IBC SOLAR SolControl Pro Manual

Device connection plans

Advertisement

Device connection plans
IBC SolControl
Version: 20151210
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SolControl Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for IBC SOLAR SolControl Pro

  • Page 1 Device connection plans IBC SolControl Version: 20151210...
  • Page 2 Copyright Copyright for this manual remains with the manufacturer. No part of this manual may be reproduced or edited, duplicated or distributed using electronic systems, without written permission. Compensation shall be payable in the event of any copyright infringements. All brand names mentioned in this manual are the property of their respective manufacturers and are hereby acknowledged.
  • Page 3: Table Of Contents

    Contents Notes on this operating manual....................... 4 Safety instructions for operation ...................... 4 Intended use .......................... 4 Personnel ..........................4 Overview of interfaces ........................5 Cabling ............................6 RS485 and RS232/422 ......................6 Sensors ............................9 Irradiance sensors ......................... 9 Pyranometer ........................
  • Page 4: Notes On This Operating Manual

    1 Notes on this operating manual This manual is a key aid when it comes to ensuring proper operation of the device. It contains important information and safety notes to help you use the devices correctly, economically and in the intended manner.
  • Page 5: Overview Of Interfaces

    3 Overview of interfaces overview of interfaces Analog inputs (DI1–DI4) Ethernet Reset button RS485 Digital inputs (DI1–DI4) RS232/422 Power supply (10) Digital output (DO1) (110 V… 230 V AC) RJ45 phone socket (PSTN) (11) Switch between RS232 / RS422 Can also be operated as RS485 Power supply for additional Modbus devices (24 V DC)
  • Page 6: Cabling

    4 Cabling 4.1 RS485 and RS232/422 The two RS485 and RS232/422 interfaces are used to query information recorded on various bus devices such as inverters, power quality analyzers, etc. The RS232/422 interface can also be used as an RS485 interface. In order to do this the interface has to be operated in RS422 mode (for this, please refer to the manual of your IBC-SolControl data logger).
  • Page 7 Daisy chain If you want to connect more than one device to the bus, you must daisy-chain the connection. This means that different devices can only be queried jointly if they use the same communication protocol and the same serial communication parameters (baud rate, data bits, parity, stop bits). The first and last device on the bus must be terminated with a resistor.
  • Page 8 Star wiring Another possible way of operating multiple devices on the RS485 bus is called star wiring. In this wiring variant, a HUB 6 Port RS485 S is used to seperate the bus into a serveral bus strings. To connect the HUB 6 Port RS485 S to the IBC SolControl, please use a Connect Universal RS cable.
  • Page 9: Sensors

    5 Sensors 5.1 Irradiance sensors SI-12-TC, SI-12-TC-T Connection Wire color Black Ground Power supply (12… 24 V DC) Brown Temperature signal (0… 10 V / 0… 20 mA / 12.28… 20 mA) Orange Irradiance signal (0… 10 V) Configuration data Sensor Measurement Input...
  • Page 10 IBC SolControl Sensor connection...
  • Page 11 SI-12-TC-LC Connection Wire color Black Ground Power supply (12… 24 V DC) Orange Irradiance signal (0… 10 V) Configuration data Sensor Measurement Input Unit Gradient Offset SI-12-TC-T Irradiance Analog 0… 10 V...
  • Page 12 IBC SolControl Sensor connection...
  • Page 13 SI-420-TC, SI-420-TC-T Connection Wire color Black Ground Power supply (12… 24 V DC) Brown Temperature signal (12.28… 20 mA) Orange Irradiance signal (4… 20 mA) Configuration data Sensor Measurement Input Unit Gradient Offset Irradiance Analog 4… 20 mA -300 SI-420-TC-T Temperature Analog 12.28…...
  • Page 14 IBC SolControl Sensor connection...
  • Page 15 SI-RS485-TC-T (Modbus RTU) Connection Wire color Black Ground Power supply (12… 24 V DC) Brown RS485 Modbus interface A (+) Orange RS485 Modbus interface B (-) § Set the bus address on the sensor (see sensor documentation). § If the device is the last one on the RS485 bus, terminate the bus with a 120 Ω terminating resistor.
  • Page 16 IBC SolControl Sensor connection...
  • Page 17 Si-RS485-TC-T V2 (Modbus RTU) Connection Wire color Black Ground Power supply (12… 24 V DC) Brown RS485 Modbus interface A (+) Orange RS485 Modbus interface B (-) § Set the bus address on the sensor (see sensor documentation). § If the device is the last one on the RS485 bus, terminate the bus with a 120 Ω terminating resistor.
  • Page 18 IBC SolControl Sensor connection...
  • Page 19: Pyranometer

