User Maintenance Manual/Handbook
Issue 1.01
Firmware version 1.00+
www.isotech.co.uk
sotech.co.uk E E E E - - - - mail:
mail: info@isotech.co.uk
www.i
www.i
sotech.co.uk
sotech.co.uk
mail:
mail:
info@isotech.co.uk
info@isotech.co.uk
info@isotech.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the millisKanner and is the answer not in the manual?

Questions and answers

Summary of Contents for Isotech millisKanner

  • Page 1 Tel: +44 (0)1704 543830 Fax: +44 (0)1704 544799 Internet: www.i www.isotech.co.uk sotech.co.uk E E E E - - - - mail: mail: info@isotech.co.uk info@isotech.co.uk Tel: +44 (0)1704 543830 Fax: +44 (0)1704 544799 Internet: Tel: +44 (0)1704 543830 Fax: +44 (0)1704 544799 Internet: www.i...

  • Page 2: Table Of Contents

    232 INTERFACE 232 INTERFACE ............................... 41 RS232 C STABLISHING AN ONNECTION ........................41 SCPI C OMMAND ..............................44 8.2.1 SCPI Command Structure ..........................45 8.2.2 SCPI Numeric Suffices ............................ 47 ©Isothermal Technology Page 2 of 61 914 millisKanner manual Iss. 1.00...
  • Page 3 8.2.3 Parameters ................................ 47 8.2.4 Controlling the millisKanner Using the RS232 Port ................47 8.2.5 Terminology – Inputs and Channels ......................48 8.2.6 SCPI Commands .............................. 49 8.2.6.1 Command: REMote ................................ 50 8.2.6.2 Command: LOCal................................50 8.2.6.3 Command: *IDN? ................................50 8.2.6.4...

  • Page 4: Introduction

    Each channel is provided with 5 binding posts (for connection to a PRT or thermistor sensor with bare-wire, 4mm plugs or spade connections) and a miniature thermocouple connector. The output from the millisKanner is connected to Channel 2 of the milliK (Channel 1 remains available). Each channel can be configured for use with PRTs, thermocouples or thermistors giving you complete freedom when configuring your system.

  • Page 5: Unpacking

    Section 2.2 (to learn how to connect the millisKanner to your milliK) and then refer back to the manual using the list of contents to find additional information as required.

  • Page 6: Safety

    Safety Safety The millisKanner is a precision instrument, designed for use in a laboratory. It complies with the requirements of safety standard EN61010-1 (2010) and is therefore safe to use in laboratory or light industrial environments. It is not intended for use outdoors or in extreme environments (refer to specification in Section 9).

  • Page 7: A Quick Tour Of Your Millis Kanner

    A Quick Tour of Your millisKanner A Quick Tour of Your millisKanner On the top panel of your millisKanner you will find the binding posts (five per channel) and miniature thermocouple connectors for the eight inputs channels , the “left”/”right”...
  • Page 8 “daisy-chained” together. The unused RS232 port on the last millisKanner in your system can be connected to a PC in order to control the whole measurement system using your own software (see section 8). The command protocol employs the widely used SCPI format (see section 8.2 for details).:...
  • Page 9 (V) terminals are spaced on 19mm (¾”) centres so that standard BNC to 4mm adaptors (not supplied) can be used to connect to thermometer sensors that have BNC terminations ©Isothermal Technology Page 9 of 61 914 millisKanner manual Iss. 1.00...

  • Page 10: Using Your Milliskan Using Your Milliskanner Ner Ner

    Instrument screen of the milliK to re-invoke the discovery process. A millisKanner will only work with a milliK that is running with firmware version 1.11 or above and software version 1.5.4 or above. The firmware and software versions are Start shown on the milliK in the opening screen (with the button).
  • Page 11 C8 socket on the power supply. The plug head can easily be changed: Plug the DC connector from the power supply into either of the “DC Power” sockets on the rear of the millisKanner. ©Isothermal Technology Page 11 of 61...

  • Page 12: Connecting A Single Milliskanner To A Millik

    Using the null modem cable provided (see section 8.1 if you wish to make your own cable), connect either of the RS232 ports on the millisKanner to either RS232 port on the rear of the milliK (it does not matter which port is used as they are completely interchangeable).
  • Page 13 PTFE or polyethylene (otherwise measurement performance may be affected). The screen should be connected to the (green) ground connector of the millisKanner and shell of the Lemo connector. The pin-out used for the Lemo connectors (looking into the solder buckets) is: ©Isothermal Technology...

