Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2020 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
20k
Advertisement
Table of Contents
Summary of Contents for FISCHER 63298
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Specifications
The operator must understand that common sense and caution are factors, which cannot be built into this product, but must be supplied by the operator. SaVE tHESE inStrUctiOnS. Page 2 For technical questions, please call 1-888-866-5797. Item 63298... - Page 3 Finger tighten the hardware. lock lock Washer (9) Washer (9) Flat Flat Washer Washer base base nut (10) Support Support bolt (7) (11) (11) Step 2: attach Support bars to base Item 63298 For technical questions, please call 1-888-866-5797. Page 3...
- Page 4 Support bar Support bar in place in place Step 3: attach lower lift arm to Upper lift arm assembly and Support bars Page 4 For technical questions, please call 1-888-866-5797. Item 63298...
- Page 5 Replace the R-Clip on the end of each Wheel Bracket Rod to secure the Rods in place. Wheel bracket (34) Width pin (31) cross beam (33) Wheel bracket rod (32) r-clip (23) Step 5: install Wheel brackets and attach Wheel bracket rods Item 63298 For technical questions, please call 1-888-866-5797. Page 5...
- Page 6 (23) and r-clips (23) Upper ram Upper ram lower lower ram pin ram pin ram Secured ram Secured in place in place Step 6: attach Foot pedal and install ram Page 6 For technical questions, please call 1-888-866-5797. Item 63298...
- Page 7 8. Insert the Wheels (1) into the wheel brackets on the rear of the Base (2) and align the holes. Secure Wheels in place using Wheel Bolts (3) and Nuts (4). nut (4) Wheel (1) Wheel bolt (3) base (2) Wheel bracket Step 8: attach Wheels Item 63298 For technical questions, please call 1-888-866-5797. Page 7...
- Page 8 Width pin Safety lock lever Safety lock lever release Foot pedal pedal Fluid Fill Hole Fluid Fill Safety lock levers in plug lOcKED position. Safety lock levers in UnlOcKED position. Page 8 For technical questions, please call 1-888-866-5797. Item 63298...
- Page 9 Refer to Components on page 8. 6. When not in use, store Lift in a safe, dry location out of reach of children. Item 63298 For technical questions, please call 1-888-866-5797. Page 9...
-
Page 10: Maintenance And Servicing
Bleeding instructions on page 9. 4. Clean with a clean cloth with a detergent or mild solvent. Store the Lift in a safe, dry location out of reach of children. Page 10 For technical questions, please call 1-888-866-5797. Item 63298... -
Page 11: Troubleshooting
Ram may be low on fluid. Check the fluid level and refill if needed. Ram may require bleeding – refer to Bleeding on page 9. Unit may have too much hydraulic fluid inside. Check fluid level and adjust if needed. Item 63298 For technical questions, please call 1-888-866-5797. Page 11... -
Page 12: Please Read The Following Carefully
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 12 For technical questions, please call 1-888-866-5797. Item 63298... - Page 13 If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 792363632980 when ordering parts. Item 63298 For technical questions, please call 1-888-866-5797. Page 13...
-
Page 14: Parts List And Diagram
Handle End Cap Upper Ram Pin Handle Bolt M10 x 2 0 Lower Ram Pin Lock Washer Foot Pedal Flat Washer Foot Pedal Bolt M8 x 1 6 Shaft Lock Washer Lower Lift Arm Handle Page 14 For technical questions, please call 1-888-866-5797. Item 63298... -
Page 15: Assembly Diagram
Diagram Item 63298 For technical questions, please call 1-888-866-5797. Page 15... -
Page 16: Limited 90-Day Warranty
limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
