- Page 1 RJB-4 Manual for use and maintenance RJB-4 Ag/MIS/UmGB-2186-05/14 Rev 1.1 P/N: 116252...
- Page 2 Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal developments. © Munters AB, 2018...
-
Page 3: Installation
1 Installation Munters RJB-4 (RJB-4) enables connecting up to 16 load cells to a single RSW-2 Controller or a Platinum Controller. This document details the wiring procedures between the scales and the RJB-4, and between the RJB-4 and the RSW-2. - Page 4 The RJB-4 can support more than one load cell on each terminal. To connect more than four load cells to the RJB-4, place a second set of load cell wires into each terminal load cell block. Figure 2 illustrates four load cells connected to the RJB-4.
- Page 5 6: Red wire o 7: White wire NOTE: There can be up to 100 meters of the supplied black/gray cable between the RSW and the RJB. Figure 4 illustrates a complete Platinum – RJB-4 system. © Munters AB, 2018...
- Page 6 Figure 4: RJB-4 Wired to Platinum Key: • 1: Ground 2: Neutral (USA: L1) • • 3: Phase (USA: L2) 4: Red wire • • 5: White wire 6: Green wire • • 7: Black wire 8: Brown wire •...
- Page 7 1.2 Grounding Proper grounding consists of two steps. 1. Use the AWG 22 cable to connect the RJB-4 to a grounding rod. Figure 5: RJB-4 Connected to Grounding Rod NOTE: Less than 5 ohm is considered a good ground. 2. Use the AWG 14 cable to connect the silo to a grounding rod.
-
Page 8: Scale Calibration
• CAUTION Verify that the RJB-4 is properly grounded to one of the ground terminals. The RJB-4 is powered via the RSW-2 or the Platinum. For detailed wiring information refer to the respective manual. 1.4 Scale Calibration Calibrate the RJB-4 before using the unit. For detailed calibration instructions, refer to the RSW-2 or Platinum manuals. -
Page 9: Warranty And Technical Assistance
Munters plant was required: if this is not done, the user is fully responsible for the damage which they could suffer. - Page 10 The use of non-original spare parts or incorrect assembly exonerates the manufacturer from all liability. Requests for technical assistance and spare parts can be made directly to the nearest Munters office. A full list of contact details can be found on the back page of this manual.
