- Page 1 Broadmoor Wood Bench Item No. OF-1001 For assistance with assembly, please contact DTYStore.com Customer Satisfaction Center 866-217-8155 . CS@DTYStore.com Made in Vietnam Broadmoor Wood Bench OF-1001 www.DTYStore.com Page 1 of 5...
- Page 2 Pre-Assembly Instructions • Read all instructions carefully before assembly. • Find a smooth clean area in which to work to avoid damaging your item. • Check that all parts and hardware from the lists are present. • Lay out parts in alphabetical order and hardware in numerical order to make them easier to find when you are ready to assemble •...
- Page 3 Hardware List: 1. Bolt/Barrel Nut Qty: 4 2. Long Screw (90mm long) 3. Medium Screw (60mm long) Qty: 4 Qty: 2 4. Short Screw (35mm long) Qty: 4 5. Hex Wrench Qty: 2 Assembly Instructions: Step 1 Wait to fully tighten all hardware until the end of Step 3. Use two Bolts/Barrel Nuts (1) and one Long Screw (2) to loosely attach one Leg (A) to the Back (C).
- Page 4 Step 2 Use two Bolts/Barrel Nuts (1), two Long Screws (2), and one Medium Screw (3) and Hex Wrench (5) to loosely attach the Leg (A) to the Back (C), Seat Cross-Bar (D) and Leg Cross-Bar (E). Insert Seat (B) Broadmoor Wood Bench OF-1001 www.DTYStore.com Page 4 of 5...
- Page 5 Step 3 From the underside of the Seat, use four Short Screws (4) with the Hex Wrench to loosely attach the Seat to the Legs. Use the Hex Wrench to fully tighten all bench hardware. Post-Assembly Instructions: • Periodically check hardware to be sure it does not loosen over time. •...