    5.2 Pyranometer Kipp & Zonen SMP10 / SMP11 (analog interface) Connection Wire color Black Ground White Power supply (5… 30 V DC) Brown Irradiance signal GND Green Irradiance signal (4… 20 mA) Configuration data Measurement Input Unit Gradient Offset Irradiance on horizontal plane Analog 4…...
  • Page 20 IBC SolControl Sensor connection...
  • Page 21 Kipp & Zonen SMP10 / SMP11 (Modbus RTU) Connection Wire color Black Ground White Power supply (5… 30 V DC) Gray RS485 Modbus interface B (-) Yellow RS485 Modbus interface A (+) Blue RS485 Modbus interface GND § Set the bus address on the sensor (see sensor documentation).
  • Page 22 IBC SolControl Sensor connection...
  • Page 23 Kipp & Zonen CMP11 with AMPBOX Connection Wire color Blue Power supply + 24 V DC Yellow Analog output 4 mA to 20 mA Configuration data Measurement Input Unit Gradient Offset Irradiance on horizontal plane Analog 4… 20 mA -400 Irradiance on module plane Analog 4…...
  • Page 24 IBC SolControl Sensor connection...
  • Page 25: Temperature Sensors

    5.3 Temperature sensors PT1000 Adhesive Sensor Connection Wire color Brown Ground White PT1000 temperature signal Configuration data Measurement Input Unit Gradient Offset Temperature PT1000 °C...
  • Page 26 IBC SolControl Sensor connection...
  • Page 27 PT100 adhesive sensor with signal converter Connection Wire color Ground White Temperature signal PT100 Configuration data Measurement Input Unit Gradient Offset Temperature Analog 0… 10 V °C § The following signal converters are available for connecting the temperature sensor: PT100 Signal converter 24 V power supply PT100 Signal converter 230 V power supply...
  • Page 28 IBC SolControl Sensor connection...
  • Page 29: Hygro-Thermal Sensors

    5.4 Hygro-thermal sensors compact hygro-thermal sensor Connection Wire color Yellow Power supply for humidity sensor (24 V DC) Black Power supply for temperature sensor (24 V DC) Green Temperature signal (4… 20 mA) Brown Ambient humidity signal (4… 20 mA) Configuration data Measurement Input...
  • Page 30 IBC SolControl Sensor connection...
  • Page 31: Wind Speed Sensors

    5.5 Wind speed sensors compact wind speed sensor (0… 10 V) / (4… 20 mA) Connection Wire color Yellow Wind speed signal ground Green Wind speed signal (4… 20 mA) Gray Power supply for heater (24 V AC or DC +) Pink Heater GND (24 V DC -) White...
  • Page 32 IBC SolControl Sensor connection...
  • Page 33: Wind Direction Sensors

    5.6 Wind direction sensors compact wind direction sensor (0… 10 V) / (4… 20 mA) Connection Wire color Yellow Wind direction signal GND Green Wind direction signal (4… 20 mA) Gray Power supply for heater (24 V AC or DC +) Pink Heater GND (24 V DC -) White...
  • Page 34 IBC SolControl Sensor connection...
  • Page 35: Weather Stations

    5.7 Weather stations Compact weather station WS501 / WS510 / WS600 UMB (Modbus RTU) Connection Wire color Yellow RS485 bus wire A (+) Green RS485 bus wire B (-) Brown Power supply for sensor (+24 V DC) White Sensor GND (-) Power supply for heater (+24 V DC) Blue Heater GND (-)
  • Page 36 IBC SolControl Sensor connection...
  • Page 37: Power Quality Analyzers

    6 Power quality analyzers 6.1 Janitza power quality analyzers UMG604 (Modbus RTU) § Set the bus address on the power quality analyzer (see power quality analyzer documentation). § If the device is the last one on the RS485 bus, terminate the bus with a 120 Ω terminating resistor.
  • Page 38 IBC SolControl Sensor connection...
  • Page 39: Energy Meter

    7 Energy meter 7.1 Three-phase energy meter ALE3 (Modbus RTU) energy meter § Set the bus address on the energy meter (see energy meter documentation). § If the device is the last one on the RS485 bus, terminate the bus with a 120 Ω terminating resistor.
  • Page 40 IBC SolControl Sensor connection...
  • Page 41 Energy meter ALE3 (S0) § Pulse value of the S0 interface is 1000 pul/kWh § Energy meter suitable for IPL function Configuring the IPL meter In the factory, the meter’ s S0 interface is set up in a way that allows for pulses to be transmitted in both directions (in and out), when energy is flowing.
  • Page 42 IBC SolControl Sensor connection...
  • Page 43: String Measuring Technology

    8 String measuring technology 8.1 IBC SolControl string measuring technology i’ catcher 8-1B, i’ catcher 16-1B, i’ catcher 24-1B (Modbus RTU) § Set the bus address on the i'catcher (see i'catcher documentation). § If this is the last bus device on the RS485 bus, set the terminating switches (Term.) to “...
  • Page 44 (1) RJ12 connector (IBC SolControl), Last i’ catcher RS485/RS422 (2) Pinout of Connect Universal RS Terminating resistor 120 Ω (3) Terminals (i’ catcher) Bus cable (4) First i’ catcher...
  • Page 45 IBC SolControl Connection i’ catcher, central power supply, separate shield IBC SolControl Connection i’ catcher, central power supply, connected shield...
  • Page 46 IBC SolControl Connection i’ catcher, decentralized power supply, separate shield IBC SolControl Connection i’ catcher decentralized power supply, connected shield...
  • Page 47 IBC SOLAR AG Am Hochgericht 10 96231 Bad Staffelstein Telefon +49 (0) 9573-92 24 0 Telefax +49 (0) 9573-92 24 111 info @ ibc-solar.de www.ibc-solar.de...
