Woodland 02GRFF4118-V1 Instructions Manual

02GRFF4118-V1
Overall Dimensions:
Length = 4246mm
Width = 1512mm
Height = 3459mm
Base Dimensions:
Length = 2504mm
Width = 1525mm

Before assembly

please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
WARNING: Only for domestic use
Not suitable for children under 36 month
To be used under direct supervision of an adult
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not
supplied) including a Phillips screwdriver, Stanley knife, wood saw, step
ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
-Not suitable for children under 36 months.
-Please retain product label and instructions for future reference.
-This product has been designed to be permanently xed into the ground and
not present a hazard.
-Ensure the base is level and is built on rm ground, to prevent distortion. -We
recommend that this product is situated at least two meters away from any
structure or obstruction, including but not limited to, fencing, garages,
houses, overhanging branches, laundry lines or electrical wires.
-We highly recommend that this product is not installed on a hard surface
such as concrete, or asphalt.
-To ensure the longevity regarding the colour of any plastic objects attached
to this product we suggest, such items are positioned away from constant
direct sunlight.
-Any modi cations that are made to this product i.e. Adding another unit
should be carried out according to the manufactures instructions.
-This product is delivered pressure treated with a water based treated.

Maintenance

Maintenance should be carried out at regular intervals. If checks are not carried out the product could overturn or otherwise
become a hazard. Check at the beginning of each season and at regular intervals. Access all the nuts, bolts and screws for
tightness, tighten when required. Check all coverings for bolts and sharp edges, replace any defective parts in accordance with
the manufacturer's instructions.
Sun
To ensure the longevity regarding the colour of any plastic objects attached to this product we suggest, such items are
positioned away from constant direct sunlight.
The Woodland Trust is a charity
register in England and Wales (No.
294344) and in Scotland (No.
SCO38885).
x2
This building should be erected by
two adults
For ease of assembly, you must pilot
drill all screw holes and ensure all
screw heads are countersunk.
2mm Drill bit
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
CAUTION
Every e ort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces
of the timber. You are strongly advised
to wear gloves when working with or
handling rough sawn timer.
For Assistance Please
Contact Customer Care on
01636 880514
02GRFF4118-V1
This product has been tested to BS EN 71 standard however, we cannot accept responsibility
for your safety whilst erecting or using this product if these instructions have not been
Mercia Garden Products Limited, Sutton On Trent, Newark, Nottinghamshire, NG23 6QN
www.merciagardenproducts.co.uk
2
1
Big Base QTY 1
4 5
Medium Rail QTY 2
Small Base QTY 1
Fixing Kit
8
Small Skirting - 1320mm x 27mm x 144mm QTY 2
9
Medium Skirting - 1525mm x 27mm x 144mm QTY 1
10
Long Skirting - 1673mm x 27mm x 144mm QTY 2
11
Long Post - 2750mm x 75mmx 75mm QTY 2
12
MediumPost - 2450mm x 75mmx 75mm QTY 4
13
Back Post - 1000mm x 75mmx 75mm QTY 2
14
Short Post - 840mm x 75mmx 75mm QTY 1
followed.
3 Step QTY 1
Long Rail QTY 1
6 Short Rail 7
QTY 2
Roof
QTY 2
