SUMMARY
01 SUMMARY
The backup box is a product of AlphaESS for switching on and off the grid.
1.1. Parts List
Check the following parts list to ensure the package is complete.
A complete backup box system consists of:
Name
1 transfer 3 cable (for
L
SMILE5/SMILE-B3)
1 transfer 2
communication
connector
Meter patch cable
for backup box
Installation manual
Terminal
Cylindrical fuse
Fuse holder
Note: 1. Meter patch cable for backup box is different from backup patch cable for
backup box. Meter patch cable for backup box must be connected in the correct
place as the diagram shows.
2. We will install the cylindrical fuse in the fuse holder before shippment. Please
install the fuse part when installing the Backup Box.
Alpha ESS Suzhou Co., Ltd.
+86 512 6828 7609
info@alpha-ess.com
www.alpha-ess.com
Level 15,SIPC 158 Wangdun Road SIP Suzhou,
215028
Alpha ESS Italy S.r.l.
+39 599 239 50
info@alpha-ess.it
www.alpha-ess.it
Via Loda,17-41013 Castelfranco Emilia(MO)
Alpha ESS Korea Co., Ltd
+82 64 721 2004
korea@alpha-ess.com
2F, 19-4, Nohyeong 11-gil, Jeju-si, Jeju-do,
Republic of Korea
Illustration Quantity
GRID_L1
GRID_L2
GRID_L3
QUICK INSTALLATION MANUAL
INSTALLATIONMANUAL
ENERGYSTORAGESYSTEM(ESS) BACKUP BOX
STORION-SMILE-T10(INDOOR)
V02
01 02
1.2 Terminal Diagram
1
2
1
1.3 Technical Specification
Datasheet:
Phase
1
Display
Communication
Operating Temperature Range
25
Humidity
Protection Level
3
Dimension (W x D x H)
Warranty
Nominal Output Power
1 Grid Frequency
Nominal Current
LED Status Indication
LED Display
PF
QF
Fault
ON
COM
OFF
Figure 1: backup box Terminal Diagram
Single Phase / Three Phase
LCD
RS-485
-20 ºC ~ 60 ºC
15% ~ 85%
IP20
208mm x 67mm x 127 mm
5 Years
20 kW
50/60 Hz
30 A *3
Description
Active Power
Reactive Power
Communication Lost/Relay
SUMMARY
