Summary of Contents for Ampronix BAR8358ACR
- Page 1 PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE PROTECTION PANEL Model: BAR8358ACR Installation Guide Doc.. BAR8358ACR 112219 Rev. A...
- Page 2 No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or any of its part translated into any language or computer file, in any form or by any means — electronic, mechanical, magnetic, optical, chemical, manual, or otherwise — without the express written permission and consent of AMPRONIX. Doc.. BAR8358ACR 112219 Rev. A...
- Page 3 Barco MDSC-8258 & Barco MDSC-8358 Contents INSTALLATION GUIDE PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 BLUE GEM x8 M4 x 12mm Screws x2 Pairs of 2.5mm Allen Key Cleaning Kit Cotton Gloves (1:1 Scale) Doc.. BAR8358ACR 112219 Rev. A...
-
Page 4: Specifications
• Protection panel is made of high grade Acrylic Plastic, allowing for full visibility while offering protection from high impact and chemicals that might otherwise damage or obscure your monitor. • Easily placed and removed and slips over Barco MDSC-8258 & Barco MDSC-8358. Doc.. BAR8358ACR 112219 Rev. A... - Page 5 PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE Doc.. BAR8358ACR 112219 Rev. A...
- Page 6 3. Examine your protection panel. Verify everything shown in the diagram on the next page is there and perfectly functional. 4. Identify what each object on the protection panel is defined as shown to the right. Doc.. BAR8358ACR 112219 Rev. A...
- Page 7 S C R E E N P R OT E C TO R M O N I TO R TO P M O N I TO R B OT TO M 1. Mounting Screw Slots (Top) 2. Screw Inserts (Top) 3. Screw Inserts (Bottom) Doc.. BAR8358ACR 112219 Rev. A...
- Page 8 3. Place the monitor on a clean, even surface with the screen facing towards you. Begin by using the included Allen Key to remove ONLY the screws marked in the next page. These are marked as “2. Screw Inserts (Top)” and “3. Screw Inserts (Bottom)” on the previous page. Doc.. BAR8358ACR 112219 Rev. A...
- Page 9 PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE Doc.. BAR8358ACR 112219 Rev. A...
- Page 10 Ensure that the Mounting slots and the screw inserts line up with the slots on your monitor. 2. Use the x8 enclosed screws that Ampronix included to secure your monitor. We (recommend) using the enclosed screws to ensure your protection panel is secure.
- Page 11 Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE The top of the screen protector will have 12 Inserts, 4 of which are screw inserts. The bottom of the screen protector will have 4 inserts, 4 of which are screw inserts. Doc.. BAR8358ACR 112219 Rev. A...
- Page 12 PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE Part IV. Final Results Doc.. BAR8358ACR 112219 Rev. A...
- Page 13 PROTECTION PANEL for Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE Doc.. BAR8358ACR 112219 Rev. A...
- Page 14 Barco MDSC-8258 & Barco MDSC-8358 INSTALLATION GUIDE For Technical Support or Questions about your product, please use the following: www.ampronix.com info@ampronix.com 15 Whatney, Irvine CA 92618 US and Canada: 1 800 400 7972 International: + 1 949 273 8000 Doc.. BAR8358ACR 112219 Rev. A...