  • Page 14: Connecting Multiple Millis Kanners To A Millik

    You can still communicate with the milliK even though there is no physical connection to it as the millisKanner will relay commands from the PC to the milliK and will relay back responses from the milliK to the PC (see section 8 for further details).
  • Page 15 Similarly, use the Power Link cable provided to connect either DC Power connector on the millisKanner to the unused DC Power connector on the previous millisKanner in a ‘daisy-chain’...
  • Page 16 It then assigns channels numbers 20-27 to the next multiplexer and so on. This means that the channel marked 7 on the third millisKanner in the ‘daisy-chain’ of RS232 connections will be assigned channel number 37. The red LED (below the binding posts) will light when measurements are being made on that channel.
  • Page 17 If you do not use this feature, or are controlling the millisKanner manually (see section 2.5) you should use good quality, low thermal EMF connectors to connect between the millisKanner and the instrument.
  • Page 18 If a command is sent to the millisKanner to change channels, it returns a <CR> (carriage return) when the change has been made. Any software you write should take advantage of this feature and wait for the change to be acknowledged before making a measurement as this will ensure that erroneous measurements are not made during a transition.

  • Page 19: Controlling Millis Kanner Manually

    (see section 8.2.6.2) to the RS232 port or cycle the power to the instrument. The millisKanner can be used manually with the milliK (do not connect it to the milliK with the RS232 cable so that it is not detected by the milliK) or with another compatible thermometer instrument.
  • Page 20 This means that the voltage offset will be higher than when it is used with a milliK although it should be well within the ±2µV specification of the milliK provided good quality (low thermal EMF) connectors are used.

  • Page 21: Connecting Thermometer Sensors Connecting Thermomet Connecting Thermomet Er Sensors

    The millisKanner can be connected to 3-wire PRTs and will provide automatically compensate for cable resistance. The two positive (red) terminals should be connected together and the ‘single’ end of the 3-wire PRT should then be connected to the I+ terminal as follows: ©Isothermal Technology...

  • Page 22: Connecting Prt S (2- Wire )

    Connecting PRTs (2 wire) wire) wire) The millisKanner can be connected to 2-wire PRTs. The two red and two black measurement terminals should be connected together and then connected to the PRT as follows: ©Isothermal Technology Page 22 of 61...
  • Page 23 BLACK 2-WIRE PRT BLACK The top (green) terminal should be connected to the screen of the PRT’s lead (where present) to minimise electrical noise picked up by the wires. ©Isothermal Technology Page 23 of 61 914 millisKanner manual Iss. 1.00...

  • Page 24: Connecting Thermocouples

    Connecting Thermocouples Connecting Thermocouples Connect thermocouples to your millisKanner by using miniature thermocouple plugs that plug into the sockets below the binding posts for that channel. Copper miniature thermocouple plugs should be used if you intend to use an ice point reference or external reference junction compensation.

  • Page 25: Connecting Thermocouples (Using External Compensation)

    (ensure that it is isothermal with the reference junction). Connect this sensor to another channel (on the milliK or a millisKanner) and configure it with a conversion to temperature units. If you do not first configure the channel so that it can measure temperature, it cannot be used as the reference junction sensor.

  • Page 26: Connecting Thermocouples (Using Internal Compensation)

    To use a thermocouple with internal reference junction compensation (reference junction formed within the millisKanner and its temperature measured using an internal sensor), fit a thermocouple connector of the same type as the thermocouple and connect this to the socket below the binding posts.

  • Page 27: Connecting Thermistors

    3.6 Connecting Thermistors Connecting Thermistors Connecting Thermistors Connecting Thermistors The millisKanner and milliK can be connected to thermistors using the same arrangement as for 2-wire PRTs (see section 3.4): ©Isothermal Technology Page 27 of 61 914 millisKanner manual Iss. 1.00...
  • Page 28 PRTs. ©Isothermal Technology Page 28 of 61...

  • Page 29: Ines Es Es

    The only part of the millisKanner that requires a routine calibration check is the internal reference junction temperature sensor. We recommend that you check this annually. You can check this yourself using the procedures given in this manual (see section 6.2), or we...
  • Page 30 Here are a few guidelines: The most sensitive points are the inputs to the millisKanner or milliK (measuring to better than 0.5 V). Whilst the millisKanner and milliK will work satisfactorily with...
  • Page 31 ‘earth’ the equalising block). Do not ‘earth’ the equalising block to the screen/measurement ground terminals on the front panel of your millisKanner or milliK as this is not connected to the safety earth of the electrical supply.

