Alamo Schulte SDX - 840 Operator's Manual

Snow removal

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Published 06/2020

This Operator's Manual is an integral part of the safe operation of this

machine and must be maintained with the unit at all times. READ,

UNDERSTAND, and FOLLOW the Safety and Operation Instructions

contained in this manual before operating the equipment. C01-Cover

Schulte Industries Ltd.

PO Box 70

Englefeld Saskatchewan

Canada S0K 1N0

Tel. (306) 287-3715

Fax. (306) 287-3355

Parts Fax. (306) 287-4066

Web: www.schulte.ca

SDX - 840

SNOW REMOVAL

s/n 2020 Current

OPERATOR'S MANUAL

Part No. B840-010C

Table of Contents

Need help?

Do you have a question about the Schulte SDX - 840 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alamo Schulte SDX - 840

Page 1 UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. C01-Cover Schulte Industries Ltd. PO Box 70 Englefeld Saskatchewan Canada S0K 1N0 Tel. (306) 287-3715 Fax. (306) 287-3355 Parts Fax. (306) 287-4066 Web: www.schulte.ca ©2020 Alamo Group Inc.
Page 2 To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3 DEALER’S PREDELIVERY SERVICE GUIDE for the SCHULTE SNOW BLOWERS SDX840 DETAILS OF ITEMS LISTED BELOW ARE COVERED IN THIS OPERATOR’S MANUAL ____Shipping damage corrected ____Set up machine as outlined in the shipping instructions attached to these instructions. ____Check that all safety decals are in good condition, replace if necessary. ____Check that gearboxes have been filled with oil.
Page 5: Table Of Contents
Table of Contents SAFETY SECTION ......................1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES .................1-2 OPERATOR SAFETY INSTRUCTIONS AND PRACTICES ................1-3 EQUIPMENT OPERATION SAFETY INSTRUCTIONS AND PRACTICES ............1-5 CONNECTING OR DISCONNECTING IMPLEMENT SAFETY INSTRUCTIONS AND PRACTICES ....1-8 TRANSPORTING SAFETY INSTRUCTIONS AND PRACTICES ..............1-9 MAINTENANCE AND SERVICE SAFETY INSTRUCTIONS AND PRACTICES ..........1-11 CONCLUDING SAFETY INSTRUCTIONS AND PRACTICES ................1-13 Decal Location ..............................1-14...
Page 6 DISCONNECTING SNOW BLOWER FROM THE TRACTOR ................4-29 SNOW BLOWER STORAGE ...........................4-31 TRANSPORTING THE TRACTOR AND SNOW BLOWER ................4-32 Transporting on Public Roadways ........................4-33 Hauling the Tractor and Implement ........................4-36 TROUBLE SHOOTING GUIDE ........................4-37 MAINTENANCE SECTION ....................5-1 GENERAL MAINTENANCE ..........................5-2 Bolt Grades and Torque .............................5-2 Auger Drive Chain ..............................5-3 Blade ..................................5-3...
Page 8: General Safety Instructions And Practices
Safety Messages. Always use good common sense to avoid hazards. (SG-2) Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) SDX840 06/20 Safety Section 1-2 © 2017 Alamo Group Inc.
Page 9: Operator Safety Instructions And Practices
(SG-I7) Always read carefully and comply fully with the manufacturer’s instructions when handling oil, solvents, cleansers, and any other chemical agent. (SG-22) SDX840 06/20 Safety Section 1-3 © 2017 Alamo Group Inc.
Page 10 Stay away until all motion has stopped and the snow blower is securely blocked up before removing material, performing service, and making repairs. (SSB-5) SDX840 06/20 Safety Section 1-4 © 2017 Alamo Group Inc.
Page 11: Equipment Operation Safety Instructions And Practices
Operator’s Manuals, been trained in proper operation of the tractor and Implement, and are physically large enough to reach and operate the controls easily. (SG-11) SDX840 06/20 Safety Section 1-5 © 2017 Alamo Group Inc.
Page 12 Implement. Lower the implement carefully to the ground. Do not put hands or feet under lifted components. (SPU-3) SDX840 06/20 Safety Section 1-6 © 2017 Alamo Group Inc.
Page 13 Do not operate this machine with anyone in the immediate area. Stop Snow Blowing if anyone is within 200 feet of Snow Blower. (SSB-11) SDX840 06/20 Safety Section 1-7 © 2017 Alamo Group Inc.
Page 14: Connecting Or Disconnecting Implement Safety Instructions And Practices
Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) SDX840 06/20 Safety Section 1-8 © 2017 Alamo Group Inc.
Page 15: Transporting Safety Instructions And Practices
Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in such a way as to be clearly visible and legible. When transporting the Equipment use the Tractor flashing warning lights and follow all local traffic regulations. (SG-6) SDX840 06/20 Safety Section 1-9 © 2017 Alamo Group Inc.
