- Page 1 USER's MANUAL/INSTALLATION NOTE Wind Sensor Static, WSS 500 series • Mounting • Connecting • Replacing an old sensor • References Document no.: 4189350072B...
-
Page 2: Table Of Contents
WSS 500 Series User’s Manual/Installation Note Table of contents INTRODUCTION ................3 ..................4 NPACKING ........4 EGAL INFORMATION AND RESPONSIBILITY MOUNTING THE WIND SENSOR ..........5 ............5 LACING OF THE WIND SENSOR ............... 7 IRD AVOIDANCE KIT CABLE CONNECTIONS ............. 9 WSS 500 .... -
Page 3: Introduction
WSDI-2 wind display to form a complete wind system. The WSS 500 series can also be used as wind sensor for previous DEIF wind displays, such as WSDI and 879, in which case it must be connected via an interface box. -
Page 4: Unpacking
User’s Manual/Installation Note Unpacking The WSS 500 series sensor is delivered in a cardboard box. Inside this box, the sensor is packed in a white foam box (called a protection cap), which is supposed to stay on, until the sensor is mounted in the mast. -
Page 5: Mounting The Wind Sensor
WSS 500 Series User’s Manual/Installation Note 2. Mounting the wind sensor Placing of the wind sensor Ideally, the wind sensor should be placed far from large objects that might influence the measuring results; however, in practice this is normally not possible on-board a ship. The best result is achieved by placing the wind sensor at the top of a mast in the opposite end of the superstructure. - Page 6 WSS 500 Series User’s Manual/Installation Note Mount the WSS Remove the protective cap To ensure that the display represents the precise wind direction relative to the ship, the wind sensor must be aligned correctly. That is, when mounting the wind sensor, the arrow on...
-
Page 7: Bird Avoidance Kit
The black rubber heads are known to attract some birds’ attention because of the click-sound they give off. The bird avoidance kit is mounted as standard on the WSS 500 series and can be purchased as an optional extra to mount on previous WSS versions. - Page 8 WSS 500 Series User’s Manual/Installation Note 3. Check that the kit sits tightly on the WSS 500 series sensor. ¾” pipe thread: Outer diameter: 1.04 inch (26.4 mm), 14 threads per inch IMPORTANT! The stainless steel mounting base on the WSS 500 series sensor must be connected to earth (for example the steel hull).
-
Page 9: Cable Connections
If the instrument is installed in a metal panel, this panel has to be carefully earthed, as well as the instrument itself. Suitable extension cable is available from DEIF. Alternatively, an installation cable, for example UL2464 18AWG4C + AE, 4 × 0.75 mm screened, can be used. -
Page 10: Connecting Awss 500 Series Sensor To An Xd I -Nindicator
WSS 500 Series User’s Manual/Installation Note Connecting a WSS 500 series sensor to an XDi-N indicator WSS 500 Terminal number Description series XDi-N NX2 module cable colour Black (-) 5. 0 V Aux. voltage: 0 V Red (+) 4. +24 V Aux. - Page 11 WSS 500 Series User’s Manual/Installation Note Set up NMEA input to show wind data The initial setup of XDi-N is easily performed with the wizard; you will be guided through the setup of NMEA with automatic scan of NMEA sentence. Setup of the needed NMEA data is described below.
-
Page 12: Connecting Awss Or Wss-Lto Awsdi-2 Display
WSS 500 Series User’s Manual/Installation Note Connecting a WSS or WSS-L to a WSDI-2 display WSS/WSS-L WSDI-2 Wind sensor Display WSDI- Description Comments WSS/WSS-L 2 Terminal Cable colour no.: Black (-) 1. 0 V Aux. voltage: Aux. voltage to WSDI-2 and WSS is parallel-coupled in 2. -
Page 13: Ip67 Connector Kit Assembly (Optional)
WSS 500 Series User’s Manual/Installation Note Connection of other equipment One standard NMEA0183 input for a VDR or integrated navigation system can be connected to terminal A and B. It is recommended to use an NMEA-buffer or NCI-1 if more than one NMEA input has to be connected. - Page 14 WSS 500 Series User’s Manual/Installation Note Measures are in mm. DEIF A/S Page 14 of 25...
-
Page 15: Dimensions
WSS 500 Series User’s Manual/Installation Note 4. Dimensions ¾” pipe thread: Outer diameter: 1.04 inch (26.4 mm), 14 threads per inch. DEIF A/S Page 15 of 25... -
Page 16: Troubleshooting A Wss 500 Series/Xdi-N Installation
WSS 500 Series User’s Manual/Installation Note Troubleshooting a WSS 500 series/XDi-N installation Flashing data and symbols on the XDi-N indicate that data is missing. Using the XDi-N NMEA monitor makes it easy to see the NMEA data received on the COM ports of the NX2 module. -
Page 17: Xdi-N Nmea Monitor
WSS 500 Series User’s Manual/Installation Note Yellow pop-up box in The NMEA sentence MWD has been activated in the upper left corner with system and is also shown in the NMEA monitor, cabling is text message correct, but geographic true wind symbol and data are still “CAN Data lost!”... -
Page 18: Troubleshooting Awss/Wsdi-2 Installation
Aux. voltage is not available (18 to 31 V DC), or the WSDI- backlight or display 2 is damaged. Orange Error LED is The WSDI-2 is defective, contact DEIF or a sales/service flashing representative. Wind speed is “----“ Cause: There is no valid wind data via RS-485 from the and direction is not wind sensor. - Page 19 WSS 500 Series User’s Manual/Installation Note Wind direction is Check that the sensor is aligned correctly. The arrow at the wrong bottom must point ahead and be parallel with the ship’s centre line (see chapter 2). No data on the NMEA There must be correct wind data on the WSDI display.
-
Page 20: Replacement Of An Old Wind Sensor
879.50/879.521 or WSDI The special upgrade kit should be used when an existing 879.3c dynamic wind sensor is to be replaced with a new WSS 500 series sensor and connected to a display type 879.50/879.521 or WSDI. The interface box type WSI is needed to translate the RS-485 data signal from the WSS 500 series into a speed and direction TTL signal appropriate for the 879.50/879.521 or WSDI display. - Page 21 *) The screen should only be connected to WSDI-2 terminal 8 in case of problems with electrical noise. IMPORTANT! The stainless steel mounting base of the WSS 500 series sensor must be connected to earth (for example the steel hull).
- Page 22 WSS 500 Series User’s Manual/Installation Note WSI interface box dimensions: 99.7 85.0 110.0 Before the replacement is carried out, it is recommended to carefully read the User's Manual/Installation Note (this document). DEIF A/S Page 22 of 25...
- Page 23 WSS 500 Series User’s Manual/Installation Note 2 meters of cable - part of WSS Use: Connection 9 7 5 4 6 IP66 Connection box option or IP67 Connector kit option 4 x 0.75mm² cable lenght max. 300m D = wind Direction...
-
Page 24: Troubleshooting An Installation Upgrade
2 or 3 happens only when The aux. supply is not able to supply enough current to drive outdoor temperature is the WSS 500 series heater. (24 V DC power supply >2 A is below 5 °C recommended). Direction LED jumps 0- The connection from WSI to WSDI is most likely OK. -
Page 25: References
For more details, see the following documents: WSDI-2 User’s Manual/Installation Note, document no. 4189350032. WSS 500 series appendix to user’s manual, document no. 4189350076. Documentation is available on www.deif.com. DEIF A/S reserves the right to change any of the above. DEIF A/S Page 25 of 25...
