Ultrasonic Marine
AF300 PRO
Installation INSTRUCTIONS
SAFETY
Exercise caution when working on the vessel, especially in confined spaces or
when working near the bottom or "bilge" area of the boat.
Make sure the work area is properly ventilated prior to beginning installation.
These areas may contain residual fuel or fumes that can be harmful when inhaled.
Extreme vigilance should be used in these spaces especially when working alone.
A basic understanding of drilling, sanding and the vessel's electrical system are needed for
the installation work required.
The equipment must be installed in accordance with these instructions.
Failure to do so could result in poor product performance, personal injury and/or damage to the vessel.
The success and performance of the system depends on a quality installation.
CLEANING OF THE HULL
It is important to clean the hull close to the time of the installation.
Barnacles and mussels, are not killed by this system.
This system kills the micro-organisms at the bottom of the food chain.
Algae and other vegetation are killed and consequently the barnacles & mussels that feed on them
will not attach to the hull.
ITEMS SUPPLIED
Included in this box:
Control Box Unit AF301C
Transducers from 1 to 4 AF301T as ordered
Transducer cables 1 RG6 coaxial cable for each transducer ordered 5m or10m
Two cable glands 12mm
One pack Devcon adhesive
1
Advertisement
Table of Contents
Summary of Contents for Citadel AF300 PRO
- Page 1 Ultrasonic Marine AF300 PRO INSTALLATION INSTRUCTIONS SAFETY Exercise caution when working on the vessel, especially in confined spaces or when working near the bottom or “bilge” area of the boat. Make sure the work area is properly ventilated prior to beginning installation.
- Page 2 Options if ordered: AC shore power supply LPF60-30 INSTALLATION Planning & Positioning Before beginning work it is important to plan out the installation, taking note of: The vessels hull design. Location for the transducers and control box. Cable runs and power supply. Location of Control Box The control box is sealed and water resistant so can be installed in the most convenient location, preferably above the water line.
- Page 3 A reasonably flat area of the hull should be chosen for transducer locations and the surface should be well prepared before mounting (see preparation and mounting instructions below). Typical Position: Installing the Control Box The control box is splash proof to IP66 and can be installed in any convenient location, preferably above the water line.
- Page 4 Mounting the Transducer to the Hull When mounting transducers, the goal is to make 100% contact between the transducer and the hull. The better you prepare the surface, the better the result. To make a neat and tidy installation, proceed as follows:- 1.
- Page 5 Installed transducer Running the Transducer Cables Having mounted the transducers and control box, the cables can now be connected to the units. Up to four transducers can be connected to a single control box. Maximum 30m cable length per transducer. Testing and Operation With the control box closed, connect and turn on the power supply.
- Page 6 Technical Support If your system is not working and you are unable to resolve the problem, Please contact us at vic@citadelproducts.co.uk for help. Issue 2.6 December 2017...