Page 16 Failure to maintain adequate vision of the public roadway and traffic can result in serious injury or even death. (STI-10) SDX840 06/20 Safety Section 1-10 © 2017 Alamo Group Inc.
Page 17: Maintenance And Service Safety Instructions And Practices
Do Not fill fuel tank while engine is running. Refuel only after engine has cooled down. If fuel is spilled, move machine away from the area of the spill and avoid creating any source of ignition until the spill has been cleaned up. (SG-28) SDX840 06/20 Safety Section 1-11 © 2017 Alamo Group Inc.
Page 18 DO NOT weld or repair rotating Blower components. Welds and other repairs may cause severe vibration and/or component failure resulting in parts being thrown from the blower causing serious bodily injury. See your Authorized Dealer for proper repairs. (SSB-14) SDX840 06/20 Safety Section 1-12 © 2017 Alamo Group Inc.
Page 19: Concluding Safety Instructions And Practices
Safety Messages and operation instruction in each of the appropriate sections of the Tractor and Equipment Manuals. Pay close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18) SDX840 06/20 Safety Section 1-13 © 2017 Alamo Group Inc.
Page 21 (Some shipping and handling charges may apply). Contact your Schulte dealer to order replacement decals. SDX840 06/20 Safety Section 1-15 © 2017 Alamo Group Inc.
Page 29: Federal Laws And Regulations
(Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) SDX840 06/20 Safety Section 1-23 © 2017 Alamo Group Inc.
Page 32 Left hand side: Side which is to the left when the operator is facing in the normal forward direction of the tractor. Right hand side: Side which is to the right when the operator is facing in the normal forward direction of the tractor. SDX 840 06/20 Introduction Section 2-2 © 2017 Alamo Group Inc.
Page 33 3. Record the Snow Blower Model and Serial Numbers on the Warranty page at the front of the Operator’s Manual. Keep this as part of the permanent maintenance file for the Implement. SDX 840 06/20 Introduction Section 2-3 © 2017 Alamo Group Inc.
Page 35 The customer is responsible for the transportation costs of the product or parts to the dealer for repair. • Ground freight charges for shipping new warrantable replacement parts to the dealer or customer will be covered by Schulte. Only ground transportation will qualify for reimbursement. SDX 840 06/20 Introduction Section 2-5 © 2017 Alamo Group Inc.
Page 36 Warranty Contacts: All warranty questions can be emailed to info@schulte.ca or phone Schulte Industries at 1-800-404-6044. Schulte reserves the right to change and modify this warranty policy at any time. SDX 840 06/20 Introduction Section 2-6 © 2017 Alamo Group Inc.
Page 38: Three Point Hitch Kit
IMPORTANT: Carefully raise and lower the snow blower and check for any possible interference between the snow blower and tractor. Turn discharge chute full left and right. Make adjustments if necessary. SDX 840 05/19 Assembly Section 3-2 © 2017 Alamo Group Inc.
Page 40 Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) STANDARD EQPUIPMENT & SPECIFICATIONS SDX-840 Weight (approximate) 1000 (lbs) Working Width 84" SDX 840 05/19 Operation Section 4-2 © 2017 Alamo Group Inc.
Page 41: Operator Requirements
• Hard Hat • Steel Toe Safety Footwear • Gloves • Hearing Protection • Close Fitting Clothing • Respirator or Filter Mask (depends on operat- ing conditions) OPS-U- 0002 SDX 840 05/19 Operation Section 4-3 © 2017 Alamo Group Inc.
Page 42 Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. (SG-27) SDX 840 05/19 Operation Section 4-4 © 2017 Alamo Group Inc.
Page 43: Tractor Requirements
Never operate the tractor PTO with the PTO master shield missing or in the raised position. OPS-U- 0004 SDX 840 05/19 Operation Section 4-5 © 2017 Alamo Group Inc.
Page 44: Tractor Horsepower
(if equipped) or block up securely to prevent falling and possible crushing injury and/or other injury from holding or lifting heavy components. Use the stand to stabilize the implement during storage. (S3PT-3) SDX 840 05/19 Operation Section 4-6 © 2017 Alamo Group Inc.
Page 45: Tractor Hydraulics
Mower blades driving the Tractor transmission even though the Tractor clutch has been disengaged. Install an over running clutch between the Tractor PTO and the Mower driveline to prevent this potentially dangerous situation. (S3PT-16) SDX 840 05/19 Operation Section 4-7 © 2017 Alamo Group Inc.
Page 46: Tire Spacing
(SG-11) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) SDX 840 05/19 Operation Section 4-8 © 2017 Alamo Group Inc.
Page 47: Dismounting The Tractor
