STEP-BY-STEP INSTALLATION
1.
PRE-LIGHT PRODUCT
Pre-light ribbon to ensure the color is correct.
2.
TURN POWER OFF AT CIRCUIT BREAKER
SHOCK HAZARD! May result in serious injury or death.
Turn power OFF at circuit breaker prior to installation.
3.
DETERMINE LOCATION TO INSTALL
Dry-fit the lights to the desired location BEFORE
removing the adhesive backing. Refer to your
configuration diagram for a list of products and zone
locations when applicable.
Group Name
# of runs
Item Code
Run # 1---24'
2
NF-DS-O-128-24V-3000K
Run # 1---24'
NF-PS-96W-24V-0/10V
Run # 1---24'
NF-CH-1612-2M
Run # 1---24'
NF-CH-1612-C/SOFT-2M
Run # 2---24'
2
NF-DS-O-128-24V-3000K
Run # 2---24'
NF-PS-96W-24V-0/10V
Run # 2---24'
NF-CH-1612-2M
Run # 2---24'
NF-CH-1612-C/SOFT-2M
Run # 3---17' with one
NF-PS-96W-24V-0/10V
90 degree bend
Run # 4---15'
1
NF-DS-O-128-24V-3000K
Also dry-fit channel to the location if you are using.
Run # 4---15'
NF-PS-96W-24V-0/10V
Run # 4---15'
NF-CH-1612-2M
Run # 4---15'
NF-CH-1612-C/SOFT-2M
4.
INSTALL CHANNEL (OPTIONAL)
Run # 4---15'
NF-CATALOG (1 pc)
This order was customized by Nova Flex to save you an estimated install time of : 0hr and 45minutes
OPTION 1:
Installation guides can be found at www.novaflexled.com/resources/
Install channel clips to the wall with screws. (Clips
We appreciate your business!
should be mounted at the beginning and end of each
section of channel and at 1/3 and 2/3 the length of each
channel section.
Example: 78" section of channel
clips mounted to wall at start, 26", 52" and the
Do not attempt to make sharp bends. Excessive or
exaggerated bending and twisting should be avoided. This
stress can split the PU coating and damage the circuit.
NOTE: IP65 is water resistant & IP68 is protected against
water; power supply is NOT.
Configuration Guide
Description
Nova Flex Design Series IP65 128 24 Volt
3000K
120in HW Lead + 143in LED
96 Watt 24 Volt 0/10V Dimming UL Listed
Power Supply with JBox - 120-277V
Surface 1612 Track - 2 Meter Section
Soft Cover for Surface 1612 Track- 2 Meter
Section
Nova Flex Design Series IP65 128 24 Volt
3000K
120in HW Lead + 143in LED
96 Watt 24 Volt 0/10V Dimming UL Listed
Power Supply with JBox - 120-277V
Surface 1612 Track - 2 Meter Section
Soft Cover for Surface 1612 Track- 2 Meter
Section
96 Watt 24 Volt 0/10V Dimming UL Listed
Power Supply with JBox - 120-277V
Nova Flex Design Series IP65 128 24 Volt
3000K
120in HW Lead + 180in LED
96 Watt 24 Volt 0/10V Dimming UL Listed
Power Supply with JBox - 120-277V
Surface 1612 Track - 2 Meter Section
Soft Cover for Surface 1612 Track- 2 Meter
Section
Nova Flex Catalog (1 pc)
end at 78".
OPTION 2:
Install channel directly to the wall with screws. Place
screws at the begining and end of each section of
channel and at 1/3 and 2/3 the length of each channel
section.
5.
PREPARE SURFACE FOR LEDs
Wipe down surface to remove any dust particles to
ensure a proper installation. For slippery surfaces, pre-
sand the area before installing the lights or use Primer
94 from 3M to prime the surface.
6.
REMOVE ADHESIVE BACKING
Once fit is confirmed, remove 3M adhesive backing
and install to your desired location. Adhesive MUST BE
REMOVED for proper heat dissipation.
Qty.
U/M
24
ft.
1
each
4
each
4
each
24
ft.
1
each
4
each
7.
INSTALL RIBBON
4
each
1
each
Install ribbon to your desired location and use the
15
ft.
wiring diagram, on the back, as a guide to connect. Do
1
each
3
each
NOT mount with components or board touching any
3
each
flammable surfaces. Do NOT press on LEDs or connect
1
max runs.
8.
TURN POWER ON AT CIRCUIT BREAKER
Once your ribbon is connect using the diagrams on the
back, turn the power on at the circuit breaker.
