QMT-1B Operations Manual
Mark plainly with indelible ink all mailing documents as follows:
GOODS RETURNED FOR REPAIR
Mark all sides of the package:
FRAGILE - ELECTRONIC EQUIPMENT
Inspect the package prior to shipment to be sure it is properly marked and securely wrapped.

2.4 Installation Overview

NOTE: QMT-1B installation requires knowledge of Ethernet network
fundamentals as well as a basic understanding of Internet Protocol (IP). As with any
network-connected device, improperly configuring and installing the QMT-1B
could disrupt proper network operation. Please seek the assistance of your network
administrator or other knowledgeable person if you are unsure about how your
network is configured.
Five steps are needed to properly install the QMT-1B. These steps are:
1. Determine the IP address, subnet mask, and (if applicable) the gateway address for
the unit. You may have to contact the network administrator for your organization to
obtain this information.
2. Provide the proper primary power for the unit.
3. Interconnect the unit with the communications system via the QMT-1B's rear panel
connectors. J6 provides the audio and control lines necessary to interface the QMT-
1B to your voting receiver and any system transmitter. J4 uses a standard RJ-45
Ethernet Patch Cable (non-crossover) to connect to the network.
4. Configure the unit's operational parameters per the Configuration section of this
manual.
5. Set the input and output audio levels per Section 3.2.
The QMT-1B is then ready to use.
