Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2019 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
19l
56803
Advertisement
Table of Contents
Summary of Contents for Maddox MF15-1
- Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
-
Page 2: Specifications
Specifications 0 – 30 In. of mercury (in Hg) Gauge Range Important Safety Information WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS Failure to follow instructions listed below may result in serious injury. SAVE THESE INSTRUCTIONS Keep bystanders, children, and Do not force the tool. Use the visitors away while operating the correct tool for your application. - Page 3 11. Tool service must be performed 18. People with pacemakers should only by qualified repair personnel. consult their physician(s) Service or maintenance performed before use. Electromagnetic fields by unqualified personnel could in close proximity to heart pacemaker result in a risk of injury. could cause pacemaker interference or pacemaker failure.
-
Page 4: Setup Instructions
Setup Instructions Open the Cup (3). Operate the pump several times to create the vacuum. The vacuum Seat the O-ring (11) completely into should not decrease quickly. If air the groove in the top of the Cup. is entering through the vacuum Remove the shipping spacer that release valve, tighten it. -
Page 5: Brake Bleeding
Brake Bleeding Attach a 3" Hose (5) to the Connect the 23" Hose to the bottom of the Suction Lid (2a). remaining port on the Suction Lid. Attach a 23" Hose (4) to the port on Insert a Tapered Hose Adapter (14) the top of the Suction Lid that does not into the 23"... -
Page 6: Maintenance And Servicing
Release the vacuum in the Vacuum 10. Remove the cap from the vehicle’s Pump with the Vacuum Release Valve. master cylinder, and refill the master Then, disconnect the Brake Bleed cylinder back to its normal capacity Screw Adapter from the vehicle’s with clean, new brake fluid. -
Page 7: Parts List And Diagram
Parts List and Diagram Part Description Part Description Vacuum Pump Universal Cup Adapter Suction Lid Cup O-Ring Transport Lid 5/32" x 1 /4" ID Tubing Adapter 4 oz. Cup Vacuum Line Cap 1/4" x 23" Vacuum Hose Tapered Hose Adapter 1/4"... -
Page 8: Limited 90-Day Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