  • Page 32: The Milliskanner Tec The Milliskanner Technology Hnology

    The limitation is then the thermal EMFs generated by the devices used to implement this reversal. The millisKanner duplicates the reversal system used by the milliK. It detects that it is making a measurement via a millisKanner, and then makes the reversal in the ©Isothermal Technology...

  • Page 33: Solid State Switching

    This means that the voltage measurement uncertainty is the same whether measurements are made directly on the milliK or via a millisKanner. 5.2 Solid Solid- - - - State Switching State Switching Solid Solid State Switching...

  • Page 34: Calibration Calibration

    Before You Check the Calibration Any calibration should be performed in a temperature controlled environment between 19°C and 25°C. The millisKanner should be powered up and left to stabilise in the calibration environment for at least 2 hours before checking or adjusting calibration.
  • Page 35 This approach has the advantage that the difference between room temperature and the reference junction in the millisKanner is likely to be very small (< 3°C) so any error resulting from imperfections in the thermocouple will also be small.

  • Page 36: Adjusting The Reference Junction Sensor

    Reference Junction Sensor Reference Junction Sensor You can adjust the calibration of the millisKanner using the RJC Sensor Calibration feature in the milliK to which it is attached. Before you can use this feature you must first attach a calibrated thermocouple to one of the channels and configure the channel for use with this thermometer (see milliK manual for details).
  • Page 37 ↵ ↵ ↵ ↵ in turn and press the key to enter their values: Press the (F4) key to start the calibration adjustment. Once started, the calibration adjustment process cannot be aborted. ©Isothermal Technology Page 37 of 61 914 millisKanner manual Iss. 1.00...

  • Page 38: Updating Firmware Updating Firmware

    Hyperterminal from your original Windows media. Start Hyperterminal to setup a new connection. Type in a name for the connection (such as millisKanner) and select an icon. In the next window, select the PC’s COM port to Connect using...
  • Page 39 This confirms that you have successfully established an RS232 connection with your millisKanner. The last parameter reported is the current firmware version (in this case, 1.00) so you can ensure that you wish to change this for the version you are about to install.
  • Page 40 When the firmware update is complete the millisKanner will report “programming *IDN? successful – jumping to loaded application”. Now send to confirm that the millisKanner firmware is loaded and running: ©Isothermal Technology Page 40 of 61 914 millisKanner manual Iss. 1.00...

  • Page 41: Rs Rs232 Interface 232 Interface 232 Interface

    Establishing an RS23 Establishing an RS23 2 Connection 2 Connection The RS232 connectors are located on the rear of your millisKanner (see section 1.3). The connector is a 9-way (male) D-type configured as a standard DTE device: Name Name Function...
  • Page 42 Shell Shell Null-Modem Cable A screened RS232 cable is recommended for minimum emissions. ©Isothermal Technology Page 42 of 61 914 millisKanner manual Iss. 1.00...
  • Page 43 The millisKanner has a 255-byte circular receive buffer. If the buffer becomes full and the data continues to be sent data this will be ignored (lost) until the millisKanner has had time to make space in the buffer by processing commands. The millisKanner returns a <CR>...

  • Page 44: Scpi Command Set

    Type into Hyperterminal (terminate the command by pressing the carriage return or Enter keys), the millisKanner should then respond with a string in the form: Isothermal Technology, millisKanner,13-P525, 1.00 This confirms that you have successfully established an RS232 connection with your millisKanner.

  • Page 45: Scpi Command Structure

    (:). To simplify the description of the SCPI commands, the notation represents levels in the tree using horizontal indentations with the root node being the leftmost column. For example, the millisKanner includes the following command structure: REMote LOCal...
  • Page 46 To shorten the commands, default (optional) keywords are enclosed in square brackets and may be omitted. For example, in the case of the command: [ROUTe:]OPEN[:ALL] Valid forms of this command include: Route:Open:all ROUT:OPEN:ALL open ©Isothermal Technology Page 46 of 61 914 millisKanner manual Iss. 1.00...

  • Page 47: Scpi Numeric Suffices

    Using the RS232 Port sKanner Using the RS232 Port The millisKanner has two RS232 ports so that up to four millisKanners can be ‘daisy- chained’ onto the RS232 port of a milliK. The SCPI commands for the milliK and millisKanner have been designed to allow commands and data to be passed along the daisy-chain.

  • Page 48: Terminology Inputs And Channels

    Inputs and Channels Inputs and Channels The terminals on a millisKanner are referred to as “Inputs” and are numbered 0 to 7 on each multiplexer. When connected to a milliK, these inputs are allocated a unique channel numbers so that they can be referenced/addressed by the milliK. The terms “Input”...

