Summary of Contents for CARLO GAVAZZI NA12D
- Page 1 SAFETY MODULE SAFETY MODULE NA12D NA12D User manual User manual...
- Page 2 Index Index 1. INTRODUCTION .......3 2. FUNCTION ........3 3.
- Page 3 NA12D • To avoid interference due to cou- safety module. The instructions pling, run the limit switches con-...
- Page 4 START) or a short-circuit (for S21-S22 terminals. automatic START); the second The NA12D must be connected to one can be employed only con- two N.O. switches/contacts S1 necting between the X1-X2 termi- and S2, which are operated (con- nals a N.O.
- Page 5 N.O. devices connected to the inputs START pushbutton is pushed. With and to the outputs of the NA12D Automatic START configuration, safety module. Check also the cor- the safety outputs close as soon as rect wiring of all the devices (See both S1 &...
- Page 6 STEP 4 (This step must operate INSPECTIONS AND first on one input contact, then on MAINTENANCE the other one) Repeat the proce- The integrity of the safety module dure from STEP 2, opening and and of all the connected devices then closing only one input con- must checked...
- Page 7 TECHNICAL DATA ELECTRICAL CHARACTERISTICS 24 Vac -15/+10% 50 ÷ 60Hz, Power supply voltage 24 Vdc -15/+10% Current consumption 70 mA (@ 24Vdc, without load) Power consumption max 5 VA Input 2 N.O. Voltage-free Safety Category (EN 954-1) E-STOP Category (EN 60204-1) Short-Circuit Protection Internal PTC SAFETY OUTPUTS...
- Page 8 Torque setting on connection 0.5 Nm terminals Dimensions 99 x 22.5 x 115 mm Weight 200g CARLO GAVAZZI si riserva il diritto di apportare modifiche o miglioramenti senza preavviso CARLO GAVAZZI reserves the right to make improvements or changes without prior notice...