After the tractor engine is running, avoid accidental contact with the tractor transmission to prevent sudden and unexpected tractor movement. OPS-U-0028 Never run the Tractor engine in a closed building or without adequate ventilation. The exhaust fumes can be hazardous to your health. (SG-23) SDX 840 05/19 Operation Section 4-9 © 2017 Alamo Group Inc.
Page 48: Connecting The Snow Blower To The Tractor
Note: Set the 3-point lift control to “Position Control” so that the lift arms maintain a constant height when attaching the snow blower. See the tractor Operator’s Manual for correct settings when attaching 3-point equipment. SDX 840 05/19 Operation Section 4-10 © 2017 Alamo Group Inc.
Page 49 Release of the control lever or mechanical failure will result in the Implement falling and possible injury or death. Always securely block up the Implement before crawling underneath to perform repairs and service. (S3PT-19) SDX 840 05/19 Operation Section 4-11 © 2017 Alamo Group Inc.
Page 50: Driveline Attachment
A driveline not attached correctly to the Tractor PTO shaft could come loose and result in personal injury and damage to the Implement. (S3PT-17) SDX 840 05/19 Operation Section 4-12 © 2017 Alamo Group Inc.
Page 51: Driveline Length Check
16” or 20” position for required clearance. SDX 840 05/19 Operation Section 4-13 © 2017 Alamo Group Inc.
Page 52: Connecting Snow Blower Hydraulic Lines To The Tractor
Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death. (SG-14) SDX 840 05/19 Operation Section 4-14 © 2017 Alamo Group Inc.
Page 53: Snow Blower Pre-Operation Inspection/Service
PTO shaft. • Inspect that the 3-point hitch pins are the proper size, correctly installed, and secured to the tractor lift arms with retaining pins inserted. SDX 840 05/19 Operation Section 4-15 © 2017 Alamo Group Inc.
Page 54 Stay away until all motion has stopped and the snow blower is securely blocked up before removing material, performing service, and making repairs. (SSB-5) SDX 840 05/19 Operation Section 4-16 © 2017 Alamo Group Inc.
Page 55 IMPORTANT: DO NOT use your hands to check for oil leaks. Use a piece of heavy paper or cardboard to check for hydraulic oil leaks. SDX 840 05/19 Operation Section 4-17 © 2017 Alamo Group Inc.
Page 56 The radiator is free of debris The air filter is in good condition Proper hourly greasing is done as per Operator’s Operator’s Signature:__________________________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT SDX 840 05/19 Operation Section 4-18 © 2017 Alamo Group Inc.
Page 57 Gearbox oil is at the proper level. Snow blower fan blades are not chipped, cracked or bent. Machine is lubricated as per Operator’s Manual. Operator’s Signature:____________________________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT SDX 840 05/19 Operation Section 4-19 © 2017 Alamo Group Inc.
Page 58: Driving The Tractor And Snow Blower
Such an impact could cause the Implement and Tractor to pivot violently resulting in loss of steering control, serious injury, or even death. Never allow the Implement to contact obstacles. (S3PT-12) SDX 840 05/19 Operation Section 4-20 © 2017 Alamo Group Inc.
Page 59: Starting The Tractor
The tractor should never be operated at speeds that cannot be safely handled or which will prevent the operator from stopping quickly during an emergency. If the power steering or engine ceases operating, stop the tractor immediately as the tractor will be difficult to control. SDX 840 05/19 Operation Section 4-21 © 2017 Alamo Group Inc.
Page 60 Raising the implement exposes the auger which creates a potentially serious hazard and could cause serious injury or even death from objects thrown from the auger. SDX 840 05/19 Operation Section 4-22 © 2017 Alamo Group Inc.
Page 61: Crossing Ditches And Steep Inclines
Ground contact also produces a severe shock load on the snow blower drive and resulting in possible damage and premature wear. OPS-SB-0024 SDX 840 05/19 Operation Section 4-23 © 2017 Alamo Group Inc.
Page 62: Operating The Tractor And Snow Blower
Inspect the area for such objects before working in the area. Remove any such objects from the site. Never allow the implement to contact such objects. (STL-6) SDX 840 05/19 Operation Section 4-24 © 2017 Alamo Group Inc.
Page 63: Engaging The Power Take Off (Pto)
Do not put hands or feet under implement as it can result in death or serious injury. Stay away until all motion has stopped and the frames are securely blocked up. (STL-3) SDX 840 05/19 Operation Section 4-25 © 2017 Alamo Group Inc.
Page 64: Pto Rpm Ground Speed
