Vimpex BIG HP18-H200-B1 Operation Manual

High performance fans

Advertisement

HOCHLEISTUNGSLÜFTER
ANS
HIGH PERFORMANCE FANS
HOCHLEISTUNGSLÜFTER
HIGH PERFORMANCE FANS
BEDIENUNGSANLEITUNG
ANUAL
OPERATIONS MANUAL
BEDIENUNGSANLEITUNG
OPERATIONS MANUAL
HP18 H/ES/EV
HP18 H/ES/EV
03/2019
03/2019
03/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIG HP18-H200-B1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vimpex BIG HP18-H200-B1

  • Page 1 FTER HOCHLEISTUNGSLÜFTER HIGH PERFORMANCE FANS HOCHLEISTUNGSLÜFTER HIGH PERFORMANCE FANS ANLEITUNG BEDIENUNGSANLEITUNG ANUAL OPERATIONS MANUAL BEDIENUNGSANLEITUNG OPERATIONS MANUAL HP18 H/ES/EV 03/2019 03/2019 HP18 H/ES/EV 03/2019...
  • Page 2 Thank you very much for choosing a BIG High Performance Fan. High Performance Fans are well proven in firefighting operations all over the world. Read the operations manual carefully before you start any operation. If you have any questions about your fan, ask your dealer or contact us directly. Thank you very much for choosing a BIG High Performance Fan.
  • Page 3: Designated Use

    INTRODUCTION Your High Performance Fan was build in accordance with approved safety regulations. A security check and a final inspection were fulfilled. However failure to follow the correct operation or misuse may result in serious personal injury, injury of a third party and/or damage to equipment and other property.
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS The suction area of the fan must be free from any objects, which could be picked up in the air stream and flown in the air. Pay special attention that no clothing or long hair could be sucked in. Do not put anything through the safety grill while operating.
  • Page 5: Pre-Operation

    PRE-OPERATION Before you start any operation make a visual inspection and check the fan for damage. In case of damage operational safety is not assured, don’t use the fan for any operation. MODELS WITH ELECTRIC DRIVE Make sure there is a suitable power supply. Consider the high power consumption, espe- cially at power-up due to the high performance of the fan.
  • Page 6 TRANSPORT The fan is equipped with versatile, innova- tive grip options for an easy handling and unloading. In addition to the color-highlighted handles (1), which can be gripped both at the top and bottom, the frame (2) offers all around areas that can be comfortably grabbed with firefighting gloves.
  • Page 7: Tilt Mechanism

    TILT MECHANISM For an optimum airflow to the ventilation opening, the inclination of the fan can be adjusted with the tilt mechanism. Hold the fan at the handle and release the locking of the tilt mechanism using the foot- operated bar. Tilt the fan and release the bar to lock the tilt mechanism by spring tension into the according notch.
  • Page 8 STARTING / STOPPING MODELS WITH COMBUSTION ENGINE STARTING Open the fuel valve (A). For cold starting set the choke-lever (B) on CLOSED position. For warm starting let the choke-lever on OPEN position. Set the throttle lever (C) to the 1/3 open position bteween MIN. and MAX. Set the ignition switch (D) on position ON.
  • Page 9 STOPPING Move the throttle lever (C) to the idle position. Turn the ignition switch (D) to the OFF position. Close the fuel valve (A). For an emergency stop just set the ignition switch to position OFF. Refer to the engine manufacturers Owners Manual for additional informa- tion.
  • Page 10: Maintenance

    MAINTENANCE Proper maintenance is necessary to ensure that your fan operates as efficiently and trouble- free as possible. Always deactivate the engine during maintenance work: with combustion engine set the ignition switch to OFF and remove the spark plug connector; with electric drive generally pull the power plug! Maintenance and repair only by personnel who have technical knowledge and are familiar with the fan.
  • Page 11: Troubleshooting

    MODELS WITH ELECTRIC DRIVE after every use every 12 months Inspect blower for damage and repair if any Check electric power lines for damage Safety inspection for all electric components Check all bolted connections, tighten or replace if necessary TROUBLESHOOTING Movement of the fan or „walking“...
  • Page 12: Technical Data

    TECHNICAL DATA Blade: Fiberglass Reinforced Polyamide Shroud: Aluminum Grill: front: Polymer rear: Steel, zinc-plated Frame: Lightweight, Aluminum and Steel tubing, powder-coated Handle: Aluminum, patented ergonomic design Tilt Mechanism: Stainless Steel, 7 or 9 positions, foot-operated HP18-H2 HP18-ES2 HP18-EV2 Type HP -H HP -ES , -B HP -EV , -B Drive...
  • Page 13 Nr. / No 12.1 15.1 23.1 33.1 33.2 25 26...
  • Page 14: Ersatzteile / Spare Parts

    ERSATZTEILE / SPARE PARTS ERSATZTEILE / SPARE PARTS ERSATZTEILE / SPARE PARTS Beschreibung Beschreibung Nr. / No. Beschreibung Description Description Description Luftleitmantel mit Frontgitter Luftleitmantel mit Frontgitter Luftleitmantel mit Frontgitter Shroud with front grill Shroud with front grill Shroud with front grill Luftleitmantel mit Luftleiteinheit Luftleitmantel mit Luftleiteinheit Luftleitmantel mit Luftleiteinheit...
  • Page 15 EG-Konformitätserklärung / EC Declaration of conformity gemäß Anhang II A der EG-Maschinenrichtlinie 2006/42/EG in accordance with the EC machine directive 2006/42/EC, appendix II A Die Firma / The company B.S. Belüftungs-GmbH Am Hungerwiesgraben 10 D-89429 Bachhagel, Germany erklärt, dass die bezeichnete Maschine / declares that the product BIG Hochleistungslüfter BIG High Performance Fan HP 18-H200-B1 / HP 18-ES2,2-B1 / HP 18-EV2,2-B1...
  • Page 16 EST. 1991 INNOVATION MADE IN GERMANY B.S. BELÜFTUNGS GMBH 89429 Bachhagel, Germany Vimpex LTD Vimpex Interguard AB Tel. +49 (0)9077 95776-0 big-fire.de Star Lane, Great Wakering, +46 (0) 36 37 10 65 info@big-fire.info MANAGEMENT Essex SS3 0PJ, UK sales@vimpex.se SYSTEMS +44 (0) 1702 216999 Quality System Certificate No.
