Quick start configuration guide for SARK and Sangoma Vega 50 FXO Gateway
Before You Begin:
The SARK PBX and Vega 50 appliance is connected to the network and all IP
•
addresses are configured as needed. If not then please consult links below for
SARK and Vega 50.
SARK PBX Quick Start Guide
Vega 50 Quick Start Guide
You are able to connect to the Web interface of both SARK PBX and Vega 50.
•
SARK PBX Configuration
Open a browser and enter IP address of Sark PBX. On prompt enter the following details.
SARK 200 / SARK 500
User Name : admin (lower case)
Password
: sarkadmin (lower case)
SARK 850/1000/1200
User Name : admin (lower case)
Password
: Aster2sk!
SARK 200 Mini PBX
Sangoma Vega Gateways

Advertisement

loading

Related Manuals for SARK 200

Summary of Contents for SARK 200

  • Page 1 SARK and Vega 50. SARK PBX Quick Start Guide Vega 50 Quick Start Guide You are able to connect to the Web interface of both SARK PBX and Vega 50. • SARK PBX Configuration Open a browser and enter IP address of Sark PBX. On prompt enter the following details.
  • Page 2 Leave everything else as default and press save and then the commit button. Step 2 : Next step is to create an inbound route for calls coming from Vega gateway to Sark. This is where you define the numbers assigned to you by Fixed line provider generally BT/Virgin Media for UK.
  • Page 3 To add a DID click on new object icon and select DID from Carrier drop down menu. Now enter a name for the incoming line. Enter the DID(geographic) number associated with PSTN line and press save and then the commit button. Finally add any extra DID`s for additional lines and press commit button to save and apply settings.
  • Page 4 You can change the route name to anything you like. For Path1 you will need to select the name of your Trunk discussed in step 1, in this case it is “Vega50”, then leave the rest of the settings as default. Vega 50 4-8 Port FXO Configuration Open a browser and enter IP address of Vega 50.
  • Page 5 Step 6: VoIP Next go to VoIP section and enter the IP address of SARK as SIP domain and SIP server IP/Name. Make sure registration mode is turn off and change codec 1 priory to G711Alaw64k or as shown below.
  • Page 6 Sark in step 2. Finally select the New Install ? Check box and press the Submit button. Wait couple of seconds and press the Reboot system button when it appears. Now you should be able to make/receive calls from and to Vega/SARK PBX.
