1. Parameters

Parameter
Interaction
Vibration motor
Charging and
battery life
IP rating
Bluetooth and
sensor
Mi Smart Band 5
Item
Screen size
Screen type
Screen resolution
Screen color quantity
Screen backlight
Cover plate material
Strap type
Strap dimensions
Weight
Force sensing button
Interaction mode
Vibration motor
Charging method
Battery capacity
Battery type
Charging duration
Battery life
Waterproofing
Sensor
Bluetooth
Mi Smart Band 5
Color AMOLED
126x294
16bit RGB
Maximum (adjustable) brightness >= 450 nit
2.5D reinforced glass+AF coating film
Detachable strap, made from thermoplastic
elastomer
Adjustable length
12 g, excluding strap
1 touch button, used to wake the band and return
to the previous screen
On Cell single-point mutual capacitance
Rotor motor
2Pin Pogo Pin, special charging cable with
magnetic suction
125 mAh (typical)
Lithium polymer
<= 2 hours
About 15 days under the following conditions: (1)
Automatic heart rate detection with a 30-minute
frequency is enabled. (2) The band receives and
displays 100 notifications every day. (3) Two
alarms are set every day, and the band vibrates
for 5 seconds when each alarm is triggered. (4)
The touch button is pressed 10 times per day to
display the current time. (5) The app
synchronizes data once per day. In actual use,
the battery life is related to various factors such
as settings, operations, and use environments,
so it may be different from lab data.
50-meter waterproofing, swimming supported
Low-power triaxial accelerometer +
Triaxial gyroscope
PPG heart rate sensor, without infrared
Bluetooth 5.0 BLE
1.1"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Band 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Mi Smart Band 5

Summary of Contents for Mi Smart Band 5

  • Page 1 Mi Smart Band 5 1. Parameters Parameter Item Mi Smart Band 5 Screen size 1.1" Screen type Color AMOLED Screen resolution 126x294 Screen color quantity 16bit RGB Screen backlight Maximum (adjustable) brightness >= 450 nit Cover plate material 2.5D reinforced glass+AF coating film...
  • Page 2 2. Does the Mi Smart Band 5 generate harmful Bluetooth signals? The Mi Smart Band 5 uses low-power Bluetooth 5.0 technology, with radiation far lower than that of a Bluetooth headset and less than one thousandth of a mobile phone's signal strength.
  • Page 3 3. What is the standard configuration of the Mi Smart Band 5 and what is the strap color? In its standard configuration, the Mi Smart Band 5 is equipped with the band body, strap, charging base, and user guide, which includes a warranty card. The strap color depends on the product actually sold.
  • Page 4 8. What is the Workout sub screen and what is its use? After you bind the Mi Smart Band 5 to the Mi Fit app, you can open the Mi Fit app and enable outdoor running, treadmill, cycling, or walking in workout mode. Then, simply raise your wrist to check the key workout data on the screen, including the time, mileage, pace, heart rate, heart rate zone, average pace, and current time.
  • Page 5 10. How do I attach and detach the strap of the Mi Smart Band 5? How to attach: (1) Install one end of the band body into a slot on the front side of the strap. (2) Press the other end of the band body with your thumb so that the entire band body is locked into the slots of the strap.
  • Page 6 13. How do I charge the Mi Smart Band 5? Use the provided special charging base to charge the Mi Smart Band 5. Take off the band body, then insert the end with two metal contacts into the special charging base as shown in the following figure.
  • Page 7 Smart Band 5 on? The Mi Smart Band 5 sets an initial step count of 10 to reduce the error rate. Step counting starts only after your step count is greater than 10, and the real-time step count on the app screen adds from 10.
  • Page 8 Open the Mi Fit app, choose Profile > Add Device > Band, and bring your phone close to the Mi Smart Band 5. When your phone successfully searches for the Mi Smart Band 5, a tick symbol (√) appears next to the band. Tap the tick to bind the app to the Mi Smart Band 5.
  • Page 9 33. Does the Mi Smart Band 5 support the idle alert feature? Yes. When the Mi Smart Band 5 detects no motion for 1 hour, it vibrates to alert you. You can set the reminder time and the "do not disturb for nap" feature.
  • Page 10 40. How do I set contacts in the Mi Fit app? In the Mi Fit app, choose Profile > Contacts. You can scan QR codes or enter IDs to add contacts, and you can set some contacts as special contacts, as well as view information about your contacts.
  • Page 11 This ensures information security. Set the Off Wrist Lock feature as follows: (1) Open the Mi Fit app, choose Profile > Mi Smart Band 5 > Lab, and tap Off Wrist Lock to go to the Settings screen.
  • Page 12 45. How do I set laptop unlock on the Mi Smart Band 5? 1） Open the Mi Fit app, choose Profile > Mi Smart Band 5 > Lab > Mi Laptop Unlock, and tap On. 2） Install the Mi Induction Key app on your PC. This app can be downloaded from the Microsoft Store.
  • Page 13 51. Why is the body of the Mi Smart Band 5 skewed after installation? The strap of the Mi Smart Band 5 is made from thermoplastic elastomer. It is resilient and can be twisted. If the band body is skewed after installation, slightly twist the skewed position or reinstall the band body.
  • Page 14 (6) If the band remains unresponsive after being charged for a long time, contact our after- sales personnel for testing. The Mi Smart Band 5 reaches the fully charged state in about 2 hours. If a user reports a failure to fully charge, tell the user to check the charging duration, that is, check whether the band has only charged for a short time.
  • Page 15 Fix this problem as follows: (1) Open the Mi Fit app and choose Profile > Mi Smart Band 5 > Incoming Call Alert > Show Contact Names and check whether Show Contact Info is turned on. If it is turned off, contact names are not displayed for incoming calls.
  • Page 16 59. How do I factory reset my Mi Smart Band 5? Swipe down on the band display screen and tap More. Swipe down until you see Settings and tap Settings. Then, Swipe down until you see Factory Reset. Press and hold the band's touch button.