  • Page 49: Scpi Commands

    10 to 17. Subsequent millisKanners are assigned channel numbers 20-27 etc. 8.2.6 8.2.6 8.2.6 8.2.6 SCPI Commands SCPI Commands SCPI Commands SCPI Commands The millisKanner supports the following commands: REMote LOCal *IDN? *RST [ROUTe:] CLOSe# CLOSe? OPEN[:ALL]...

  • Page 50: Command: Remote

    Reports information on the millisKanner in 4 comma separated fields: manufacturer model serial number firmware version Example: for a millisKanner with serial number 13-P525 using firmware version 1.00, the *IDN? millisKanner responds to with: ©Isothermal Technology Page 50 of 61...

  • Page 51: Command: *Rst

    Command: [ROUTe:]CLOSe {POSitive|NEGative} Format: [ROUTe:]CLOSe<input#> Selects (connects input to output) the specified input (on the millisKanner to which the RS232 connection is made). The polarity of the sense terminals is defined by the {POSitive|NEGative} parameter. The millisKanner returns a <CR> (carriage return) to acknowledge that the channel has been selected and is ready to use.

  • Page 52: Command: Milliskanner:list

    This command is used by the milliK to ‘discover’ which millisKanners are connected in the ‘daisy-chain’. It reports information on the millisKanner and also forwards the command to the next millisKanner in the daisy chain (on the alternate RS232 port) so that it will also respond.

  • Page 53: Command: Milliskanner:start

    Format: MILLiskanner:STARt? Reports the channel number of the first input (on the millisKanner to which the RS232 connection is made). Example: in a system with two millisKanners connected to a milliK, the response to the MILLI:START? command sent to the second (last) millisKanner in the daisy-chain is “20”.

  • Page 54: Command: Milliskanner:rjc:offset

    This command is reserved for use by the milliK and should not be used directly. It is used to reset all the millisKanners in the daisy-chain by performing a reset (equivalent to a power-on reset) and passing the command to the next millisKanner in the daisy-chain. MILL:RST...

  • Page 55: Command: Calibrate:rjc:offset

    OFFSet OFFSet Format: CALibrate:RJC:OFFSet Sets the value of the offset applied to the RJC sensor (on the millisKanner to which the RS232 connection is made). The value is in °C and has a range of ±10°C. This command CAL:UNL will only work if the calibration has first been unlocked using the command (see section 8.2.6.20).

  • Page 56: Command: Calibrate:unlock

    Command: FIRMware:LOADer Command: FIRMware:LOADer <password> Format: FIRMware: LOADer Puts the millisKanner into a special mode that allows the firmware to be updated by subsequently sending the new file in Intel HEX format (see section 7). ©Isothermal Technology Page 56 of 61...
  • Page 57 Example: to put the millisKanner (which still has the default password “1234”) into the FIRM:LOAD 1234 mode that allows the firmware to be updated, use: ©Isothermal Technology Page 57 of 61 914 millisKanner manual Iss. 1.00...

  • Page 58: Specification N N N

    9 9 9 9 Specification Specification Specification Specification Accuracy Same as milliK used (the millisKanner contributes no Accuracy Accuracy Accuracy additional measurement uncertainty – see section 5) Input Channels 8 Input Channels Input Channels Input Channels Input/Output Input/Output Input/Output Input/Output...

  • Page 59: Approvals Approvals

    10 Approvals Approvals Approvals Approvals The millisKanner has been independently verified as complying with the regulatory requirements of the EU and FCC for electromagnetic compatibility and safety (EU only). 10.1 10.1 10.1 10.1 CE Declaration CE Declaration CE Declaration CE Declaration...

  • Page 60: Standards Applied

    EN61326:2006 & CFR47:2012 Conducted Immunity EN61326:2006 Radiated Immunity EN61326:2006 Electrical Fast Transients EN61326:2006 Electrostatic Discharge EN61326:2006 Surge EN61326:2006 Voltage Dips & Interruptions EN61326:2006 Harmonic Currents EN61000-3-2:2006 Flicker EN61000-3-3:2008 Electrical Safety EN61010-1:2010 ©Isothermal Technology Page 60 of 61 914 millisKanner manual Iss. 1.00...

  • Page 61: 11 Revision History

    11 Revision History Change Note Date Manual Issue Initial release 28/02/2013 1.00 CN13105 17/07/2013 1.01 ©Isothermal Technology Page 61 of 61 914 millisKanner manual Iss. 1.00...
