VoIPon 2ENTRY Helios 9135511E Quick Manual

2ENTRY Helios – VANDAL RESISTANT accessories
Order no. 9135511E
Vandal resistant mask for
basic module
+ vandal resistant flush fitting box

Spare parts (to order):

Masks: 9135510E
9135510KE
9135514E
Boxes: 9135353E
Warning:
∗
Boxes are not to be bricked up
∗
A hood
for the vandal resistant design is not included in the offer because it is very expensive to manufacture a hood
with the same resistant properties as the panel. Location of the vandal resistant panel in an external environment is
permitted without a hood. Because the climatic conditions in various countries could differ to a significant extent, the
manufacturer cannot understandably guarantee the perfect functioning of the equipment under all circumstances (for
example under a layer of frost). In such an extreme case, a suitable individual solution must be found – for example a
recess, heating, closed boxing or similar.

Mounting instructions

Mounting the boxing into the wall:

Prepare a hole with the dimensions 215 – 220 mm (height) x 105 – 110 mm
(for one module) or in accordance with table below (for multiple modules).
WARNING!!! The boxing is designed for dry mounting. The dimensions of
the hole must be adhered to in order for all corners of the boxing to be flush
with the façade - the boxing must not sink into the hole. This ensures the
precise recessing depth of the boxing into the wall, which is necessary for
the correct functioning of the product!!!
Number of
Only for
installation
of multiple
hole width
modules:
Before connecting boxes
together, remove small side
holes for cables passing
through.
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
Order no. 9135511KE
Vandal resistant mask for
basic module with keypad
+ vandal resistant flush fitting box
vandal resistant mask for 1 basic module
vandal resistant mask for 1 basic module with keypad
vandal resistant mask for 1 extension module
vandal resistant flush fitting box for 1 module
– they are designed for dry mounting.
2
modules
239 to
244 mm
Connect boxes together jumpers
and screws before wall flush
mounting. Jumpers are from the
bottom and screws from the top.
3 4 5
372 to 506 to 639 to
377 mm 511mm 644 mm
First box from the left is designated for
base module. To the bottom strap stick
on the metal washer provided in the
package.
Order no. 9135515E
Vandal resistant mask for
one extension module
+ vandal resistant flush fitting box
6 7
773 to 906 to 1040 to
778 mm 911 mm 1045 mm
8
