Unisen Star Trac 4500 Manual

Manager mode
Hide thumbs

Advertisement

Table of Contents

After having used you
customize your treadmill by changing some of its settings.
To engage Manager Mode:
1.
Press and hold the " 0 ", " 1 " & " START " keys together. While holding the " 0 " &
" START " keys down, release the " 1 " key only.
2.
The display will beep and display Manager Mode momentarily, then UNITS will be displayed.
Once the treadmill is in Manager Mode, you may use the following keys:
INCLINE KEY: Displays the next or previous parameter.
SPEED KEYS: Allows the variable to be changed within the parameter.
ENTER KEY: Saves the value if changed in the EPROM (software).
Note: ENTER KEY must be pressed, for each value changed.
STOP KEY: Exists Manager Mode and restarts the treadmill with a "warm start."
0 – 9 KEYS: Enters new parameter values. If UNITS parameter is displayed, key 5
starts DISPLAY TEST and key 8 starts MOTOR TEST.
HEART
HEART KEY: When pressed will automatically display manufactures default value.
Note: ENTER KEY must be pressed, to save the default values if changed.
Manager Mode
Star Trac 4500 treadmill
for several workouts, you may wish to specially
3.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Star Trac 4500 and is the answer not in the manual?

Questions and answers

Related Manuals for Unisen Star Trac 4500

Summary of Contents for Unisen Star Trac 4500

  • Page 1 Manager Mode Star Trac 4500 treadmill After having used you for several workouts, you may wish to specially customize your treadmill by changing some of its settings. To engage Manager Mode: Press and hold the “ 0 ”, “ 1 ” & “ START ” keys together. While holding the “ 0 ” &...

  • Page 2: Manager Mode

    Manager Mode The following parameters may be changed using the previous keys: Parameters Lowest Highest Option 1 Option 2 Default Meaning Value Value Value UNITS English Metric English English= units of lbs., miles, hours, minutes Metric= units of kg., km, hours, minutes. MN SPD English=0.5 Metric=1.0...

  • Page 3: Maintenance Mode

    Maintenance Mode Maintenance Mode includes all of the items of Manager Mode, plus additional data that is automatically saved to properly troubleshoot in case of a problem. To engage Maintenance Mode: Press and hold the “ 0 ”, “ 2 ” & “ START ” keys together. While holding the “ 0 ” & “...
  • Page 4 Maintenance Mode The following parameters may be changed using the previous keys: Parameters Lowest Highest Option 1 Option 2 Default Meaning Value Value Value UNITS English Metric English English= units of lbs., miles, hours, minutes Metric= units of kg., km, hours, minutes. MN SPD English=0.5 Metric=1.0...
  • Page 5 Maintenance Mode Parameters Lowest Highest Option 1 Option 2 Default Meaning Value Value Value HRT CON OFF= Heart Control disable ON= Heart Control enabled CNT DN CNT DN CNT DN CNT DN= Manual POLAR POLAR countdown heart rate CONTACT CONTACT POLAR, CONTACT or BOTH BOTH...
  • Page 6 Maintenance Mode Parameters Lowest Highest Option 1 Option 2 Default Meaning Value Value Value KEY DN Number of times the Stop Switch was down or disconnected on power-up since last reset. Number of times the NO RPM display did not detect a RMP signal.
  • Page 7 Maintenance Mode Parameters Lowest Highest Option 1 Option 2 Default Meaning Value Value Value LSTRES Displays 1 = Unit was resetting to 0%. 0 = Unit finished resetting to 0% prior to the display code. LSTSSP Displays the speed prior to the display code.

  • Page 8: Motor Test Mode

    Motor Test Mode Motor Test Mode allows the treadmill to calibrate both elevation and running belt speed. Verifies RPM Sensor feedback, Drive Motor and MCB response, and verifies Elevation Motor range (count). Also burns in the motor, by way of the controls and displays of the treadmill. ***Caution*** : Do not stand on the running belt while performing these test.
  • Page 9 Calibration ***Caution*** : Do not stand on the running belt while performing these test. Automatic Speed Calibration: In this mode minimum and maximum speed is automatically calibrated. Calibration lasts less than 3 minutes; belt will be in motion during this test. Auto-calibration should be done every time MN, MX SPD &...

  • Page 10: Display Test Mode

    Display Test Mode Display Test Mode allows you to test the light-emitting diodes (LEDs), 15-segment displays, and the watchdog timer of the Display Control Panel by way of its own controls and displays. It also allows EPROM version to be displayed. To enter Display Test Mode: ***Caution*** : Do not stand on the running belt while performing these test.
