English
battery for the duration of the charging
process:
LED green - flashing quickly
Charging internal battery at maximum
rate.
LED green - flashing slowly
80% of internal battery capacity excee­
ded.
LED green - continuous light
Internal battery is charged to 90% and
then charged fully at reduced power.
LED red - flashing
General fault indication, e.g. incomplete
contact, short circuit, battery faulty.
LED red - continuous light
Battery temperature is outside the per­
mitted range.
LED orange
Power failure mode, see chapter
6.2
On/Off switch [1-2]
The ON/OFF switch [1-2] has three set­
tings:
Press once -> Switch on in lighting
mode in energy-saving stage (Stage
1: 30%)
Press twice -> Switch to max. lumi­
nosity (Stage 2: 100%)
Press three times -> switch off
6.3
Voltage monitoring
If the minimum operating voltage is not
met during lighting mode with either in­
ternal or external battery pack, the de­
vice shifts to emergency mode. It re­
duces luminosity and switches off after
2 minutes.
14
6.4
Temperature monitoring
If the device temperature does not re­
main within the specified limits, the
working light switches to emergency
mode. It reduces luminosity and then
switches off after 2 minutes.
6.5
Power failure mode
The working light has a power failure
mode. It automatically lights up the
work area in the event of a sudden pow­
er failure.
► Hold down the ON/OFF switch [1-2]
and insert the mains charging
adapter or car charging adapter in
the connector socket [1-4].
The working light turns off and the
charging indicator switches to flashing
orange (charging) or continuous orange
(fully charged). depending on the oper­
ating state.
In the event of an interruption to the ex­
6.5
.
ternal voltage supply, the working light
automatically switches on.
Switching off the mode:
► Press the ON/OFF switch [1-2]
again.
Charging indicator switches to standard
mode, see chapter
6.6
Operating with external Festool
battery pack [2A] + [2B]
The working light can operate with any
Festool battery pack from the BPC or
BPS series. When connected to the ex­
ternal Festool battery pack, the working
light only consumes power from this
battery pack.
Only compatible Festool chargers
can charge the Festool battery
pack.
6.1
.
