Clarke CHT599 Manual

Tungsten Grit Hole Saw Set
CLARKE core drills are vibrationless when used as directed.
Core drills are used to form holes in ceramic tiles, plastic, plywood and aerated concrete
blocks.
A heavy duty drill with adjustable speed control and high torque must be used with hole saws.
B C
A
1. Insert the pilot drill into the mandrel as
shown, tighten the screw on the mandrill
to hold the pilot drill in place.
Do not overtighten the screw.
2. Hook the required hole saw onto the
mandrel.
Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International
D
E
G
H
reserve the right to change specifications at any time without prior notice.
F
A Bayonet Mandrel
B 33mm Hole saw (max -1500 rpm)
C 53mm Hole saw (max -1500 rpm)
D 67 mm Hole saw (max -700 rpm)
E 73 mm Hole saw (max -700 rpm)
F 83 mm Hole saw (max - 700 rpm)
G Carbide Gritted File
H Carbide Tipped Pilot Drill
0 6 0 8
