Summary of Contents for DIADEM DiaSafe Single
- Page 1 TECHNICAL MANUAL ® DiaSafe Single ® DiaSafe Line Multi ® DiaSafe Glide Fall Protection Anchoring Systems Pemanently secured anchor devices as per standards EN 795:2012 and CEN/TS 16415:2013 www.diadem.com 100554-01 valid from: 01.04.2020...
-
Page 2: Table Of Contents
Table of contents Description of symbols Introduction – General description Single anchoring points ® 2.1.1 DiaSafe Single Line wire-rope system ® 2.2.1 DiaSafe Line Multi ® 2.2.2 DiaSafe Glide ® 2.2.3 Possibility of combinations with RoofX systems Safety instructions General safety instructions Application Manufacturer’s responsibility, warranty General terms of warranty... -
Page 3: Description Of Symbols
Description of symbols Pictograms in the Technical Manual have the following meanings: System users are obliged to carefully read this manual and the related service book, and shall closely follow all relevant safety regulations and user requirements listed herein. Utilization modes of the safety system based on the number of persons using the system simultaneously: (1+1 persons are considered as standard case.) SOLO System: In case of use by 1+1 persons, the system can be used even by two persons simultaneously, but the fall arresting function can be... -
Page 4: Introduction - General Description
Introduction – General description Single anchoring points ® 2.1.1 DiaSafe Single ® The DiaSafe Single was developed as a safety technical system working as a single anchoring point based on the standards EN 795:2012 (Type A) and CEN/TS 16415:2013, for the simultaneous catch of 2 persons, in case of max. -
Page 5: Safety Instructions
Safety instructions General safety instructions The safety system may only be installed and used by appropriately trained, competent persons who are familiar with the safety system in accordance with this Techincal Manual and the Installation Guide. The system user must be familiar and comply with the local, and labour safety regulations. ... -
Page 6: Application
The DiaSafe ® fall protection anchoring system may be installed and used only according to the manufacturer’s guidelines in the Technical Manual. If the system has fulfilled its fall arrest function, following a fall, the system must be immediately withdrawn from use. -
Page 7: Manufacturer's Responsibility, Warranty
Particular attention has been paid to producing these instructions. However it is not possible to show ® all the potential versions and these instructions do not therefore claim to be exhaustive. DIADEM APP GmbH shall not be liable for any usage or application error, which may arise from the misinterpretation of the methods shown here. -
Page 8: Expected Lifetime
Damage caused by the user’s physical condition or health (with special regard to the weight limit: 130kg/person) and thus improper use. Damage caused by the owner/maintainer’s failure to adequately maintain, service or repair any part of the system. ... -
Page 9: System Design, Components
System design, components ® DiaSafe Single anchoring points ® 5.1.1 DiaSafe Single Post structure: DS Single anchor post + DS amoeba-shaped damping plate with ballasting mat (3x3 m) Properties: no need to break through the layering sequence of the roof insulation to perform the installation Load direction: 360°... -
Page 10: Diasafe ® Glide Wire-Rope System
® DiaSafe Glide wire-rope system ® 5.2.1 DiaSafe Glide Post structure: DS Glide anchor post + DS amoeba-shaped damping plate with ballasting mat (3x3 m) Properties: no need to break through the layering sequence of the roof to perform the installation Load direction: 360°... - Page 11 DS Swaged square end Product No.: 100354 Material: Stainless steel 1.4404 DS DiaGlider-Fix (without carabiner) Product No.: 100471 Material: Stainless steel Application: Placed on the wire, not detachable, it can be used by max. 2 people simultaneously. DS Wire-rope terminating shrinkable tube Product No.: 090845 Size: Ø...
-
Page 12: Diasafe ® Line Multi Wire-Rope System
® DiaSafe Line Multi wire-rope system ® 5.3.1 DiaSafe Line Multi Post structure: DS Multi anchor post + DS amoeba-shaped damping plate with ballasting mat (3x3 m) Properties: no need to break through the layering sequence of the roof to perform the installation Load direction: 360°... -
Page 13: Recommended Carabiner To Connect To The System
DS Wire-rope terminating shrinkable tube Product No.: 090845 Size: Ø 9 mm DS Multi rectangular anchoring ring Product number: 100317 Material: Stainless steel 1.4404 Size: 57.5 mm x 87.5 mm Material thickness: Ø 8 mm DS Cable Thimble Product number: 100279 Material: Stainless steel 1.4404 Size: 58 x 38 mm DS Multi-turn buckle... -
Page 14: Load Bearing Structure And Ballast Layer
Load bearing structure and ballast layer Load bearing structure ® DiaSafe systems were tested and examined on a number of surface types and structures (roofs with steel, reinforced concrete and wooden structure). Their performance is controlled on the most prevailing waterproofing materials (bituminous, PVC, TPO or EPDM) and roof panes. The system is applicable on any roof system which is able to bear the extra load originating from the installation and use of the system. - Page 15 Standard mat sizes belonging to the anchor points is 9 m (3×3 m) and optionally 25 m (5×5 m), respectively. The specified minimum ballast layer thickness of minimum 3 cm shall always be ensured. When applying custom mat sizes, the minimum ballast surface weight shall be determined according to the Technical Manual to which assistance is provided by the table series below: Solo –...
-
Page 16: Installation Of The System In The Case Of Ballast Materials With Various Layer Thicknesses
point, and special attention shall be paid to the existence of the appropriate ballast weight. It is prohibited to cut or damage the glass-fibre reinforced plastic in any way. Warning! Because the thickness of the ballast layer may change by time (people walk on it, it is eroded by wind or rain etc.), the actual layer thickness must be controlled before each use by visual inspection at least. -
Page 17: Information On System Installation And Usage
Information on system installation and usage The system guarantees full-scale safety for the user, regardless of the sag of the wire. Sag of the wire may change during the lifetime of the system, e.g. due to the mounting actions, ® thermal expansion or other dynamic effects. -
Page 18: Documentation
The manufacturer provides documentation for each DiaSafe system attached and in digital, ® downloadable form. The installed falling arrest system can be registered on the DIADEM Online registration interface. The Service Manual is prepared during registration. Parts of the documentation: ... -
Page 19: Installation
Installation 11.1 Presses usable for pressing ® The DiaSafe anchoring systems were tested and approved by pressings produced by REMS radial presses. The following models are suitable for pressing: REMS Power-Press REMS Power-Press SE REMS Power-Press ACC REMS Akku-Press REMS Akku-Press ACC These machines exert 36 kN pressing force which finally results in 100 kN force. -
Page 20: Manufacturer, Certification
TÜV Austria Services GmbH. Copyright: ® ® ® DIADEM , DiaSafe and RoofX are registered trademarks! This technical manual is the intellectual property of the manufacturer, the use of its content in any form for business purpose, without the previous authorization of the manufacturer is strictly forbidden.
