PMI SB5100 Owner's Manual

OWNER'S GUIDE
USE AND CARE MANUAL
MODEL SB5100
Congratulations: You have purchased a product of superior
performance and design, which will give the best service when
properly operated and maintained. This cooler is intended to be
used as a convenient roll-around spot cooler.
This guide was designed to provide you with the information
needed to prepare the unit for roll-around spot-cooling. It also
contains information on how to safely operate, inspect, maintain
and troubleshoot your Shop Blaster evaporative air cooler.
The first section contains instructions to prepare your cooler for
roll-around portable service. The second section, Maintenance,
contains operational and maintenance instructions to aid in
keeping your unit in good working order, while Troubleshooting
includes information to help diagnose and repair commonly
encountered problems.
READ AND SAVE THESE IMPORTANT SAFETY
INSTRUCTIONS
Read all instructions carefully before installation
• This cooler must be connected to 120 volt AC, 60 Hz (cycle)
power only. NOTE: Improper voltage will void the pump and/
or motor warranties and may cause serious personal injury or
property damage.
• This cooler is NOT intended for outdoor use.
• Do NOT exceed a maximum weight of 50 pounds per drawer.
• Do NOT exceed a maximum total weight of 600 pounds
including water and toolbox contents.
• Do NOT have more than one drawer open at a time, the unit may
tip.
• When moving this unit ensure the water has been emptied and
all drawers are closed and locked.
• Ensure the brakes on the two rear casters are engaged when the
unit is not being moved.
• This cooler must be plugged into a GFCI protected receptacle,
which has been properly installed in accordance with all local and
national codes. If you are not sure that the receptacle is GFCI
protected, consult with a qualified electrician.
• This cooler is equipped with a power cord having an
equipment grounding conductor and grounding plug. Do NOT
attempt to defeat this safety device by removing the grounding
pin.
• Do NOT step on or rollover power cord with heavy or sharp
objects. Do NOT operate if plug or cord is damaged in any way. If
the unit is damaged or malfunctions, do NOT continue to operate
it.
01-999-2534
Safety
Operation
Maintenance
Trouble Shooting
Parts Replacement
READ THIS FIRST!
WARNING
- TO REDUCE THE RISK
OF FIRE, ELECTRIC SHOCK OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING
• Always disconnect electrical power to unit before
attempting to work on or service your cooler.
• Do NOT operate with evaporative pad removed.
• Do NOT use this unit as a step stool or ladder. Do not sit or
stand on this unit. Serious risk of personal injury or
property damage may occur.
• Do NOT operate this cooler (fan motor) with any solid-state
speed control device.
• Do NOT operate with pad frame removed. Do NOT
place fingers or any other objects inside the fan section.
Serious risk of personal injury or property damage may occur.
• Never wash your cooler cabinet with a garden hose, water
may harm motor and pump.
• Use of extension cord is not recommended.
NOTE:
• Do not use indoors on carpet or wood floor. Unit may leak
water and could damage flooring or create a slip hazard.
• Do not locate or operate cooler near exhaust or vent pipes
as odors or fumes may be drawn into unit.
• Your warranty does not cover shipping damage. Report all
shipping damage at once to store making the delivery.
• For future reference, record the serial number and
purchase date of your evaporative cooler here:
Serial #____________________________________________
Purchase Date:_____________________________________
Place of Purchase:___________________________________
Page 1
