Summary of Contents for FIRST TUNNELS DOM
- Page 1 Overhead Irrigation Installation Guide Copyright © First Tunnels Ltd 2012.
- Page 2 Warnings General Please keep children and pets away from the work area. ■ If any holes are not to be filled for a period of time, please cover them over. ■ Keep the working area free of tools and parts. ■...
- Page 3 Overhead Irrigation Installation Guide Elbows see (dia. 2) Spray line Down tube and Sprayer see (dia. 4) End stop Tap and Pressure Regulator with Hose Connector see (dia. 3) TOOLS REQUIRED. Hacksaw, Sharp knife, Hammer and a Phillips Screwdriver. Inserting the barb fittings into the pipe can be Overhead Irrigation very tight - holding the pipe in hot water for a few seconds will help.
- Page 4 Overhead Irrigation Installation Guide Door Post Pipe System PTFE Tape Pipe Turn the elbow in the overhead spray line so that it (4007 0001) (20LDPE) is pointing in the direction of the door post you have chosen to support the pipe work. Cut a short piece of the remaining 20mm pipe at a length that spans the distance Pipe clamp Pressure...
- Page 5 PARTS Quantities depend on the length of your Polytunnel PFRK Adaptor (3054 0006) 15cm Microtube with weight Anti drip Male plug Elbow Hose Pressure (3050 0015) valve (3106 0020) (3102 2020) connection Regulator (3035 0606) (3718 0002) (4801 0172) (3174 0202) Female coupling (3061 0606)
