  • Page 1 Instructions for Installation and Servicing CONDENSATION AUXILIARY UNIT Appliance types: ZENIT CONDENSER www.pakole.com...
  • Page 2: Table Of Contents

    ZENIT Condenser Contents Table of Contents Safety information �������������������������������������������������������������������������������������������������������3 General Instruction ����������������������������������������������������������������������������������������������������4 Installer’s responsibilities ��������������������������������������������������������������������������������������������������������4 Data board ������������������������������������������������������������������������������������������������������������������������������4 Standards and laws ����������������������������������������������������������������������������������������������������������������5 Safety signs ����������������������������������������������������������������������������������������������������������������������������5 Safe usage �����������������������������������������������������������������������������������������������������������������������������5 Transportation, unpacking, handling �����������������������������������������������������������������6 Operation principle ������������������������������������������������������������������������������������������������������6 Installation ����������������������������������������������������������������������������������������������������������������������7 external structure ��������������������������������������������������������������������������������������������������������������������7 Internal structure ���������������������������������������������������������������������������������������������������������������������7...
  • Page 3: Safety Information

    ZENIT Condenser Instructions for Installation and Servicing Safety information Read and understand this manual thoroughly before installing starting or servicing this equipment. The improper installation or using can cause serious damages! Keep this manual in a safe place in order to...
  • Page 4: General Instruction

    ZENIT Condenser Instructions for Installation and Servicing General Instruction • Make sure that read and understood all the warnings, correct keeping of which can guarantee the safety and faultless operation ! • During the installation be always circumspect! Follow the valid instructions and recommendations! •...
  • Page 5: Standards And Laws

    Qualified service engineers are those having specific technical experience and/or valid license in the field of heating and cooling installa- tion for home and industry. In any case, call the Manufacturer office or the closest dealer (www.pakole.com) and ask for further informa- tions�...
  • Page 6: Transportation, Unpacking, Handling

    ZENIT Condenser Instructions for Installation and Servicing ATTENTION • Never use the unit to support other equipment. • Never leave tools, spare parts, etc. inside the unit. • Make sure that all inspection panels are closed properly� • Do no expose the unit to inflammable gases.
  • Page 7: Installation

    ZENIT Condenser Instructions for Installation and Servicing Installation external structure 3190 1� Outlet of the cooled down flue gas 2� Condensed water outlet 3� Suction of the ambient air 4� Heat exchanger elements 5� Regulator of the blow down temperature of the fan 6�...
  • Page 8: Installation Of Condenser Unit

    ZENIT Condenser Instructions for Installation and Servicing Installation of Condenser Unit When installing the Condenser member attention must always be paid to its inclination otherwise the condense water flows back to the fan and may cause its breakdown. When the inclination is too large excessive load is put on the fan of the basic heating appliance as it should deliver in the opposite direction of the natural flow direction.
  • Page 9: Appliance Operation

    ZENIT Condenser Instructions for Installation and Servicing Lefújó ventilátor motor bekötése ground null Lefújó ventilátor Connecting of fan motor Phase motor bekötése 230V/50Hz gorund 230V/50Hz null 230V/50Hz Phase 5. picture: Connecting of thermostat Appliance operation ATTENTION! When installing and commissioning the Condenser member the entire system must be checked in accordance with the instructions of the manufacturer below and the description laid down in the machine manual.
  • Page 10: Operation Of Automatic Burner Control ( Honeywell S4965R Typ)

    ZENIT Condenser Instructions for Installation and Servicing direction of gas flow direction of gas flow INPUT OUTPUT 6. picture: Input and output gas pressure checking connections in case of HONEYWELL solenoid valve Operation of automatic burner control ( HONEYWELL S4965R typ) Following the switched on voltage the fan operates continuously assuring the 30 seconds pre-purge time.
  • Page 11: Maintenances

    Maintenances The ZENIT Condenser appliance apart from the supervision and cleaning of radiant tubes (see: Maintenance supervision by the cus- tomer), do not need extra maintenances but to be able to preserve the SAFETY OPERATION and LONG LIFETIME of appliance it is recommended to have yearly supervision done by qualified service department.
  • Page 12 If you would like to contact us the type and serial number of device always be at hand. In case of other needed information write to the following address: PAKOLE TRADE Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. Phone.: +36 22 316 484...
