This manual covers units shipped June 12, 2018 to date.
Language: English (Hazards: English, French)
TS-5000 Trailer Stabilizer
Installation/Service/Owner's Manual
TS-5000 7
WARRANTY 12
Publication: AMEN00180 2019-04-05
4
8
Model: TS-5000
Manual Part #: 54450058
Advertisement
Table of Contents
Summary of Contents for RITE-HITE TS‑5000
-
Page 1: Table Of Contents
TS‑5000 Trailer Stabilizer Installation/Service/Owner's Manual This manual covers units shipped June 12, 2018 to date. NOTICE TO USER 2 SAFETY 2 FEATURES 3 INSTALLATION... -
Page 2: Notice To User 2
TS‑5000 Trailer Stabilizer Rite‑Hite ® Installation/Service/Owner’s Manual NOTICE TO USER SAFETY Safety Identifications Thank you for purchasing a Rite‑Hite product ® The TS‑5000 Trailer Stabilizer is a heavy duty trailer DANGER support that provides additional safety to a parked trailer resting on its landing gear Indicates a hazardous situation which, if not Capacity: 140,000lbs [63500kg]... -
Page 3: Features 3
Rite‑Hite TS‑5000 Trailer Stabilizer ® Installation/ Service/Owner’s Manual FEATURES Stabilizer Jack Pads Stabilizer Guide Brackets/Positioning Handles C Stabilizer Carriage Wheels D Height Adjustment Crank Flag Assembly (Optional) E1 Clamping Bracket E2 Lock Collar E3 Knob Figure 1 Publication: AMEN00180 2019-04-05... -
Page 4: Installation
TS‑5000 Trailer Stabilizer Rite‑Hite ® Installation/Service/Owner’s Manual INSTALLATION Preparation Stabilizer Guide Bracket/Positioning Handles Before assembling, verify all components were received 1 Align holes on handle flange (A) with holes in the top Notify your authorized Rite‑Hite representative if parts are plate (B) Place stabilizer guide bracket/positioning missing or damaged handle (C) perpendicular to the top plate... -
Page 5: Operation
Rite‑Hite TS‑5000 Trailer Stabilizer ® Installation/ Service/Owner’s Manual OPERATION Position TS-5000 WARNING / AVERTISSEMENT 1 Confirm vehicle restraint and/or wheel chocks (supplied by others) are securely in position DO NOT put arms or hands between the 2 Adjust height of trailer’s landing gear, if necessary trailer and the TS-5000 Trailer Stabilizer. -
Page 6: Trailer Height Adjustment
TS‑5000 Trailer Stabilizer Rite‑Hite ® Installation/Service/Owner’s Manual OPERATION Trailer Height Adjustment Required Tools 24mm wrench 24mm socket w/ ratchet or impact driver The working range of the TS‑5000 can be field adjusted to fit under shorter trailers, or raised for taller trailers. Select the tallest working range (A) to accommodate most trailers and minimize crank turns needed for snug placement and removal from under the trailer... -
Page 7: Parts
Rite‑Hite TS‑5000 Trailer Stabilizer ® Installation/ Service/Owner’s Manual PARTS TS-5000 <1110A006.PDF:5> DESCRIPTION PART # DESCRIPTION PART # PLATE,WELDMENT,TOP,TS5000 65000968 JACK,DRIVE,TS5000 53390001 PLATE,WELDMENT,TOP,TS5000 65000968 JACK,DRIVEN,TS5000 53390002 JACK,DRIVE,TS5000 53390001 CRANK,ASSY,TS5000 19600006 GRIP,PVC,BLK 55150364 JACK,DRIVEN,TS5000 53390002 SCR,HHMS,M16-2X30,CLASS8.8,ZNC 67930058 NUT,HEX,M16-2,CLASS 8,ZNC 55680011 CRANK,ASSY,TS5000 19600006 WSHR,FLAT,5/8,SAE,ZNC 74160004 LABEL,REFLECTOR,RED,2"X3.5"... -
Page 8: Carriage Assembly
TS‑5000 Trailer Stabilizer Rite‑Hite ® Installation/Service/Owner’s Manual PARTS Carriage Assembly DESCRIPTION PART # – – CARRIAGE, ASSY,TS5000 55150362 CARRIAGE,WELDMENT,TS5000 55150363 WHEEL,ASSY,13IN,SWVL,TS5000 75550022 WHEEL,ASSY,13IN,FIXED,TS5000 75550021 SCR,HHMS,3/8‑16X1,ZNC 67880002 NUT,HEX,NYLCK,3/8‑16,Z5 55630005 WSHR,FLAT,3/8X1X063,ZNC 74130001 <TS5000 OWRS PARTS CARRIAGE REV A.PDF> ITEM PART NUMBER DESCRIPTION 55150363 CARRIAGE,WELDMENT,TS5000 Communication Flag... - Page 9 Rite‑Hite TS‑5000 Trailer Stabilizer ® Installation/ Service/Owner’s Manual Publication: AMEN00180 2019-04-05...
- Page 10 TS‑5000 Trailer Stabilizer Rite‑Hite ® Installation/Service/Owner’s Manual Publication: AMEN00180 2019-04-05...
- Page 11 Rite‑Hite TS‑5000 Trailer Stabilizer ® Installation/ Service/Owner’s Manual Publication: AMEN00180 2019-04-05...
- Page 12 GLOBAL SALES & SERVICE Representatives in All Major Cities RITE-HITE WORLD HEADQUARTERS RITE-HITE CHINA RITE-HITE LATIN AMERICA...
