Summary of Contents for Moffat WC8S
- Page 1 Wall Cupboards & Base Units Installation instructions Manual 030 Issue 001 March 2021...
- Page 2 To ensure the best results from these units please take the time to read and follow all safety, installation and maintenance guidelines carefully before proceeding to install. Keep this manual in a safe place for future consultation. These appliances are marked in compliance with the relevant Low Voltage &...
- Page 3 Sliding door models Height with sloping roof L x D x H (mm) (mm) Model 800 x 303 x 600 WC8S 1000 x 303 x 600 WC10S 1200 x 303 x 600 WC12S Hinged door models Height with sloping roof...
- Page 4 1: Positioning base units Check designated area for floor level irregularities. Step 1: Step 2: • Lay out skid plates (e.g. 100mm x 1000mm x 1mm approx metal sheet strips ) on the floor roughly where the counter module feet will land & place unit on top. •...
- Page 5 1: Positioning base units Joining Multiple Modular Units Together Step 3 & 4: • Positioned the next module onto the skid plates and slid up to the first, being careful not to move the first unit out of position. • Adjust the legs until it’s perfectly aligned and level with the first. •...
- Page 6 2: Kick plates Kick plates are designed to clip onto the counter legs allowing easy fitting and removal. The leg clips slide freely along the inside of the kick trim. • Slide the leg clips into the kick plate and line up with legs, push on to the legs to fit. •...
-
Page 7: Door Hinges
3: Door Hinges Clip On Design This hinge comes supplied with an adjustable clip on mounting plate, which allows the door to be fully adjusted and then quickly removed by simply pushing a small button at the very tip of the hinge. Below diagram shows how the concealed style hinge clips on and off from the mounting plate. - Page 8 4: Drawers Drawer are fitted with lift out stainless steel inners. For deep cleaning the drawers also have fully extendible runners with an easy release lever located on the side of the runner.
- Page 9 5: Wall-cupboards: Doors Hinged Doors Soft closing easy to remove and adjust, fitted with sturdy easy clip in hinges and recessed handles. (See page 7.) Sliding doors Easily lift off for cleaning fitted with unique skid pads and black recessed handles. 1.
- Page 10 5: Wall-cupboards: Fitting Commercial grade wall cupboards available in three standard lengths (800mm 1000mm or 1200mm with a choice of sliding or hinged doors. Wall cupboards are fully enclosed, fabricated in stainless steel. The internal mid shelf is removable and adjustable for height in 48mm increments. Designed with a flat roof as standard with the option of a sloping type roof.
- Page 11 5: Wall-cupboards: Fitting 47.5 47.5 Dimension "A" Wall-plate fixing centres Fixing bracket centres Model (Dimension “A” mm) Wall Plates WC4HL/R WC8H EXAMPLE: 400MM WIDE CUPBOARD WC10H WC12H 1105 Additional Anchor Points...
- Page 12 5: Wall-cupboards: Fitting The correct and fit for purpose wall fixings must be use. A wide range of fixings are available from expansion, universal or multi-purpose plugs to various anchor types. Make your decision based on the material you’re working on and the weight of the fixture. Fixings should be selected according to: •...
- Page 13 6: Cleaning Do not use scouring pads or abrasive cleaners of any type. Do not use Solvents, bleach, Caustic Cleaners or biological powders General fabrication and neutral units. Cleaned with hot soapy water and thereafter dried & polished with a soft dry cloth or Leather chamois.
- Page 14 Thank you for choosing E&R Moffat! Scan the QR code below to visit the E&R Moffat website for further information: Failure to use the correct cleaning procedure will invalidate the warranty of your product. E&R Moffat Ltd. www.ermoffat.co.uk Bonnybridge +44 (0) 1324 812272 FK4 2BS sales@ermoffat.co.uk...
