Summary of Contents for MTS Systems D808 PRO
- Page 1 User manual 808nm Diode Laser Hair Removal Machine D808 PRO...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction 2. Security 3. System Installation 4. Machine operation 5. Treatment considerations 6. Maintenance 7. Technical description 8. Environmental protection... - Page 3 Limited liability guarantee The company guarantees free repairs for products lacking workmanship during the warranty period. During the warranty period, the company or its authorized personnel will be responsible for maintenance and replacement of any products found to be defective after inspection. The warranty does not cover the following：...
- Page 4 2. Read the chapters under the logo such as before operating the machine. 3. Harmful radiation may be produced if it is not used or adjusted according to the instructions. 4. Guidance and manufacturer's declaration: electromagnetic radiation and resistance to electromagnetic interference. 808 Diode Laser Hair Removal System User Manual Ⅰ.Introduction Equipment description...
-
Page 5: Security
D. Scope of application: Hair removal: armpits, limbs, back chest, bikini line, face, upper lip and chin; Skin rejuvenation: Reducing pores, whitening skin Technical Parameters Laser type: Diode laser power: 600w Wavelength：808nm 1064nm 755nm Spot Site（mm）: 12mmx12mm ... - Page 6 3. Understand the accident report 4. Understand the biological response of laser injury ● When the machine is not in use, it must be powered off. Remove the key after the operation is completed, and keep the key properly, and prohibit non-operators from using the machine.
- Page 7 laser exit of the hand tool directly at the treatment site. Electrical and mechanical safety Please turn off the equipment and disconnect the power when performing maintenance. It is best not to move frequently. This equipment is connected to the ground through the ground wire in the power cord.
- Page 8 understanding of the patient’s medical history before treatment. And sign a treatment agreement with the patient, telling them the possible results and dangers during the treatment process. Fire Safety The absorption of light energy will increase the temperature of the absorbing substance.
- Page 9 A、Emergency Switch E、Water injection hole B、Key Switch F、Power Switch C、Handle G、Power line interface D、Handle hanger H、Overflow hole I、Drain hole...
- Page 10 Follow the steps below to complete the installation： Unpack the device Check the equipment and all accessories for damage First install the handle hanger, then install the handle, and then add water Turn off the nut of Water injection hole, insert the water funnel into the Water injection hole and add distilled water or pure water (it is recommended to add frozen water in summer), if it is added to the overflow, there is water overflow, indicating that the water tank is full...
-
Page 11: Machine Operation
maintained between 20°C -25°C (68°F-77°F), the corresponding humidity is not less than 80% Do not store equipment with water below 2°C (35°F) Device movement Turn off the device before moving, pull out the key and power cord If the moving distance is far, please drain all the water in the equipment ... - Page 12 part Connect the power line Turn on the power switch Turn on the emergency stop switch Use the key to turn on the instrument Operation interface Selection Skin selection interface: six kinds of skin selection...
- Page 13 Extension button： hair color selection：...
- Page 14 working interface Cooling level : Cooling regulation （1-4）...
- Page 15 Click the Cooling level button to display: select the cooling intensity level Current: Energy output regulation（10-50） Frequence: Frequency adjustment (number of light emission per second)（1Hz-10Hz） 1Hz: Pulse width range is（10ms-500ms） 2Hz: Pulse width range is（10ms-250ms） 3Hz: Pulse width range is（10-160ms） ...
-
Page 16: Treatment Considerations
Flow: Water flow detection Temperature：Temperature detection Working and pause selection button READY: Ready to work STANDBY：Pause to work Appears when the READY button is pressed Appears when the STANDBY button is pressed When pressing the READY button, press the handle switch to start shot ... - Page 17 Contraindications： The following symptoms cannot be treated with laser： Malignant or diseased pigment; Light sensitive skin; Pregnant Use of non-coagulating drugs; Scar constitution; Bacterial infectious diseases; Defects in the immune system; scleroderma; diabetes; Other diseases that cannot be used for laser treatment Preparation before treatment：...
- Page 18 wear protective glasses。 Do not wear reflective accessories such as watches, necklaces, bracelets, etc. There should be warning signs in the treatment room and no entry Treatment parameters Choosing the right treatment parameters is very necessary for successful treatment. The optimal pulse width allows effective thermotherapy with minimal skin damage.
-
Page 19: Maintenance
After treatment, it is recommended to apply cold compress to the treatment area but not ice. It is best not to expose the skin to sunlight for two weeks after treatment. The skin may become red or erythema after treatment, but these symptoms will disappear within six months. -
Page 20: Technical Description
4.When disinfecting the machine, you can use 70% medical alcohol or related disinfection methods. 5.Clean the light emitting port on the front of the handle after each operation Ⅶ、Technical Description Label Laser treatment instrument Electric shock protection：Class I, Type B ... - Page 21 808 hair removal instrument is the use of laser photopyrolysis, through reasonable adjustment of laser wavelength, energy and pulse width so that light energy can pass through the skin surface to reach the root hair follicle of the hair, which is absorbed and converted into heat energy that damages the hair follicle tissue.
- Page 22 enter the dermis and be absorbed by the melanin particles in the hair and hair follicles, generating a photothermal effect, completely destroying the hair follicles and hair shafts, resulting in permanent hair removal; 5. Hair removal and skin beauty serve two purposes: aggregate all the advantages of traditional freezing point hair removal, powerful SPA function, not only hair removal but also skin rejuvenation and whitening, firming the skin.
- Page 23 （1）Fit the skin to avoid light leakage, and slowly slide the handle probe to operate （2）Energy adjustment: start from the default energy of the system. If the operator feels that the heat is too large, reduce the energy; if there is a slight thermal expansion, it means that the melanin is absorbed by the laser with a wavelength of 808nm, and the light energy is converted into heat energy.
- Page 24 3. When sliding during treatment, appropriate pressure should be applied to the laser handle to keep the handle in good contact with the skin. It can also drive local blood and reduce oxyhemoglobin absorption of laser energy. 4. When the frequency is high, the speed control is in place and cannot be stopped 5.
- Page 25 2. Avoid eating spicy, tobacco, alcohol, and stimulating food 3. Avoid exposure to the sun, do a good job of sun protection, wipe the sunscreen, isolation cream 4. Avoid hair hanging manually after hair removal. Do a good job of hair removal Ⅶ、Taboo crowd 1.
- Page 26 Growth period: 2-6 years (70%-85%) Degeneration period: March-April (15%-25%) Rest period: 2-4 weeks (5%-10%) 5.Reaction after laser hair removal Immediate reaction: the skin has obvious heat sensation, and it is best to be slightly warm; a few parts will have redness and edema. Late reaction: the hair protrudes from the hair follicle, the longer the hair color, the lighter, the longer the speed, the slower, the longer the thinner 6.Treatment effect: Hair growth is stable after 6 months, and no longer...
