Kleenmaid SMC4530 Instructions For Use And Warranty Details

Steam microwave convection oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

cooking collection
Instructions for use and warranty details
Steam Microwave
Convection Oven
Model No.: SMC4530

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMC4530 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kleenmaid SMC4530

  • Page 1 Instructions for use and warranty details Steam Microwave Convection Oven Model No.: SMC4530...
  • Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.

  • Page 3: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY SPECIFICATIONS IMPORTANT SAFETY INSTRUCTION EARTHING INSTALLATION TO REDUCE THE RISK OF INJURY TO PERSONS CLEANING UTENSILS SETTING UP YOUR OVEN IMPORTANT INFORMATION ABOUT INSTALLATION BEFORE FIRST USE 13-30 OPERATING INSTRUCTIONS TROUBLE SHOOTING KLEENMAID WARRANTY...

  • Page 4: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    It is hazardous for anyone other than a qualified person to carry out any service or repair operation that involves the removal of the cover which gives protection against exposure to microwave energy. Specifications Model: SMC4530 Rated Voltage: 230-240V, 50Hz Rated Input Power (Microwave): 1550W...

  • Page 5: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 13. Install or locate this oven only in 1.
  • Page 6 23. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. 24. Children should be supervised to ensure that they do not play with the appliance. 25. This appliance is not intended to be operated by means of an external timer or separate remote-control system.

  • Page 7: Earthing Installation To Reduce The Risk Of Injury To Persons

    Earthing Installation to Reduce the Risk of Injury to Persons DANGER 2)The extension cord must be an earthed- type 3-wire cord. Electric Shock Hazard 3)The long cord should be arranged so that Touching some of the internal components it will not drape over the counter top or can cause serious personal injury or death.

  • Page 8: Utensils

    UTENSILS See the instructions below on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below. Utensil Test: 1.

  • Page 9: Setting Up Your Oven

    Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing.

  • Page 10: Important Information About Installation

    Before making preparations for or commencing installation, the installer should refer to the current online version of the User Manual, which is available on the Kleenmaid website (see back cover for details). The appliance is fitted with a plug and must only be connected to a properly •...
  • Page 11 Built-in Only • This appliance is only intended to be fully fitted in a kitchen. This appliance is not designed to be used as a tabletop appliance or inside a cupboard. • The fitted cabinet must not have a back wall behind the appliance. •...
  • Page 12 Side view (not to scale) Fig. 2 Fig. 1 Fig. 3 Place the oven into the niche ensuring that it is centred. Do not kink the connecting cable. The setback from the glass fascia to the niche front should be 20mm (see Fig. 2 above). Once the oven is correctly positioned open the door and fasten the oven with the screws supplied (see Fig.