1” to avoid blowing rocks & debris. Before operating the snow blower recheck that all fasteners, nuts, bolts, screws and cotter pins are in place and all bolts are torqued to specification. SDX 840 05/19 Operation Section 4-26 © 2017 Alamo Group Inc.
Page 65 For best results keep the snow blower fan running at rated PTO speed. If the tractor engine starts to labour, gear down. SDX 840 05/19 Operation Section 4-27 © 2017 Alamo Group Inc.
Page 66 PTO and wait for all implement rotation to come to a complete stop before proceeding to raise the implement. If implement is raised to high while the unit is running there is a possibility of damaging the driveline. SDX 840 05/19 Operation Section 4-28 © 2017 Alamo Group Inc.
Page 67: Shutting Down The Implement
Snow Blower, Lower and lock storage stand in place, Stay away from front of Snow Blower until equipment is stable and secured from falling. Sudden or inadvertant falling of equipment could result in serious injury or death. (SSB-35) SDX 840 05/19 Operation Section 4-29 © 2017 Alamo Group Inc.
Page 68 Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death. (SG-14) SDX 840 05/19 Operation Section 4-30 © 2017 Alamo Group Inc.
Page 69: Snow Blower Storage
Implement to shift or fall crushing themselves or others. (SG-25) Always maintain the safety signs in good readable condition. If the safety signs are missing, damaged, or unreadable, obtain and install replacement safety signs immediately. (SG-5) SDX 840 05/19 Operation Section 4-31 © 2017 Alamo Group Inc.
Page 70: Transporting The Tractor And Snow Blower
Use extreme caution and avoid hard applications of the tractor brakes when towing heavy loads at road speeds. Never tow the implement at speeds greater than 20 MPH (32 kph). OPS-U- 0018 SDX 840 05/19 Operation Section 4-32 © 2017 Alamo Group Inc.
Page 71: Transporting On Public Roadways
Be extremely cautious when the piece of equipment that you are towing is wider than the tractor tire width and/or extends beyond your lane of the road. SDX 840 05/19 Operation Section 4-33 © 2017 Alamo Group Inc.
Page 72 Allow sufficient clearance for the Implement to swing outward while turning. Implements carried behind the Tractor will swing outside the tire path when making turns. Contacting a solid object while turning will cause equipment damage and possible injury. (S3PT-20) SDX 840 05/19 Operation Section 4-34 © 2017 Alamo Group Inc.
Page 73 When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. (SG-19) SDX 840 05/19 Operation Section 4-35 © 2017 Alamo Group Inc.
Page 74: Hauling The Tractor And Implement
If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 SDX 840 05/19 Operation Section 4-36 © 2017 Alamo Group Inc.
Page 75: Trouble Shooting Guide
Tighten bolts Worn universal joints bearings See your dealer Worn Bearings See your dealer Does not throw snow Check valve installed wrong Install check valve as shown on parts page SDX 840 05/19 Operation Section 4-37 © 2017 Alamo Group Inc.
Page 78: General Maintenance
Do not replace lock nuts with nuts and lock washers. Use only original equipment lock nuts. Recommended Torques in foot pounds for SAE Grade 5 bolts, based on dry assembly: SDX 840 05/19 Maintenance Section 5-2 © 2017 Alamo Group Inc.
Page 79: Auger Drive Chain
Grade 8.8. Refer to the illustrations for help in identification of these grades of bolts. Specified shear bolts and their locations are listed below: Model 8400, Auger: 5/16 18 UNC, 2" long, Grade 2 Model 8400 PTO Shaft: M10 METRIC, 50mm, Grade 8.8 SDX 840 05/19 Maintenance Section 5-3 © 2017 Alamo Group Inc.
Page 80: Lubrication
IMPORTANT: Replacement of the shear bolt with one of any other grade or size will be considered an unauthorized modification and the warranty will be void. 5.1 LUBRICATION Gearboxes IMPORTANT: Remember to check oil level in all gearboxes. SDX 840 05/19 Maintenance Section 5-4 © 2017 Alamo Group Inc.
Page 81 If the fan must be removed from the gearbox, antiseize must be added to the shaft prior to installation. Gear case oil should meet the following specifications: API Service Classifications GL 5 Military Specification MIL L 2105C Consult the following chart for the oil viscosity recommendations: SDX 840 05/19 Maintenance Section 5-5 © 2017 Alamo Group Inc.
Page 82: Grease Schedule
½". If wear is found, a shim kit can be purchased from your local Schulte dealer. To install the shim kit: SDX 840 05/19 Maintenance Section 5-6 © 2017 Alamo Group Inc.
Page 83: Storage
7. STORAGE Wash any dirt or salt off the snow blower. Remove drive chains and submerse in oil Smear grease over any exposed hydraulic cylinder shafts SDX 840 05/19 Maintenance Section 5-7 © 2017 Alamo Group Inc.
Page 86 SDX-840- 06/20 Part No. B840-010C Printed Canada...
