manual
of buona cucina italiana
...
All Cooker models from 2021
IMPORTANT:
This cooker is for domestic applications. It is NOT suitable for commercial applications of any kind. Do not install the
cooker if there is any doubt. Contact Glem Gas Australasia if you require clarification.
This cooker must be installed by a qualified & licensed installer in accordance with these instructions.
If you do not retain proof of correct installation your warranty will be voided. If your cooker is found to be incorrectly
installed you will be liable for all service costs.
If a warranty call is made and the cooker is found to be incorrectly installed you will be charged for the service call
even if the cooker is not repaired. We will not service an incorrectly installed cooker.
IF THE APPLIANCE IS DAMAGED DO NOT INSTALL. CALL 1300 307 917 FOR ASSISTANCE
ISSUE 21/13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Glem 534 Series
Summary of Contents for Glem 534 Series
- Page 1 This cooker is for domestic applications. It is NOT suitable for commercial applications of any kind. Do not install the cooker if there is any doubt. Contact Glem Gas Australasia if you require clarification. This cooker must be installed by a qualified & licensed installer in accordance with these instructions.
-
Page 2: Table Of Contents
TABLE OF CONTENTS FIRST TIME USE......................4 MOVING THE COOKER ..................5 INSTALLING THE ADJUSTABLE LEGS ..............6 INSTALLING THE ANTI TILT BRACKETS..............7 IMPORTANT WARNINGS BEFORE USING THE COOKER........8 OVEN DOOR REMOVAL AND REPLACEMENT ..........9 IDENTIFYING THE SYMBOLS ON THE CONTROL PANEL.........10 BEFORE USING FOR THE FIRST TIME..............10 OPERATION OF THE GAS COOKTOP..............11 OPERATING THE GAS OVEN................12 PRE HEATING THE GAS OVEN ................13... - Page 3 Model number details are on the inside of the compartment under the oven of located on a label next to the oven cavity above the door seal. Glem Gas & Emilia cookers are manufactured in the Glem Gas factory in Modena, Italy. They have been designed and constructed to meet the following standards:...
-
Page 4: First Time Use
DO keep the cooker clean to avoid fires WARNING - THIS COOKER IS NOT TO BE USED AS A SPACE HEATER. If the upright cooker fails to operate correctly, call Glem Gas Australasia Pty Ltd or their appointed agent for service. DO NOT ATTEMPT REPAIRS YOURSELF. -
Page 5: Moving The Cooker
MOVING THE COOKER When moving the cooker always use two people. When it is installed correctly this cooker complies with all safety requirements. However, it is manufactured from sheet metal stainless steel and care must be taken when moving the cook- er as some sharp edges and corners that are not normally intended to be touched could cause injury. -
Page 6: Installing The Adjustable Legs
INSTALLING THE ADJUSTABLE LEGS Glem Gas and Emilia cookers are delivered with adjustable height legs that need to be fitted prior to the cooker installation. On some models the legs easily screw into the underside of the cooker. On other models the legs have a new keying system where the screw on the top of the leg is inserted and then slid up the slot so it can be tightened securely. -
Page 7: Installing The Anti Tilt Brackets
INSTALLING THE ANTI TILT BRACKETS Install the legs to the cooker and adjust the height to the desired level. Make sure that this height is absolutely correct to what you require. 1. On the rear of the cooker there is a covering panel. Accurately measure the distance from the top of this panel to the floor Height H. -
Page 8: Important Warnings Before Using The Cooker
IMPORTANT INFORMATION AND WARNINGS BEFORE USING THE COOKER After the cooker is unpacked make sure that it is not damaged. If unsure please contact Glem Gas Australasia on 1300 307 917. All packaging materials should be disposed of appropriately. Cookers are hot. This cooker meets Australia Standards on external surface temperatures but the surfaces are still hot and children should not be allowed to play with the cooker at any time. -
Page 9: Oven Door Removal And Replacement
If at some time you wish to remove the oven door follow these procedures. Do not force the door on or off the cooker as you may damage the hinges. Call Glem Gas Australasia on 1300 307 917 should you require assistance. 1. Open the door fully. -
Page 10: Identifying The Symbols On The Control Panel
IDENTIFYING THE SYMBOLS ON THE CONTROL PANEL Symbols printed on the control panel identify the functions controlled by each knob and switch. The table shows the meaning of each symbol. There may be slight differences in designs. SYMBOL MEANING SYMBOL MEANING Burner / front left area Multi-function electric oven features... -
Page 11: Operation Of The Gas Cooktop
OPERATION OF THE GAS COOKTOP Gas Burners The combination of large burners, wok burners and smaller burners provides the flexibility for different cooking tasks. All burners are fitted with flame failure safety devices. This means that if the flame goes out for any reason the gas stops flowing. To ignite any burners simply depress the corresponding control knob and rotate anti clockwise to the high flame position. -
Page 12: Operating The Gas Oven
Hot water on a cloth is recommended. DETERGENTS CAN CAUSE RUST SPOTTING EVEN ON STAINLESS STEEL. Call 1300 307 917 for technical advice on cleaning or visit the Emilia and Glem Gas websites for details on maintaining stainless steel. -
Page 13: Pre Heating The Gas Oven
