MOC 901D User Manual

UNIVERSAL
TRAVEL ADAPTER
Model 901D/901A – User Manual – En

OVERVIEW

1 Fuse reset button
2 USA/AUS/UK plugs
3 LED indicator
4 USB-C port (PD & QC)
5 USB-A port
6 Universal AC output
7 EU plug

SPECIFICATIONS

Model:
Rated voltage:
AC Input:
Color:
Pin type:
AC Output:
USB-C PD;
USB-C QC:
USB-A:
Total DC Output: 30W.
Fuse
Dimentions:
Op. temp:

CHOOSE A SUITABLE PLUG

1. Using USA/AUS/UK plug
Press down on the control
for the desired connector
and then slide it forward.
Plug it in to a power outlet.
2. Using EU plug without resettable fuse
Unplug the EU plus from the adapter
and plug it in to a power outlet.
3. Using EU plug with resettable fuse
Insert the EU plug into
the USA/AUS/UK plug
(as a combination) and
then plug in to a power
outlet.

USING THE ADAPTER

1. Charge your device from USB-C
port (901D only)
Connect your devices to the
USB-C port on the adapter
using a USB-C cable.
2. Charge your device
from USB-A ports
Connect your devices to the USB-A port on the
adapter using a USB-A charge/sync cable.
3. Charge your device with AC outlet
Connect your devices to the universal
AC outlet with its built-in plug.
RESETTING
THE FUSE
When an overload occures, push the fuse reset
button on the adapter to regain power.

PLEASE NOTE

Always disconnect the adapter from the outlet when
it's not in use.
THIS PRODUCT IS NOT A VOLTAGE CONVERTER!
Use this adapter vith devices rated 100-250 volts only.

APPLICABLE OUTLETS

1. Adapter can accept type A, B, C, E, F, G, I, J, L, N plugs.
2. Adapter can plug into B, D, E, F, G, H, I, K, O outlets.
901D
110-250 VAC
100-250V1AC
50-60Hz
White
EU/USA/AUS/UK
10A Max.
(1000W/100V or
2500W/250V).
5V/3A,9V/2A,
12V/1.5A
3.6-6V/3A,
6-9V'2A.9-12V1.5A.
5V/2.4A (total).
10A.
68 x 49 x 66 mm
0°C to 35°C.
Imported by MOC Sport AB.
All Rights Reserved.
All trademarks registered.
Internationally protected design.
Limited warranty.
MADE IN CHINA.
901A
110-250 VAC
100-250V1AC
50-60Hz
White
EU/USA/AUS/UK
10A Max.
(1000W/100V or
2500W/250V).
–
–
2x 5V/2.4A Max.
12W.
3A.
