update the firmware first. To get detailed information about the firmware
upgrade, see the Firmware Upgrade Section.
When you slide the switch to the ON position, the LED will blink with short intervals
and the device will start to work.

4. Camera and Flash Connection

The MIOPS Splash uses connection cables to trigger your camera or flash unit. Your
unit will be shipped with a flash cable. You should purchase a camera cable
separately if you need to trigger your camera. The MIOPS Splash is a versatile
device, which is compatible with many brand and models. You can use the same
device with many different cameras by just changing the connection cable.
The MIOPS Splash has separate outputs for the camera and flash cables. The
camera cable port is a 2.5 mm stereo female jack. The camera cables have the
male 2.5 mm stereo jack on one end. This end is plugged into the camera
connection port. The other end changes depending on the camera
make and model. This end is plugged in the shutter release port of your camera.
The flash cable port is a 3.5 mm stereo female jack. There is only one type of flash
connection cable. It has a 3.5 mm male jack on one end. This end is plugged into
the flash connection port. The other end of the cable is a standard PC Sync port.
This end is connected to the PC Sync port of the flash unit. If your flash does not
have a PC Sync port, you can use a hot shoe adapter with a PC Sync port.
The camera and flash cables are designed to trigger the cameras and flash units
only. Do not use them for any other purpose. Doing so may damage the cable or the
device.

5. Mobile Application

MIOPS Splash requires a mobile app which has been designed as an interface to
configure and control your device easily. The communication between the
smartphone and MIOPS Splash is done over Bluetooth connection. So, your
smartphone has to be compatible with Bluetooth 4.0.
MIOPS MOBILE app is available on iOS and Android platforms. Search for MIOPS
MOBILE in your app store, or use the following buttons to download the app.

6. Connecting to MIOPS Splash
