- Page 1 INSTRUCTION MANUAL CABLE MANAGEMENT DESIGNED BY PJ PRODUCTION & HANS THYGE & CO Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
- Page 2 4 x spacers 4 x nuts CABLE MANAGEMENT - 700 MM Nordic Dark Blue: 6000-0024-5008 Danish Dusty Green: 6000-0024-7033 Scandinavian Matte Black: 6000-0024-9000 Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk...
- Page 3 INSTRUCTION MANUAL PARTS This instruction manual is equal for following: cable management - 700 mm, cable management - 1100 mm, and cable management - 1500 mm. The different parts for cable management - 1100 mm is illuminated below. Note: the instruction manual is made with the large version measuring 1500 mm.
- Page 4 INSTRUCTION MANUAL PARTS This instruction manual is equal for following: cable management - 700 mm, cable management - 1100 mm, and cable management - 1500 mm. The different parts for cable management - 1500 mm is illuminated below. Note: the instruction manual is made with the large version measuring 1500 mm.
-
Page 5: What You Will Need
INSTRUCTION MANUAL WHAT YOU WILL NEED 2 x MULTI CLAMPS 1 x SCREWDRIVER 1 x ALLEN WRENCH Nordic Dark Blue: 6000-0000-5008 One screwdriver. Please note that this is not The Allen wrench is included in the multi Danish Dusty Green: 6000-0000-7033 included! clamp box Scandinavian Matte Black: 6000-0000-9000... - Page 6 INSTRUCTION MANUAL STEP 1 The finger screw must be closed entirely before continuing. Now carefully lead the tube through the hole at the top of the multi clamp. Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
- Page 7 INSTRUCTION MANUAL STEP 2 When the multi clamps have been connected to the tube, then open the finger screw entirely before continuing. Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
- Page 8 INSTRUCTION MANUAL STEP 3 Now carefully insert the tip of the Allen wrench into the hexagon cross section of the socket screw and turn the wrench in a clock- wise fashion until the socket screw has been sufficiently tightened. Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
- Page 9 INSTRUCTION MANUAL STEP 4 The felt wall must be aligned with the cable management before continuing. Now connect the felt wall and cable management with either four or six screws, spacers, and nuts, - depending on the size of the cable management. When these are connected, carefully insert the tip of the screwdriver into the hexogon cross section of the screw and turn the screwdriver in a clockwise fashion until the screw has been sufficiently tightened.
- Page 10 INSTRUCTION MANUAL STEP 5 The cable management can now be attached to the prefered surface. Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
- Page 11 INSTRUCTION MANUAL STEP 6 When the placement of the cable management is correctly, then tighten the finger screw completely. Designed by PJ Production & Hans Thyge & Co // Hårup Skovvej 2, 8600 Silkeborg, Danmark // + 45 86 81 23 75 // www.aptocollection.dk Copyright ©...