  • Page 13: Before First Use

    BEFORE FIRST USE Initial cleaning and heating Remove he microwave oven For more information see the "CLEANING" on p Before using the appliance for the first time: ￭ Remove all accessories ￭ ￭ New appliances typically emit an odour when first used. Before using the electrical appliance to cook food, follow the steps below to help banish any odours:- 1.
  • Page 14 SETTING COOKING FUNCTIONS Note: Pressing " " allows you to choose Microwave, Grill, Fan Forced Convection, Fan Assisted Grill, Fan Forced+Microwave, Fan Forced+Grill+Microwave, Grill +Microwave functions. 1.Clock Setting When the microwave oven is first powered on, "00:00" will blink, and the beeper will sound once.
  • Page 15 The table below indicates the recommended power levels for various foods and cooking processes. Power level Food 900 W - Boiling water, reheating - Cooking chicken, fish, vegetables 700 W - Reheating - Cooking mushrooms, shell fish - Cooking dishes containing eggs and cheese 450 W - Cooking rice, soup 300 W...
  • Page 16 4. Fan Assisted Grill Cooking 1) Press " ", "01:00" displays and the microwave icon appears. " twice to select Fan Assisted Grill mode. The default Press"" " or " temperature is 180 degrees. Press " " to enter the temperature selection mode. 4) Press "...
  • Page 17 6. Fan Forced + Microwave Combi Cooking 1) Press " ", "01:00" displays and the microwave icon appears. 2) Press" " or " " four times to select the Fan Forced + Microwave combi mode. 3) Press " " to enter the temperature selection mode. The default temperature is 180 degrees.
  • Page 18 8. Grill + Microwave Combi Cooking 1) Press " " ", "01:00" displays and the microwave icon appears. " six times to select the Grill+Microwave combi mode. 2) Press" " or " 3) Press " " to enter the grill level selection mode. 4) Press"...
  • Page 19 10. Defrost 1) In standby mode, press" "button once to select defrost mode.The display" " appears as auto defrost mode. d01, initial weight, cooking time and cooking signs display. 2) Press " ", to confirm the selected defrost mode and enter the defrost weight selection state.
  • Page 20 13. Microwave+Steam Cooking 1) In standby mode, press " " ", to enter the steam mode, time displays by default 10:00. Press " " again to select the Microwave+Steam mode. The icon is displayed, then the default power 300W is displayed. 2) Press "...
  • Page 21 14. Convection+Steam Cooking 1) In standby mode, press " " ", enter the steam mode, time displays by default 10:00. Press " " twice to select Convection+Steam function and the icon displays. The default temperature is 180 degrees. 2 ) Press " "...
  • Page 22 Error codes - Steam Cooking The following error codes may occur during steam functions: E-06: Water reservoir is not properly closed. E-05: There may be irregularities in the water system. Contact an authorised repairer to check this system including: Add water here 1-The water sensor 2-The water pipe 3-The water pump...
  • Page 23 16. Child Safety Lock Lock: In standby mode, press " " for 3 seconds, there will be a long "beep" denoting the locked state and " " indicator displays. Unlock : In locked mode, press " " for 3 seconds, there will be a long "beep"...
  • Page 24 18. Steam Auto Cooking Menu AUTO-MENU DISPLAY WEIGHT POWER Steam100℃ Trout +300W Steam100℃ Salmon Fillet +100W Steam100℃ Pike/perch +300W fillet Prawns Steam100℃ Steam100℃ Halibut Fillet +300W Cockles Steam100℃+100W Steam100℃ Cod Fillet +300W Steam100℃ Herring +300W Steam100℃ Tuna Fillet +100W...
  • Page 25 Steam100℃ Crab +300W Steam100℃+300W Chicken Leg Chicken Steam100℃ +300W Breast Steam100℃ Meatball +300W Turkey Steam100℃ schnitzel +300W Steam100℃ Pork Fillet, +300W whole Steam100℃ Sausages +100W Eggs, runny Steam100℃ Eggs, hard Steam100℃ Eggs, soft Steam100℃ 200g+400mL Brown Rice + Steam100℃+ 450W/ water Steam100℃+ 300W 400g+800mL...
  • Page 26 Steam100℃+300W Eggplant/ Aubergine Steam100℃ +300W Beans Steam100℃ Broccoli Steam100℃ +300W Cauliflower Steam100℃ +300W Peas Potatoes with skin Steam100℃+ 300W (whole,small) Potatoes with skin Steam100℃+ 300W (whole,large) Potatoes without skin Steam100℃+ 300W (pieces) Steam100℃+300W Carrots Steam100℃+300W Corn Cobs...
  • Page 27 Steam100℃ Capsicum Steam100℃ Hot Peppers Steam100℃+300W Mushrooms Steam100℃+300W Leeks Steam100℃ Brussels Sprouts Steam100℃+300W Celery Steam100℃+100W Asparagus Steam100℃+300W Spinach Steam100℃+300W Courgette/ Zucchini...
  • Page 28 19. Non Steam Auto Cooking Menu DISP AUTO-MENU WEIGHT POWER 450W 450W Melt Chocolate 450W 450W 450W Melt Butter 450W 100W+220℃ 100W+220℃ Sweet Potato 100W+220℃ 100W+220℃ Chicken Whole 1000 100W+220℃ 1200 100W+220℃ 450W+220℃ 450W+220℃ 450W+220℃ 450W+220℃ Chicken Leg 450W+220℃ 450W+220℃ 450W+220℃...
  • Page 29 450W+220℃ 450W+220℃ 450W+220℃ 450W+220℃ Roast Pork 450W+220℃ 450W+220℃ 1000 450W+220℃ 100W+220℃ 100W+220℃ 100W+220℃ Chicken Kebabs 100W+220℃ 100W+220℃ Pre-heat/220℃ Pre-heat/220℃ Shrimp Pre-heat/220℃ 100W+220℃ 100W+220℃ 100W+220℃ Beef Steak 100W+220℃ 100W+220℃ 100W+220℃ 1000 100W+220℃ 100W+220℃ Barbecued 100W+220℃ Spare 100W+220℃ Chocolate Pre-heat/180℃ Cookies Pre-heat/200℃ Lemon Cookies Pre-heat/220℃...
  • Page 30 (+800ml cold water) 700W Pasta (+1000ml cold water) (+1200ml cold water) 900W Soup Pizza 900W Muffin 900W 50+500ml water 100+1000ml water Oatmeal 900W/450W 150+1500ml water Baked Apple 700W Sandwich 900W Popcorn 900W Fudge Brownies 100W+180℃ Bread Grill Level3 Chicken Nuggets 100W+220℃...
  • Page 31 Peanut Chocolate Pre-heat/180℃ Cookies Hamburger 100W+220℃ Pre-heat/180℃ Muffin (70g*12)

  • Page 32: Trouble Shooting

    TROUBLE SHOOTING Microwave oven interfering with TV reception In low power microwave cooking the oven light may become dim. This is normal. Steam may be released from food during cooking. Most will escape through vents but some may accumulate on cool places like the oven door.

  • Page 33: Kleenmaid Warranty

    Australian Consumer Law. c. In the event that a request for repair is made against this Kleenmaid Warranty where the serial number for the Product cannot be verified or you cannot produce for verification a proof of purchase for the Product (including but not limited to the original invoice), the repairer will not carry out any repairs on the Product and you will be charged a service call-out fee.
  • Page 34 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
  • Page 35 This page intentionally left blank.
  • Page 36 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
