HT Series Specifications Technical Data
Power:
Voltage:
Heating Element:
Service Life:
Surface Temperature:
Power Attenuation:
Energy Transfer Ratio:
1 – Measure spacing on back of mirror and drill holes into the wall. Make
sure the positions are correct, double check for differences on the heater.
2 – Insert the screws into the plastic expansion tube.
3 – Insert screws into holes.
4 – Mount the panel onto the 4 screws.
Far Infrared Carbon
Crystal Heating Panel
Front
Installation
User Manual
Back
220W-1200W
220V-240V
Carbon Crystal Heating Film
100,000 hours
80°C-90°C
3%, good for 5-10 years
98%
Advertisement
Table of Contents
Summary of Contents for TGM HT Series
- Page 1 Far Infrared Carbon Crystal Heating Panel User Manual HT Series Specifications Technical Data Front Back Power: 220W-1200W Voltage: 220V-240V Heating Element: Carbon Crystal Heating Film Service Life: 100,000 hours Surface Temperature: 80°C-90°C Power Attenuation: 3%, good for 5-10 years Energy Transfer Ratio: Installation 1 –...
- Page 2 WARNING Do not cover the heater. • To avoid the possibility of burns the following people should be more • careful when using the heaters: Infants & children, people with sensitive skin, the elderly, people who are intoxicated or people who take sleeping or other medication that makes you drowsy.
