Summary of Contents for Aspar ARB-0612
- Page 1 ARB-0612 ARB-0612 Converter USB – RS 232/422/485/485-4W/TTL Manual ARB-0612_v1_01 Update date: 10/2018r. 10/2018 ARB-0612_v1_01...
-
Page 2: Table Of Contents
ARB-0612 Table of Contents Symbols & Marks............................3 General installation and safety rules......................3 1.Destination of device...........................4 2.Device parameters..........................5 2.1.Technical parameters ........................5 2.2.Description of connectors......................6 2.3.Block diagram..........................8 2.4.Dimensions ..........................8 3.Wiring..............................9 4.Instalation............................10 4.1.Installation of USB drivers......................10 4.2.Changing the COM port assignment in Windows...............11 4.3.Exploitation..........................14... -
Page 3: Symbols & Marks
ARB-0612 Symbols & Marks Advice It suggests activities that help solve the problem and / or diagnose it. Their implementation is not obligatory and does not affect the correct functioning of the device. Attention! Important information or action relevant to the correct operation of the device. -
Page 4: Destination Of Device
RS232 port signals. – The ARB-0612 converter has an internal reset signal, thus it can be used for permanent operation in applications that have the option of automatically rebuilding the serial port. -
Page 5: Device Parameters
ARB-0612 2. Device parameters Technical parameters 2.1. Technical parameters of the converter are presented in Table 2.1.1. Table 2.1.1. Technical parameters of the converter ARB-0612 Parameter Description USB 2,0. type B socket USB standard USB 3.0 supported like USB 2.0... -
Page 6: Description Of Connectors
57 x 96 x 23 mm 2.2. Description of connectors The view of the ARB-0612 converter is shown in Figure 2.2.1. A description of its connectors is presented in Table 2.2.1. A description of the function of connectors, DB9 sockets, dip-switch and LED indicators is presented in Table 2.2.2. - Page 7 ARB-0612 Tab. 2.2.1. Description of ARB-0612 converter connector type Name of the Description connector RS232 Socket DB9 RS232 RS422 Separable terminal block 2,5 mm RS485 Separable terminal block 2,5 mm USB type B connector Tab. 2.2.2. Description of the function of connectors, dip-switch and LED indicators...
-
Page 8: Block Diagram
ARB-0612 2.3. Block diagram The block diagram of the ARB-0612 converter is shown in Figure 2.3.1. Fig. 2.3.1. Block diagram of ARB-0612 2.4. Dimensions Dimensions of the ARB-0612 converter are shown in Figure 2.4.1. Fig. 2.4.1. Dimensions of the ARB-0612... -
Page 9: Wiring
ARB-0612 2.5. Versions Table 2.5.1 presents the available versions with catalog numbers. Tab. 2.5.1. Versions of the ARB-0612 Symbol Opis Nr katalogowy ARB-0612-1,5 USB – RS232/422/485/RS485-4W/TTL separation 1,5 kV, black 03-01-03-07-01-20 ARB-0612-2,5 USB – RS232/422/485/RS485-4W /TTL separation 2,5 kV, black... -
Page 10: Instalation
ARB-0612 Tab. 3.1. Description of the communication cable with full confirmation Connector 1 Connector 2 Function Rx ← Tx Tx → Rx DTR → DSR DSR ← DTR RTS → CTS CTS ← RTS 4. Instalation 4.1. Installation of USB drivers Before you start the proper operation, you must install the appropriate USB drivers on the computer with which the converter should work. -
Page 11: Changing The Com Port Assignment In Windows
Changing the COM port assignment in Windows To change the assignment of the COM port, it is necessary to start the Device Manager while the converter ARB-0612 is connected from the USB side to the computer. Menu: Start->Control Panel->System->Hardware->Device Manager Select USB Serial Port whose settings you want to change. - Page 12 ARB-0612 In the Port Settings tab, please select Advanced options ... 10/2018 ARB-0612_v1_01...
- Page 13 ARB-0612 Then select the appropriate COM port from COM Port Number. In case the selected port is already occupied by another device, the following message will appear: If you have to use this port, press YES 10/2018 ARB-0612_v1_01...
-
Page 14: Exploitation
ARB-0612 Advice. The operation system often should be restarted after changing the assignment of COM port. 4.3. Exploitation After correct installation of the drivers and connecting the converter to the USB port in the device manager should be visible COM port assigned to the converter.
