SignVideo SV88 Operation Manual

8x8 Component Video Routing Switcher
This Class B digital apparatus complies with Canadian ICES-003.
Cet Appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the manufacturer, dealer or an experienced radio/TV technician for help.

Included Items:

Routing Switcher, 1 AMP AC adapter, manual & warranty

Description:

Eight in, eight out component video (rca) plus stereo audio electronic routing switcher

HOOK UP

Connect to Power .

Find the small plug on the end of the cable on the 1 Amp AC power adapter. Go to the back panel of the switcher and
connect this plug to the small jack which is labeled 9 vac 1a. Plug the AC adapter itself into a 110V power receptacle.
Press the power button on the front of the switcher. The power LED should light.

Connect Equipment

There are 8 sets of video and stereo audio inputs and outputs. Video is comprised of three components, and there are
three connections for each video channel. The sets are all on the switcher back panel and are numbered 1 through 8.
These correspond to the FROM and TO push buttons on the front panel which are likewise numbered 1 through 8.
Generally, first connect items of video/audio equipment which will be both sending and receiving signals. Connect
these to both the inputs and outputs of one numbered set. Next, connect video/audio equipment which will be only
receiving or only sending signals. Connect these only to one of the output sets or one of the input sets, respectively.
You may wish to number each piece of equipment to correspond to the numbered connections.

OPERATION

Select Mode (Switching Protocol)

One of 3 red LEDs will light to indicate switching mode
Press Button to Select Mode
A/V for video and audio to switch together (audio follow video)
V to switch video only
A to switch audio only

Route Signal

1 Select and press a numbered FROM button to select source
2 Select and press a numbered TO button to select destination
3 Directly above the TO number, the selected FROM number will display, indicating which source signal has been
sent to that destination.
SignVideo
The
with stereo audio
Operations Manual
Copyright © 2004 by Sign video Ltd
.
