Summary of Contents for Mhdt Labs Atlantis

  • Page 1 Instructions and Manual Rev 1.0 NTIS Realistic yet Natural Sounding DAC Mhdt Labs Audio Products...
  • Page 2: Important Safety Instructions

    Thank you for purchasing the Mhdt Labs’ Atlantis DAC. Please take a few moments to read over this instruction manual to get the most out of your unit. The manual describes how to operate the Mhdt Labs’ Atlantis DAC and provides some technical background information.
  • Page 3 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC  Unplug the unit from the mains supply before cleaning. The case should normally only be cleaned with a dry, soft, non-fluffy cloth. Do not spray any liquid cleaner onto the cabinet, as this may lead to dangerous shocks.
  • Page 4: Connections And Operation

    Atlantis DAC is capable of up to 24bits/192kHz digital signal inputs yet remains driving legendary AD1862 R-2R digital to analog output. Atlantis DAC is a non over-sampling, no digital filter, no op-amp, no feedback structured DAC. This tends to produce most realistic and natural sound.
  • Page 5 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC When any of digital inputs is selected, this input is stored after selection, and will remain the last selection after disconnection from mains power. 2.2 Rear Panel Connections 1 Right Channel Analog Output – Connect to Pre-Amplifier or Receiver’s line input 2 Left Channel Analog Output –...
  • Page 6: Technical Specifications

    Realistic yet Natural Sounding DAC 2.3 Powering up Before applying power to the Atlantis DAC, ensure that the correct mains voltage is used. This can be either 220-240VAC or 100-120 VAC (50/60Hz). The factory preset voltage is indicated on the rear panel.
  • Page 7: Warranty

    No driver installation is needed if using w/ Mac and Linux OS, just plug and play USB2.0 driver installation on Windows OS To support 176.4kHz and 192 kHz formats, the Atlantis DAC is operated in USB2.0 full speed condition. Thus, you have to install USB2.0 driver before use USB input.
  • Page 8 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC The use and setup of USB2.0 can be referred to our USBridge user manual located in: http://dhost.info/mhdtlab/Usbdriver.htm, Let’s take W7 (32/64) as example: Installed driver version: CM6631_6631A-1.01(CR) After drivers installed, please check control panel to see if the drivers is properly installed.
  • Page 9 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC Test if the supported formats sounded normally., Rev 1 Jul, 2015...
  • Page 10 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC Note: If you want to install different version of drivers, please uninstall previous drivers before install new driver. The uninstall is operated in control panel like following: Rev 1 Jul, 2015...
  • Page 11 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC After driver is installed properly, you may try to run media agent to play the USB2.0 audio. The Stockholm USB2.0 input supports: 16, 24 bits 44.1 kHz, 48 kHz, 88.2kHz, 96kHz, 176.4kHz and 192 kHz formats and can handle Direct Sound (DS),...
  • Page 12 Foobar and restart Foobar. Then, you are ready to use ASIO. 6. Tube, Fuse Replacement The vacuum tube installed in Atlantis DAC is GE JAN 5670W. The reason we choose 5670W is that this tube is very reliable, durable, good sounding and easy to find in nowadays’...
  • Page 13: Troubleshooting

    In case there is no audio coming out of your system, there are a few things to check:  Atlantis DAC accepts USB audio signal via USB port. Be sure the input is USB audio signal.  Atlantis DAC accepts only SPDIF (PCM) format digital signal for the rest of inputs;...
  • Page 14 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC If none of these suggestions cure the problem, please do not hesitate to contact Latest version of firmware/driver can be downloaded from our website: http://dhost.info/mhdtlab/ Rev 1 Jul, 2015...
  • Page 15 ATLANTIS Mhdt Laboratory Taipei, Taiwan http://dhost.info/mhdtlab/ Realistic yet Natural Sounding DAC Mhdt Labs DAC Families Havana Havana 2 Stockholm 2 Atlantis Atlantis Steeplechase Input Capacity USB (Max) 16bits/48kHz 24bits/192kHz 24bits/192kHz 24bits/192kHz 24bits/192kHz 24bits/192kHz Input Capacity SPDIF (Max) 24bits/96kHz 24bits/192kHz 24bits/192kHz...
