AmbiCom WL1100C-CF Product Specifications

11 mbps wireless lan compactflash card
Hide thumbs Also See for WL1100C-CF:

Advertisement

Quick Links

Product Specifications
Model Number
Descriptions
Interface
Radio Specifications
Radio Type
Data Rate
Antenna
Frequency Band (ISM Band)
and Operating Channels
(IEEE 802.11b Compliant)
Type of Modulation
Receiver Sensitivity
Operating Temperature
Storage Temperature
Operating Range
Confined Environment
Open Environment
Output Power
Power Consumption
Security
Physical Specifications
Dimension
Weight
LED
11 Mbps Wireless LAN
CompactFlash Card
Model: WL1100C-CF
WL1100C-CF
802.11b Wireless LAN CompactFlash Card
Type I CompactFlash Card
Direct Sequence Spread Spectrum (DSSS)
1, 2, 5.5,11 Mbps Per Channel
Embedded Antenna
N. America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels)
Japan: 2.412~2.484 GHz (14 channels)
France: 2.457~2.472 GHz (4 channels)
Spain: 2.457~2.462 GHz (2 channels)
DBPSK : 1 Mbps
DQPSK : 2 Mbps
CCK
: 5.5 and 11 Mbps
1, 2, 5.5 Mbps < -85 dBm
11 Mbps: -83 dBm
-20 degree C – 70 degree C
-30 degree C – 80 degree C
164 ft. (50M) @ 11 Mbps
262 ft. (80M) @ 5.5 Mbps
394 ft. (120M) @ 2 Mbps
492 ft. (150M) @ 1 Mbps
820 ft. (250M) @ 11 Mbps
1,148 ft. (350M) @ 5.5 Mbps
1,312 ft. (400M) @ 2 Mbps
1,640 ft. (500M) @ 1 Mbps
11dBm (Max. 13dBm)
Tx: <370 mA
Rx: <250 mA
Standby: <100 mA
Up to 128-bit Key WEP, RC4 Wireless Data Encryption
2.18 x 1.69 x 0.13 in. (55.4 x 42.8 x 3.3 mm)
0.60 oz. (17 g)
Power
Rev : 3.0
