Included in this package:
1 Pcs PC Player PC0101
1 Pcs 230 VAC / 12 VDC Power Adapter
1 Pcs Stereo Audio Cable (2xRCA - 3,5mm jack)
Application
The PC Player PC0101 is a single channel FM stereo
modulator with balanced outputs dedicated for the
ELKO Link Home system. The PC0101 can be connec-
ted to any audio source and creates from the LF signal
a FM radio channel that can be distributed with in the
ELKO Link Home system, which can be received at any
radio or stereo Hi Fi unit, connected to the system.
The PC0101 is especially dedicated to distribute stereo
audio signals from your home PC (such as MP3 music,
Internet radio, movie sound etc.). The principal
illustration on the back shows how the individual
units are installed in the system.
Installation
• The PC0101 has two input jacks (RCA) for the audio
line (marked "L" and "R"). These are connected to the
PC sound card (audio output) or to the audio equip-
ment in question.
• The PC0101 has an RJ45 output supplying the FM
radio channel (marked "AV link"). The output is conn-
nected to a separate wall outlet using a STP patch
cord (min cat. 5).
• Further, the output signal is distributed into the AV link
port of the multimedia amplifier mounted in the distri-
bution centre.
• The power adapter is connected to the 12 VDC
power input.
• Further an IR link output is available on the PC0101
in case the Audio source can and shall be operated
from a remote control (requires installation of ELKO
Link Home IR link system).
Configuration
The PC Player PC0101 modulates the incoming LF
Stereo signal to a Stereo FM radio channel.
ELKO Link Home
Instructions for
PC modulator PC0101
Art.nr. Typ
PC0101
3386
The PC0101 has a chart of 84 pre-programmed radio
channels (frequencies) that can be set as output. The
radio frequency to be selected (programmed) depends
on which frequencies already are occupied and which
are free (not used by existing radio stations) in the FM
band of the antenna signals.
In the PC0101, 4 main frequencies can be selected,
these are 90 MHz, 95 MHz, 100 MHz and 105 MHz.
Around these main frequencies, in steps of 0,1 MHz,
another 10 channels above and 10 channels below can
be selected.
The total range of possible frequencies is:
89,0 - 91,0 MHz
94,0 - 96,0 MHz
99,0 - 101,0 MHz
104,0 - 106,0 MHz
Once a suitable radio channel (frequency) has been
determined, this has to be set in the PC0101.
The 3 push buttons marked "UP", "SEL" and "DWN"
are used for the programming purpose. Pressing the
"SEL" button for min. 2 seconds starts the programming
– and having not pressed any button for 10 seconds
exits the programming again.
"SEL"
This push-button both enables the programming mode
and afterwards shifts between the 4 main frequencies
at each time being pressed. First, keep the button
pressed for more than 2 seconds to enable programm-
ming. Secondly, press the button a number of times
until the desired main frequency is reached.
90
95
100
105
E-nr
S No Finland: 72 046 05
EL No Norway: 69 426 80
E No Sweden:
(21 channels)
(21 channels)
(21 channels)
(21 channels)
SEL
push-push
