11. Adjustment
+5°
-10°
·
It is recommended to adjust the columns to the desired height before installing the display.
· If you want to adjust the columns height after finishing the display installation. Please remove
the DVD shelf , then adjust the columns to the desired height.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
TV height is measured
from the floor to the
TV center.
SMMI-ROST-VC
TV Cart
INSTALLATION MANUAL
200x200/300x300
100"
rated
400x200/400x400
for TV
600x400/800x400
MAX
100kg/220lbs
800x600/1000x600
rated
rated
for DVD
for CAMERA
5kg/11lbs
5kg/11lbs
Advertisement
Related Manuals for traulux SMMI-ROST-VC
Summary of Contents for traulux SMMI-ROST-VC
- Page 1 DVD shelf , then adjust the columns to the desired height. INSTALLATION MANUAL 200x200/300x300 Maintenance 100" SMMI-ROST-VC rated rated rated 400x200/400x400 • Check that the bracket is secure and safe to use at regular intervals(at least every three months).
-
Page 2: Required For Installation
Read the entire instruction manual before you start installation and assembly. If you have any questions regarding any of the instructions or warnings, please contact your local distributor for assistance. left adapter bracket left column CAUTION •Use with products heavier than the rated weights indicated may result in instability causing possible injury. -
Page 3: Assembling The Base
1. Assembling the Base 2. Attaching the Columns to the Base inner column Tighten the safety screw. Attach the right base to the middle base and secure with screws(U). Repeat this step for the left base. Pull the pin outwards and pull the inner column upwards at the same time, until the inner column is pulled to the desired height then release the pin to secure. - Page 4 6. Installing the Adapter Brackets 3. Installing the Crossbar Top of the display Press the metal tab to lock the caster. Attach the crossbar to the columns with the appropriate screws. Tighten all screws using a proper When the crossbar Phillips screwdriver.
- Page 5 6b. For Screens with Irregular Back 7. Hooking the Display onto the Universal Plate M-C M-D M-C M-D · Hook the display onto the universal plate. · Tighten the bottom screws to secure them. IMPORTANT: Make sure the display is mounted correctly and the screws are tightened safely before releasing the display.
- Page 6 10. Cable Management 9. Installing the DVD Shelf Install the support bar to the columns at the desired position and secure using the appropriate screws. Route the cables through the cable covers. Attach the DVD shelf to the support bar with the appropriate screws and butterfly nuts.
