unios Evio EVIO0907 Manual

Cleaning
Warning: Before cleaning, disconnect from
mains supply and allow luminaire to cool.
1 1
Disposal
Ensure correct disposal of this
product (waste electrical and
electronic equipment).
Edition 6.7.20 | Product design and technical data may be subject to change
unios.com
Page 4/4
Corrosion Protection
It is important to note that care must be taken
during installation or maintenance to ensure that
the surface of the luminaire is not damaged. Any
damage, which is exposed to moisture will result
in corrosion occurring.
Please also note that any chemical applications on
the luminaire or chemical contact via installation will
cause corrosion of the surface of the luminaire and will
void the warranty.
Ambient Conditions
Recommended to install in an
ambient temperature <35°C.
Evio
Base Codes 7W 600mm 7W 900mm
(One Direction)
EVIO0607 EVIO0907
Base Codes 7W 600mm 7W 900mm
(Two Direction)
EVIT0607 EVIT0907
Class I IP Rating Material
220-240 V ~ 50/60Hz 65 Aluminium
CAUTION – This product must be installed by a qualified installer
Please read instruction manual carefully before installing luminaire
Surge Protection
For comprehensive protection of a luminaire against electrical surges, surge protection shall be installed
on the mains supply where required to protect luminaires and drivers from transient voltage damage.
For warranty information visit unios.com/warranty
Please read these installation instructions carefully before installing this product. This product must be installed and
maintained by a suitably qualified person/s in compliance with the latest applicable regulations and relevant legislation.
Unios does not warrant any claim based on defects or damage caused by misuse, improper installation, improper
operation and/or modifications carried out by the purchaser or third parties. This product shall not be used as a
'working light' during construction. This will result in the warranty of the product to be void. For warranty duration,
please refer to the data sheet.
EVIO EVIT
A A
B
Edition 6.7.20 | Product design and technical data may be subject to change
Page 1/4
BOLLARD LIGHT
20W 600mm 20W 900mm
EVIO0620 EVIO0920
20W 600mm 20W 900mm
EVIT0620 EVIT0920
Install Person/s
1x
Sizing Variations
Product Code A
EVIO0607/EVIT0607
Ø 80
EVIO0907/EVIT0907 Ø 80
EVIO0620/EVIT0620 Ø 115
EVIO0920/EVIT0920 Ø 115
All measurements are in millimetres.
Parts
B
OR
1x Allen Key 2x Allen Key
for 7W for 20W
OR
3x Screws 3x Dynabolts
w/ plugs for 7W for 20W
unios.com
Power
7 | 20 Watts
B
600
900
600
900
3x Heatshrink
Solder Joiners
