Summary of Contents for roco Lokmaus 2

  • Page 1: Table Of Contents

    Content (English Text) Features of the Lokmaus ® 2 Plug and play – wiring the Lokmaus ® 2 The RocoNet Handling of the Lokmaus ® 2 Taking a loco from an other Lokmaus ® 2 The Smart-Search Function The Master - Slave System Function that are only available at the ‘Master Lokmaus ®...
  • Page 2: Features Of The Lokmaus ® 2

    RocoNet is called the connection between the amplifier and the Lokmaus ® 2 that represents the second generation of the Lokmaus, the Digital System by ROCO. There must be connected one Lokmaus ® 2 to the ‘master’ connector of the amplifier. This Lokmaus ® 2 gets automatically the function of the central...
  • Page 3: Handling Of The Lokmaus ® 2

    If it is necessary to have an adaptor-plug please take a look at ‘www.roco.co.at/digital’ if there is a plug offered by ROCO. ATTENTION! If you make your own adaptor-plug you must strictly avoid short circuits! Pay attention to the correct wiring! Otherwise you can damage the devices.
  • Page 4: Taking A Loco From An Other Lokmaus ® 2

    To operate those additional functions the loco must be equipped with a special deoder or an additional function decoder. For the future it is ROCO’s plan to raise the playworth of the railroad by adding functions to locos and cars. So these functions already have been integrated into the Lokmaus ®...
  • Page 5: The Master - Slave System

    The Master - Slave system In the new ROCO Lokmaus ® 2 digital system every Lokmaus ® 2 can be the Master (central unit). A Lok- maus ® 2 plugged to the ‘master’ connector of the amplifier automatically becomes the master. The mas - ter coordinates the complete system and generates the track-signal.
  • Page 6: Programming Modes And Programming Procedures Of The Lokmaus ® 2

    An overview for the ROCO decoders and the decoders of other manufacturers that we have tested you find in the compatibility-list on page 33. There you find a list of the facilities of the ROCO decoders too.
  • Page 7: Profressional Programming Procedure

    IMPORTANT: The actual amplifier 10761 is not able to read out the decoder, therefore you get an er- ror-message in the display of the Lokmaus ® 2. For the future ROCO plans to develop a device that is more powerful and supports to read the decoder. If you use the Lokmaus ® 2 together with a LZ100 and LV101 by Lenz then you can read out the loco decoder already today.
  • Page 8: Programming The Digital Turnout Drive 42624

    It differs from one decoder-typ to the other. For the ROCO loco decoders you find a table with their fea - tures on page 34.
  • Page 9: Using One Or More Boosters 10762

    42611, by using sectionated track or simply cut the profiles of the tracks on both si- des. Install a feeding track ROCO 42517 or use the wire 22217 to feed the section. Connect it to the track out plug of the booster. The booster gets its energy via the two-ople black wire from the transfor- mer 10718.
  • Page 10: Compatibility Of Control Devices And Decoders

    The old ‘digital is cool’ system by ROCO (Lokmaus 10750 and central unit 10751) can be used – with its old facilities – together with the new system. In order to connect it to the new system you need the tans- lator modul 10759 that is plugged to the RocoNet as any Lokmaus ®...
  • Page 11: Combination Of Digital And Non-Digital Parts Of A Layout

    Lokmaus ® 2. The function is read-only. You can’t change it. CC – the software-version of the RocoNet is displayed. The display tells you the version of the Roco - Net. The function is read-only. You can’t change it.
  • Page 12: Installing The Separator 10768

    The digital and the DC-section of your layout must be strictly separated from each other. In order to be sure that it is insulated separate the sections by using the ROCO plastic connectors 42611 on both sides of the track or cut both track profiles (see fig. 6 on page 38).
  • Page 13: Trouble-Shooting

    Trouble-shooting Headlights don’t work correctly speed step mode of the Lokmaus ® 2 and the loco-decoder don’t flashes or can’t be switched on match. The speed step mode for the address of the loco at the Lokmaus ® 2 is wrong or the CV29 is programmed faulty. or off How to define the speed step mode see page 23 How to program the CV29 you find on page 25...
  • Page 14: Error Messages

    Error Messages error-code E1 A short circuit on the programming track has occured. Please make sure that the loco is not derailed and that there’s no fault in the wiring of the programming track. A newly converted loco may have a faulty wired decoder. error-code E2 Trying to read the decoder didn’t have a result because the loco didn’t answer.
  • Page 15: Compatibility Of Loco Decoders

    Compatibility of loco decoders Manufacturer Code Comment Roco 10740 — — 10741 — — 10742 10745 10771 CV01 CV01 Köf — — — — from starting-sets 41100 and — — — — 41101 not programmable — CV01 — CV01 headlight-decoder ICE...
  • Page 16 (nicht bei 10740) 00 - 07 Fahrstufen, Fahrtrichtung, etc. nicht bei 10740 siehe Seite 9 10741 nur 14 Fahrstufen Features of the ROCO / LENZ loco decoders range feature restrictions 01 - 99 loco address not for ICE / 215 from 41100...
