Enhanced touch tracker overview
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

ADTT32E Enhanced T
1
Toggles the state of
the dome's output.
Starts the menu.
Clears active alarm or
the last keypad entry
Opens or closes the camera's
iris, making the picture on the
monitor appear darker or lighter.
Calls up a specific monitor.
Also cycles through installed
monitors.
Controls the camera's
zoom function.
New and Improved Features
The enhanced T
OUCH
the following features:
LCD backlight brightness
Volume control for key click
Turn key click On or Off
8000-2656-02, Rev. A (Pages 6)
Initiates the currently selected
dome's Apple Peel pattern.
Displays the dome's
ID code.
Controls the camera's pan and tilt
function. Also allows you to interface
with the menu.
T
allows you to customize
RACKER

Quick Reference Guide

T
OUCH
RACKER
Displays
camera, monitor, Quick View or
Pattern number. Also displays
system prompts and messages.
Calls up video from a
specific camera.
Controls the camera's
focus function.
In addition, the following features have changed to
improve the usability and reliability of the Touch Tracker:
Larger, hard plastic keys
Number keys
Function keys
Camera and Monitor keys (with icons)
New Tracker Ball and mechanism
Eliminates need for calibration
Microswitch zoom and focus keys
Updated color scheme
AMERICAN DYNAMICS PRODUCTS
®
Overview
currently
selected
Enters the number of the
Camera, Monitor, Quick View,
Pattern or Output.
Flips the SpeedDome
180º.
Calls up a Quick View.
Calls up a Pattern one time.
Repeats a Pattern indefinitely.
Initiates the Sequence.
Steps forwards and backwards
through the installed cameras in
sequential order.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADTT32E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dynamics ADTT32E

Summary of Contents for American Dynamics ADTT32E

  • Page 1: Quick Reference Guide

    ADTT32E Enhanced T Displays the dome's ID code. Toggles the state of the dome's output. Starts the menu. Clears active alarm or the last keypad entry Opens or closes the camera's iris, making the picture on the monitor appear darker or lighter.
  • Page 2 Peel will run Pattern 3 (if Pattern 3 has been programmed). Clear an Alarm To clear the alarm whose information currently appears on the LCD press Clear. ADTT32E / AD32 ENHANCED TOUCH TRACKER Monitor 8000-2656-02, REV. A...

  • Page 3: Speeddome Lt Auto Pan Programming

    RACKER To initiate the pre-defined Sequence, press Seq. The Sequence repeats itself indefinitely until you press Seq or Clear. ADTT32E / AD32 ENHANCED TOUCH TRACKER 8000-2656-02, REV. A Define Quick Views Note: SpeedDome Ultra III/DeltaDome and newer domes support 96 views. Other domes support only four views.
  • Page 4 Character Selection field that will be used in the name for the camera. Press zoom or focus to select the character. If you make a typing mistake, use the Next button to move around the Title field. ADTT32E / AD32 ENHANCED TOUCH TRACKER 8000-2656-02, REV. A...

  • Page 5: Setting Up Events

    6. The default event is a Quick View. If you do not want a Quick View, press the Pattern or Seq button to change this field. ADTT32E / AD32 ENHANCED TOUCH TRACKER 8000-2656-02, REV. A 7. If you are setting up a Quick View or Pattern to be...

  • Page 6: Disabling Timed Events

    7. When finished changing event times, press Menu twice to return to camera control mode. QUICK REFERENCE GUIDE American Dynamics, AD, Touch Tracker and the AD logo are trademarks of Sensormatic Electronics Corporation. Other product names (if any) mentioned herein may be trademarks or registered trademarks of other companies.
