2.Timing settings (2.1,2.2 and 2.3 three functions can not be used at the same time)
2.1 20 groups setting of on/off function：
Step Button
1
Press
2 Press H+ and M+
3 Press D+
4
Press
5 Press H+,M+
6 Press D+
7 Repeat step 1-6
a. The ON/OFF program group can not setting overlap but should according to the time sequence.(If setting same ON/OFF time after contact 15
seconds, will have ring bell function ect,)
b. When setting is finished, press
c. Press enter to the interface ON or OFF program, press "MANUAL" to clear the ON or OFF time of current group and then display "-- ：--".
2.2 20 pulsation function setting ("P" flashes on screen when opening)
Step Button
1 Hold both H+ and M+ for 3 sec
2
Press H+, M+ and
3
Press both and Manual
4
Press
5 Press H+/M+
6 Press D+
7 Repeat step 4-6
Press both H+ and M+
a. When setting is finished, press
b. Press enter to the interface pulsation program, press "MANUAL" to clear the pulsation time of current group and then display "-- ：--".
2.3 Countdown function setting ("d" displayed at bottom left corner of screen)
Step Buttion
1
Hold both and
2
press and H+/M+ at the same time
3 Press MANUAL
4
Press
5
Hold both and
3. Manual daylight saving time (DST) display time setting：
Step Button
setting Hold both H+ and M+ for 3 sec
Hold both H+ and M+ for 3 sec again
cancel
Enter into timing ON setting (display 1 ON)
Set ON time, press H + to set the hour, press M + to set the minute
Same setting every day, MO-FR, MO-SA, SA-SU, MO-WE, TH-SA, MO WE FR, TU
TH SA (if it is same every day, do not press D+ and skip this step)
Enter into timing OFF setting (displays 1 OFF)
Set OFF time, press H + to set the hour, press M + to set the minute
Same setting every day, MO-FR, MO-SA, SA-SU, MO-WE, TH-SA, MO WE FR, TU
TH SA (if it is same every day, do not press D+ and skip this step)
Set the ON/OFF time of 2nd to 20th groups(or press
to view the set number of ON/OFF and the time, it be modified follow the appropriate setup steps.
Enter into the pulse width setting, display as 0:00 and P
Set the pulse width: min / s (max 59 min 59 sec)
at the same time
The pulse width setting is completed, the P on the screen flashes
Enter into timing pulsation ON(Display 1 ON)(Press again for the second pulse time)
Set ON time
Same setting every day, MO-FR, MO-SA, SA-SU, MO-WE, TH-SA, MO WE FR, TU
TH SA (if it is same every day, do not press D+ and skip this step)
Set the pulsation time of 2nd to 20th groups(or press
Exit the pulsation function, the display P will be disappeared
to view the set number of pulsation and the time, it be modified follow the appropriate setup steps.
Enter into the countdown setting, "d" displayed at bottom left corner, displayed as
for 3 sec
0:00
Set the min and sec of countdown respectively（duration range：1sec~99min59sec）
Start the countdown function
Halfway reset and wait to start the countdown again
Exit the countdown setting, "d" at bottom left corner will be disappeared
for 3 sec
The present time will increase 1hour("1h" displayed at the bottom left corner of the
screen)
DST will be canceled and back to the present time
