push-in style terminal block. Name Weidmüller Recommended Part No. • An inrush current of 25A or lower (when input is 24V DC) flows when Normal type SDS 0.4 ×...
- Page 15 IDEC product fails Furthermore, the warranty described here refers to a warranty on the IDEC product as a unit, and damages induced by the failure of an IDEC product are iii. Wiring and installation that ensures the IDEC product used in your excluded from this warranty.
- Page 16 For details on installation, wiring, and maintenance, see the Instruction Sheet and User’s Manual from the URL below. URL: https://product.idec.com/?product=KW2D IDEC recommends the use of the RFID reader with the following products. Flush Silhouette Switches PLCs/Controllers/Operator Interfaces USB/RJ45 Relay Ports...
