The SnapAV Luma NVRs are a line of network-enabled Video Recorders that support the connection of
up to 16 IP Cameras. The NVR Connects to the ELAN Controller via Ethernet to provide
communications, enabling control from the ELAN system.
T
HE FOLLOWING FEATURES ARE SUPPORTED
Basic Control: The SnapAV Luma NVR OSD is controllable via ELAN Keypads and the SnapAV OSD
with a built in one-way IP driver and interface. This interface is assignable as a source on any zone
controller on the Media tab.
T
HE FOLLOWING FEATURES ARE NOT SUPPORTED
Live or Recorded Video: Video output from the NVR is not available in the ELAN Viewer.
Any feature not specifically noted as supported should be assumed to be unsupported.
ELAN | SpeakerCraft | Gefen | Furman | Niles | Panamax | Sunfire | BlueBOLT | Proficient | Xantech
1800 South McDowell Blvd., Petaluma CA 94954 • Toll Free: 800.472.5555 • Fax: 707.283.5901
SnapAV
LUM-500-NVR-4CH, LUM-500-NVR-8CH, LUM-500-NVR-16CH
7.3
10/10/17
F
EATURES
:
:
Integration Note

Advertisement

loading
Need help?

Need help?

Do you have a question about the ELAN LUM-500-NVR-4CH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SnapAV ELAN LUM-500-NVR-4CH

  • Page 1 UPPORTED EATURES The SnapAV Luma NVRs are a line of network-enabled Video Recorders that support the connection of up to 16 IP Cameras. The NVR Connects to the ELAN Controller via Ethernet to provide communications, enabling control from the ELAN system.

  • Page 2: Installation Overview

    LUM-500-NVR C ONFIGURATION In addition to normal SnapAV Luma setup procedures, it is required to set the LUM-500-NVR devices to static IP addresses for reliable communications. To set a NVR to a static IP address, use the remote or attached mouse to navigate the on screen interface: 1.
  • Page 3 Network Assembly or Switch/ Any available Router Ethernet port g! System Controller SnapAV NVR Cable provided with Network Assy. ILL OF ATERIALS D e v ic e M a nuf a c t ure r P a rt N um be r...
  • Page 4 <User Defined> Password <User Defined> IP Address <User Defined> Port <User Defined> One Way Interface Interface Name <User Defined> Layout Template SnapAV Connect to Existing <Select from List> SnapAV Luma 500 NVR xxCH Two-Way Device Described above 4 of 8...
  • Page 5 ELAN C ONFIGURATION TEPS NVR I REATE NSTANCE 1. Under Media tab/ Sources, Select Add New Video Server. 2. From the dialog box, choose the SnapAV Luma 500 NVR driver and click OK. 5 of 8...
  • Page 6 3. The Source configuration pane, enter the correct IP, User and Password for the NVR. Also set the port number (default port is 80). REATE USTOM NTERFACE 1. Under Sources, select Add New Custom Source. 2. Select the SnapAV Luma template and connect to SnapAV Luma 500 NVR added in previous steps. 6 of 8...
  • Page 7 3. Finally, add the source to the desired zone controller input as normal and arrange the appropriate selections to manage your Display source to select the SnapAV NVR monitor out for one-way control from the ELAN Viewer. 7 of 8...

  • Page 8: Common Mistakes

    2. If no One-Way Interface commands are functional, authentication may have timed out on the SnapAV DVR. Use the Menu button and navigate to Login/Logout Menu, and select Login. UserID and Password should populate from ELAN credentials.
