Mean Well IRL-CL2-01 Manual

LED Strip Module
■ SPECIFICATION
With constant pressure DC12V driver, safe and reliable
‧
‧ Small size, light weight, easy to install
‧ Flexible, easy to bend, can be free to shape
‧
LEDHigh brightness, light angle, light a small decline,
maintenance free
‧ Change color temperature and brightness with controller
‧ Energy saving and environmental protection, long life
(normal use of up to 8~10 million hours)
‧
IP 65 Protection level
‧
2 year warranty
■ DESCRIPTION
This product is made by FPC flexible PCB as a substrate. It is made covering the PCB with
silicone tube ,has a greater protection for the LEDs，and with moisture-proof function .
Easy installation and configuration,convenient transportation,anti UV. Using 3527 "two
color" LED as light source. It can change color temperature and brightness with controller.
And that can be illuminated objects display more vivid and delicate, true color effect.
SPECIFICATION
Model
Product specifications
Color
Luminous angle
LED Package
LEDs
Luminous flux
Wavelength or Color temperature
Rated working voltage
Rated input power
Working temperature
IP level
Packing
NOTE : The luminous flux is allowed to float with + 10%.
Arrow.com.
Downloaded from
IRL-CL2-01
3000×13.6×7mm
Standard white~Warm white
O
120
3527(two color）
60LED/M
580lm/M
SW:5700-6500K WW:2900-3200K
DC12V
7.2W/M
-20℃~ +45℃
IP 65
250x220x20mm（Foil bag）
I R L - C L 2 - 0 1
■ APPLICATIONS
‧ LED Decorative lighting
‧ LEDLighting modeling
‧ Signs and signs
File Name:IRL-CL2-01 2016-01-27