ELECTRIC GRILLING ELEMENT - all cookers All Emilia and Glem cookers have an electric grill within the oven compartment. Gas grills have been found to be unsuitable for Australian cooking styles where we like to grill lamb chops. -
Page 14: Electric Oven Functions
ELECTRIC OVEN FUNCTIONS - functions vary according to cooker model Multifunction Electric Oven 1. Remove the grill tray. 2. Choose a function using the selector knob for oven functions. Turn the knob to the symbol of the cooking function you wish to use. On some models the ovens only operate as fan forced and the function is automatically selected when selecting the temperature. -
Page 15: Use Of Timers
USING THE TIMERS Type 1 Electronic timer Setting the clock When the oven is first connected, or after a power failure, ‘0.00’ will flash on the display. To set the clock, push the button, then the (+) or (–) buttons. The time of day will be set after 10 seconds. -
Page 16: Suggested Shelf Positions And Cooking Times
SUGGESTED SHELF POSITIONS - TEMPERATURES & COOKING TIMES Dish Shelf Position (1 = Top Temperature Degrees C Cooking Time in minutes Cakes Static Fan oven Static Fan oven Chocolate Cake 180 - 190 35 - 40 Cream Caramel 130 - 150 30 - 35 Cup Cakes 190 - 200... -
Page 17: Oven Operation Notes
OVEN OPERATION NOTES The cooking information provided is intended purely as a guideline. Modify them to suit you experience, eating habits and personal taste. The times indicated in the table do not include preheating of the oven, which is always recom- mended. -
Page 18: Cleaning And Maintenance
The outer glass should be cleaned with a specific glass and mirror cleaner. Soapy water will work to remove stains and but may leave streaks. Do not use abrasive or aggressive cleaners on alu- minium door frame components, if in doubt contact Glem Gas for advice. 6. Removal of Side Shelf Supports - All models: The sides racks are removed by simply flexing the bottom rail off the support and unhooking at the top. -
Page 19: Installation Instructions
INSTALLATION INSTRUCTIONS - Licensed qualified installers only These instructions are for the use of a qualified installer only! Warranty is immediately voided if the cooker is not installed by a licensed gas fitter. It is the owner’s responsibility to ensure that the installer is correctly licensed to complete installation. -
Page 20: Rangehoods
RANGEHOODS Rangehoods and overhead exhaust fans must be installed according to manufacturers’ instructions. Rangehoods should be installed not lower than 650mm above the cooktop. Minimum 650mm from cooking surface to underside of rangehood Height from cooking surface to floor when installed on supplied legs: 895mm - 955mm VENTILATION REQUIREMENTS FOR GAS COOKERS A cooker should not be installed in any room which has a volume less than 5.6 cubic metres. -
Page 21: Dimension Details
REFER TO RELEVANT PAGE IN THIS MANUAL FOR INSTALLATION OF ANTI TILT BRACKETS NOTE: Glem Gas Australasia Pty Ltd and their appointed agents decline any responsibilities in the case of installation not according to these instructions. -
Page 22: Installation - Gas Connection
INSTALLATION - GAS CONNECTION These technical instructions have been prepared for use by Authorised persons. THIS APPLIANCE MUST ONLY BE INSTALLED BY AN AUTHORISED PERSON – PROOF IS REQUIRED FOR WARRANTY SERVICE CLAIMS. The cooker has been manufactured with Natural Gas injectors fitted. For use with LPG the cooker must be converted. -
Page 23: Conversion To Operate On Ulpg (Lpg)
If the flame is yellow and leaves black marks on pots and in the oven then the conversion has not been done correctly. THIS WILL VOID THE WARRANTY. ALL CONVERSIONS TO ULPG MUST BE CARRIED OUT BY A LICENSED GAS FITTER. GLEM GAS WARRANTY SERVICE WILL NOT BE MADE ON INCORRECTLY CONVERTED APPLIANCES. -
Page 24: Gas Injector Selection Table
If an igniter fails to work or a burner fails to remain alight, first remove the plug from the electrical power outlet, and then check that all the electrical connections are in place. If the cooker fails to operate correctly, call Glem Gas or their appointed agent for service. Do not attempt repairs yourself. -
Page 25: Quick Reference Fault Finding Chart
QUICK REFERENCE FAULT FINDING CHART GAS COOKTOP Burner does not stay alight after several attempts 1. Check that the burner is correctly assembled. Sometimes the parts get misaligned and that interrupts correct gas flow. 2. Make sure the gas supply is turned on. 3. -
Page 26: Product Warranty
COMMERCIAL USE - NO WARRANTY APPLIES. THIS IS A DOMESTIC APPLIANCE ONLY. Glem Gas Australasia Pty Ltd, during the period of warranty, will at its option, and subject to the terms and conditions stated below, repair or replace free of charge this appliance or any component part, which upon examination by Glem Appliances P/L. - Page 27 This warranty does not cover any glass damage or replacement of light bulbs. Consquential Damage or Economic Loss Glem Gas Australasia Pty Ltd accepts no liability pursuant to this Warranty for any cost or conse- quential damage or economic loss whether direct or indirect, to any person or property, arising from breakdown or failure of this appliance or any part thereof, and no responsibility is to be implied or accepted over and above the replacement value of the product.
-
Page 28: Installer's Final Check List
Name of installer Signature License number SERIAL NUMBER - this is a requirement to request warranty service GLEM GAS AUSTRALASIA PTY. LTD. P.O.Box 63 Blaxcell PO South Granville NSW 2142 Phone: 02 96433500 l Fax: 02 96433599 l www.glemgas.com.au Email us info@glemgas.com.au...
