Summary of Contents for Sterilight Viqua S2Q-OZ
- Page 1 Owner’s Manual Models: S2Q-OZ, S2Q-OZ/2, S8Q-OZ, S8Q- OZ/2 Powered by 425 Clair Rd. W, Guelph, Ontario, Canada N1L 1R1 t. (+1) 519.763.1032 • tf. (+1) 800.265.7246 (US and Canada only) t. (+31) 73 747 0144 (Europe only) • f. (+1) 519.763.5069 e-mail: info@viqua.com www.viqua.com 520025_RevP...
- Page 2 Congratulations on the purchase of your Ozone water system! This system uses the most advanced UV technology on the market and is designed to provide you with years of trouble free operation with minimal maintenance. To ensure ongoing optimal operation, UV lamps need to be replaced annually with VIQUA factory-supplied replacements.
-
Page 3: Safety Information
Safety Information Section 1 Safety Information These are the original instructions.Please read this entire manual before operating this equipment. Pay attention to all danger, warning, and caution statements in this manual. Failure to do so could result in serious personal injury or damage to the equipment. - Page 4 Safety Information WA R N I N G • This system contains a UV Lamp. Do not operate the UV Lamp when it is removed from the chamber. Unintended use or damage of the system may result in the exposure of dangerous UV radiation. UV radiation may, even in little doses, cause harm to the eyes and skin. •...
-
Page 5: General Information
General Information Section 2 General Information Figure 1 System Components Item Description Part Number UV Systems O-ring 410933-R S2Q-OZ, S2Q-OZ/2, S8Q-OZ, S8Q-OZ/2 S415ROL S2Q-OZ, S2Q-OZ/2 UV lamp S8ROL/4P S8Q-OZ, S8Q-OZ/2 Controller (100-240V/50-60 Hz) BA-ICE-SO S2Q-OZ, S2Q-OZ/2, S8Q-OZ, S8Q-OZ/2 Retaining nut RN-001 S2Q-OZ, S2Q-OZ/2, S8Q-OZ, S8Q-OZ/2 IEC replacement power cords for... -
Page 6: Section 3 Installation
Installation Section 3 Installation 3.1 Ozone Generator WA R N I N G • Do not look directly into the ports.ultraviolet light emitted by the lamp can cause burns to unprotected eyes. • The S2Q-OZ will generate sufficient ozone for most spa and hot tub applications subject to the wide variations that occur depending on operating conditions, chemical control and bather load. - Page 7 Installation Figure 2 Figure 2 Pressure Differential System Your spa may have come equipped with a 1/4” NPT threaded inlet on the air line, if not you may be required to drill and tap a 1/4” NPT hole to install the 1/4” NPT to barbed adaptor that comes with the OE-001 kit. The location for the ozone injection point will be decided by where you choose to place the adapter.
-
Page 8: Maintenance
Maintenance 3.1.2 Water Venturi System for Pools and Some Large Spas (Not Included or Sold by Viqua) A venturi draws air by forcing a set amount (or flow rate) of water through a pipe that gradually reduces in size and at the smallest point in the pipe the venturi action (or air suction) is created. -
Page 9: Section 5 Operation
Operation The ozone generator should be on whenever the pump is operating. ozone generation requires a continuous air supply through the cell. The air suction can be produced in various ways, as discussed earlier in the installation section. Although the UV lamp may be left on without the pump operating, there would be no appreciable ozone generation since there would be no air flow in the cell. -
Page 10: Troubleshooting Guide
Troubleshooting Guide 5.1.1 Lamp Life Remaining (days) The controller tracks the number of days of operation of the lamp and the controller. The default screen will display the total lamp life remaining (in days). The controller will count down the number of days remaining until the lamp requires changing (365 days to 1 day). - Page 11 Specifications: Standard and Validated Problem Possible Causes Solution Make sure water flows in the direction of the arrow Incorrect venturi alignment located on venturi Defective/plugged venturi Replace/clear debris from venturi Cracked/plugged tubing Repair/replace any defective tubing Ozone lamp is lit, no evidence of ozone in Incorrect check valve positioning Check to see if air flows away from generator the pool/spa...
-
Page 12: Section 8 Manufacturer's Warranty
Manufacturer’s Warranty Section 8 Manufacturer’s Warranty Our Commitment VIQUA is committed to ensuring your experience with our products and organization exceeds your expectations. We have manufactured your UV system to the highest quality standards and value you as our customer. Should you need any support, or have questions about your system, please contact our Technical Support team at 1.800.265.7246 or technicalsupport@viqua.com and we will be happy to assist you. - Page 13 425 Clair Rd. W, Guelph, Ontario, Canada N1L 1R1 t. (+1) 519.763.1032 • tf. (+1) 800.265.7246 (US and Canada only) t. (+31) 73 747 0144 (Europe only) • f. (+1) 519.763.5069 e-mail: info@viqua.com www.viqua.com...
